Gerber Technology GERBERplotter MP Series User Manual

3
GERBERplotter MP Series User Manual
English
1.1 About the GERBERplotter MP Series
The GERBERplotter MP Series are ideal for plotting in an ultrawide format, yet are small enough to t into any de-
sign pattern making area. These plotters are quiet, easy to install, use minimal oor space, and can be conveniently
set against a wall. The GERBERplotter MP Series inkjet plotters are easy to use and feature high reliability, accu-
racy, and low operational costs. They are compatible with all Gerber products and offer a Windows-based graphical
interface for intuitive control and status messaging.
Technical datasheet
Power consumption 70W minimum
Power supply 85/264V auto switch
Interface USB 2.0 & LAN (optional)
Inkjet technology HP 1645 compatible | Xaar (optional)
Inkjet heads HP 1 7 2 / 3 / 4 | Xaar 1 / 2
Paper (g) Starting at 20 g/m
2
Paper (oz) Starting at 0.70548oz/m
Noise level < 40 dB
File formats accepted HPGL / HPGL2 / ISO
Package dimensions (1.8 m plotter) 2820 mm x 540 mm x 700 mm
(111.023 in. x 21.25 in. x 27.55 in.)
Package dimensions (2.2 m plotter) 3220 mm x 540 mm x 700 mm
(130.00 in. x 21.25 in. x 27.55 in.)
Net Weight (1.8 m plotter) 112 kg (247 lbs.)
Crated Weight (1.8 m plotter) 142 kg (313 lbs.)
Net Weight (2.2 m plotter) 118 kg (260 lbs.)
Crated Weight (2.2 m plotter) 152 kg (335 lbs.)
1.2 Customer support
Contact a Service Support Center with support or technical questions.
Please have the following information available prior to contacting Gerber support.
Service Support Center
Center phone number
Sales order number
Purchase date
Product name and type GERBERplotter MP Series
Optional equipment used

Gerber Technology GERBERplotter MP Series Specifications

General

Brand	Gerber Technology
Model	GERBERplotter MP Series
Category	Plotter
Language	English
