GERBERplotter MP Series User Manual

English

6.1.5 Extensions

Click Program options / Extensions to set whether ISO or HPGL formats are used.

With this option, you can lter by extension when viewing markers through the le browser.

Additionally, if a marker corresponds to a HPGL or ISO marker, its type is automatically identied.

Extensions

Format

Selects the format of extensions

Resolution

Lets you change the size of a marker, indicating the units and the divisor that are used

for the coordinate system (by default, HPGL uses 40 units per mm, 1016 per inch).

Format
