GERBERplotter MP Series User Manual
English
5.4.3 Print tests
The rst option in the ADJUST menu is the PRINTING CHECK, which allows you to perform a series of printing
tests.
This option checks that all the print heads function correctly.
1
Prints unidirectional continuous lines. This veries the print in one direction.
OK
1
2 3
KKK K
19:49
MENU
MENU

MENU
OK
MENU
Continuous lines in one or both print directions.
1
OK
PRINT
PAUSE
