Gerber Technology GERBERplotter MP Series User Manual

134
GERBERplotter MP Series User Manual
English
This dialog box lets you rotate the le 90 degrees clockwise or counterclockwise, mirror the le horizontally or
vertically, and magnify the image. You can include your changes in the job queue.
Double-click a job to preview the contents of a job that has already been added to the job queue.
Place job in queue.
Rotation (left/right). Flip (vertical/horizontal).
Magnify image.
6.1.10 History
Use the History / Queue les status tabs to access a table that displays all the tasks completed by User Manager.
This table displays the names of the les sent to the plotter, the IP address and the port used to connect with Server
Manager, the date and time they were added to the job queue, and a status indicator.
Possible status descriptions shown in history
Excess width error
The le exceeds the maximum allowed width for the plotter.
Rasterizing error
It was not possible to rasterize this le (page 127).
Printing error
An error occurred while sending the job, probably because it did not nish
printing.
Waiting to raster
File waiting to be rasterized.
Waiting for printing
Job waiting to be sent to the plotter.
Printing
Job is printing.
Printed
Job printed correctly.
Removed
Job removed from print queue.
Can’tsendle
The le cannot be sent to the server, probably because it has been stopped,
paused or User Manager cannot connect to it.
Server closed before raster
The server has stopped before nishing the rasterizing process.
