GERBERplotter MP Series User Manual
English
ERROR RF X
RF X errors occur when a main board chip is dam-
aged or running incorrectly.
ERROR MT X
MT X errors occur when a plotter motor is dam-
aged or is not working properly.
NEW CPU DETECTED
The main board is waiting for the conguration
le. Send the conguration le.
You can skip this message and start
to work by pressing the MENU but-
ton for few seconds, but printing
quality can be affected.
Print head motor
At the end of each printed line, and before the start of
the next line, the CPU waits for a response. If there is a
problem with the X axis, such as, heads don’t reach their
desired position, the CPU waits for the motor response
while showing the following error message and making a
beeping sound.
X1............X2............X3............X4............X5
Error
If this error appears, check that nothing is
blocking the movement of the printer bridge
along the X axis.
Paper motor
If there is no problem with the paper motor response, the
CPU wait for the Y motor response. If the paper doesn’t
reach its desired position, the CPU waits for the motor
response while showing the following error message and
making a beeping sound.
Y1............Y2............Y3............Y4............Y5
Error
If this error appears, check that nothing is
blocking the movement of the paper along the
Y axis.
CPU communication
Before printing the next line, the CPU reads printing
information from the main board’s memory.
If there is not enough information to print the entire line,
the job waits for more information to be sent and shows
the following error:
U1............U2............U3............U4............U5
Error
If this error appears, check that the plotter and
Server Manager are successfully communicat-
ing.
For any of the problems listed above, contact your Gerber Representative. Do not handle the plot-
ter on your own to avoid further damage.
8.1 Plotter error list
8.1.1 Error messages on display
