CHAPTER 2
Installing the GERBER EDGE FX
To set the IP Address and Network Mask for Windows 98 SE with IE 5.5 or higher
1 Click Start > Settings > Control Panel.
2 Double-click the Network icon.
3 Click the Configuration tab.
4 Click TCP/IP.
5 Click Properties to open the TCP/IP Properties dialog box.
Note: Depending on your setup, your computer's IP address may vary.
6 On the IP Address tab, click Specify an IP Address:
7 Enter 169.254.128.130 for the IP Address.
8 Enter 255.255.000.000 for Network Mask.
9 Do not enter a Gateway address; it is not required for direct connection.
10 Click OK to close the TCP/IP Properties dialog box.
11 Click OK to close the Network dialog box.

Gerber EDGE FX Specifications

General

Print Technology	Thermal transfer
Resolution	300 dpi
Connectivity	Parallel
Media Types	Vinyl, Reflective
Max Media Width	15 in (381 mm)
Max Print Width	11.8 in (300 mm)
