Gerber EDGE FX User Manual

16
CHAPTER 2
Installing the GERBER EDGE FX
10 Do not enter a Default Gateway; it is not required for direct connection. Leave the
fields blank.
11 Click OK to save the settings and exit the Internet Protocol (TCP/IP) Properties dialog
box.
12 Click OK to close the Local Area Connections Properties dialog box.
To set the IP Address and Network Mask for Windows 2000
1 Click Start > Settings > Control Panel.
2 Double-click the Network and Dial up Connections icon.
3 Right-click the Local Area Connection icon and choose Properties from the context
menu to display the Local Area Connection Properties dialog box.
4 Click Internet Protocol (TCP/IP) in the list.
5 Click Properties to open the Internet Protocol (TCP/IP) Properties dialog box.
Note: Depending on your setup, your computer's IP address may vary.

Gerber EDGE FX Specifications

General

Print Technology	Thermal transfer
Resolution	300 dpi
Connectivity	Parallel
Media Types	Vinyl, Reflective
Max Media Width	15 in (381 mm)
Max Print Width	11.8 in (300 mm)
