ProfiLux 4 Resource Guide

EN 2018-13-11 96

i. For example, if a single sensor is connected to Level 1/2, the sensor

would automatically be assigned as Level sensor #1.

2. Connect the Leak sensor(s) to the Leak interface. (Applies ONLY to those using Leak

sensors.)

CREATING THE FUNCTION

1. Click on the (+) icon to the left of

Probe/sensor controls

and select LEVEL.

2. Select an unused CONTROL CIRCUIT

3. Set the

Operation mode

to LEAKAGE DETECTION.

 Maximum on-time is not involved here. No changes need to be made.

4. If you wish to have the alarm for this function automatically reset when normal

operation is detected, check the box.

 If this box is left unchecked and an alarm is triggered by this function, ProfiLux

will keep the alarm ON and keep assigned Powerbar outlet OFF. The P4 will wait

for you to manually reset the alarm.

5. Select the sensor number that will be used for this function.

 For example, if you have the Leak interface or other sensor connected to the

Level 1/2 port without a splitter, select 1.

 If you are using a splitter cable on Level 1/2 and already have Level 1 assigned,

select 2.

6. Type-in a description for this Leakage detection function and click OK.
