Max. AC
output
Pin Conguration
Example
Circuit breaker
amps
1
2
3
0A (default)
Off
(0)
Off
(0)
Off
(0)
N/A
16A
On
(1)
Off
(0)
Off
(0)
20
24A
Off
(0)
On
(1)
Off
(0)
30
32A
On
(1)
On
(1)
Off
(0)
40
40A
Off
(0)
Off
(0)
On
(1)
50
48A
On
(1)
Off
(0)
On
(1)
60
64A
Off
(0)
On
(1)
On
(1)
80
80A
On
(1)
On
(1)
On
(1)
100
Table 3
