GM Energy V2H Bundle Installation Manual 46
Install Covers
If you will not complete pre-commissioning electrical and wiring checks and commissioning before leaving the site, install
and properly torque all equipment covers now:
Install the middle cover and torque the fourteen M4 ×12 mm Torx screws to 10.4 in-lb.
Install the front cover and torque the two M4 ×12 mm Torx screws to 10.4 in-lb.
Install the dead front, secure each door clasp, and close the cosmetic clasp covers.
Install the Inverter wing box cover and torque the five M4 x 14 mm Torx screws to 18 in-lb.
Install the front cover* and torque the two M4 x 9 mm Torx screws to 10.4 in-lb.
*Additional force on top corners of beauty cover may be required for proper fit onto Inverter box.
