GM Energy V2H Bundle Installation Manual 8
Main Components
Figure 2: Main components with covers removed
GM Energy
PowerShift
Charger
Bi-directional Electric Vehicle Supply
Equipment (EVSE)
Standalone AC charging up to 19.2 kW
14.8 × 20.9 × 6.3 in., 38.6 lb.
20.9 × 30.7 × 7.5 in., 94.8 lb.
15.2 × 13.7 × 2.5 in., 8.6 lb.
Microgrid interconnect device and
panel(s)
20.5 × 35.8 × 7.56 in., 45.2 lb.
Existing equipment (as pictured). May be replaced by Home
Hub depending on installation configuration
Also referred to as ESD (Emergency Shutdown Device).
*Installation of the Rapid Shutdown Device or Emergency Shutdown Device is highly recommended and may be required based on
local code or ordinance. Please consult with a qualified installer or electrician for more information.
