Option available when "CT at MID" selected.
This value dictates the total generation backfeed current limit from the
MID per the 120% rule.
A 200A MSP with a 200A main breaker will have the maximum
generation backfeed current at 40A. See NEC 705.12(D)(2)
Option available when "Single Power Source output limit" selected.
This value dictates the generation backfeed current limit from the
Inverter per the 120% rule.
A 200A MSP with a 200A main breaker, the maximum generation
backfeed current is 40A. See NEC 705.12(D)(2)
Check this box if this system has existing AC solar. The second meter (CT
2) will be placed to read the total output from this power source.
Refer to Appendix D: Electrical Diagrams for various installation setups
and recommended CT location settings
