24
COOLING PERFORMANCE DATA
GSH130301B*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSH130301BA / AR*F303016** Design Subcooling 9 ±3 °F @ the liquid service valve, AHRI 95 test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 27.0 28.0 30.7 - 26.4 27.4 30.0 - 25.8 26.7 29.3 - 25.2 26.1 28.6 - 23.9 24.8 27.1 - 22.1 22.9 25.1 -
S/T 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.82 0.69 0.48 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -
Delta T 16 14 10 - 16 14 11 - 16 14 11 - 16 14 11 - 16 14 11 - 15 13 10 -
1173 KW 2.04 2.08 2.14 - 2.19 2.24 2.31 - 2.32 2.37 2.45 - 2.44 2.49 2.57 - 2.54 2.60 2.68 - 2.63 2.69 2.77 -
AMPS 7.6 7.7 8.0 - 8.2 8.4 8.7 - 8.9 9.1 9.4 - 9.5 9.8 10.1 - 10.1 10.4 10.8 - 10.8 11.0 11.4 -
HI PR 146 158 166 - 164 177 187 - 187 201 212 - 213 229 242 - 239 258 272 - 264 285 301 -
LO PR 64 68 74 - 68 72 79 - 70 75 82 - 74 79 86 - 77 82 90 - 80 85 93 -
MBh 26.6 27.6 30.3 - 26.0 27.0 29.5 - 25.4 26.3 28.8 - 24.8 25.7 28.1 - 23.5 24.4 26.7 - 21.8 22.6 24.8 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
70 1050 KW 2.03 2.07 2.13 - 2.18 2.22 2.29 - 2.31 2.36 2.43 - 2.43 2.48 2.56 - 2.53 2.58 2.67 - 2.61 2.67 2.76 -
AMPS 7.5 7.7 8.0 - 8.1 8.3 8.6 - 8.8 9.1 9.4 - 9.5 9.7 10.0 - 10.1 10.3 10.7 - 10.7 11.0 11.3 -
HI PR 145 156 165 - 163 176 185 - 186 200 211 - 211 227 240 - 238 256 270 - 263 283 298 -
LO PR 64 68 74 - 67 72 78 - 70 74 81 - 73 78 85 - 77 82 89 - 80 85 92 -
MBh 25.3 26.2 28.7 - 24.7 25.6 28.1 - 24.1 25.0 27.4 - 23.5 24.4 26.7 - 22.4 23.2 25.4 - 20.7 21.5 23.5 -
S/T 0.69 0.57 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -
Delta T 17 15 11 - 17 15 11 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
927 KW 2.00 2.04 2.10 - 2.14 2.19 2.26 - 2.27 2.32 2.40 - 2.39 2.44 2.52 - 2.49 2.54 2.62 - 2.57 2.63 2.71 -
AMPS 7.4 7.6 7.8 - 8.0 8.2 8.5 - 8.7 8.9 9.2 - 9.3 9.5 9.8 - 9.9 10.1 10.5 - 10.5 10.8 11.1 -
HI PR 142 153 162 - 160 172 182 - 182 196 207 - 207 223 235 - 233 251 265 - 257 277 292 -
LO PR 62 66 72 - 66 70 77 - 68 73 80 - 72 77 84 - 75 80 88 - 78 83 91 -
MBh 27.5 28.3 30.6 32.9 26.9 27.7 29.9 32.1 26.2 27.0 29.2 31.4 25.6
26.3
28.5 30.6 24.3 25.0 27.1 29.1 22.5 23.2 25.1 26.9
S/T 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.61 0.39 0.94
0.84
0.63 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.66 0.43
Delta T1817 14 1019171410191714 10 19
17
14 10 18 17 14 10 17 16 13 9
1173 KW 2.05 2.10 2.16 2.23 2.21 2.25 2.32 2.40 2.34 2.39 2.47 2.55 2.46
2.52
2.60 2.68 2.56 2.62 2.70 2.79 2.65 2.71 2.80 2.89
AMPS 7.6 7.8 8.1 8.4 8.3 8.5 8.7 9.1 9.0 9.2 9.5 9.9 9.6
9.9
10.2 10.6 10.2 10.5 10.9 11.3 10.9 11.1 11.5 12.0
HI PR 148 159 168 175 166 179 189 197 189 203 214 224 215
231
244 255 242 260 275 287 267 288 304 317
LO PR 65 69 75 80 68 73 79 85 71 76 83 88 75
79
87 92 78 83 91 97 81 86 94 100
MBh 27.1 27.9 30.2 32.4 26.5 27.2 29.5 31.6 25.8 26.6 28.8 30.9 25.2
25.9
28.1 30.1 23.9 24.6 26.7 28.6 22.2 22.8 24.7 26.5
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90
0.80
0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
Delta T1918 15 1020181510201815 10 20
18
15 10 19 18 15 10 18 17 14 9
75 1050 KW 2.04 2.08 2.15 2.22 2.19 2.24 2.31 2.38 2.33 2.38 2.45 2.53 2.45
2.50
2.58 2.67 2.55 2.60 2.69 2.78 2.64 2.69 2.78 2.87
AMPS 7.6 7.8 8.0 8.3 8.2 8.4 8.7 9.0 8.9 9.2 9.5 9.8 9.6
9.8
10.1 10.5 10.2 10.4 10.8 11.2 10.8 11.1 11.4 11.9
HI PR 147 158 167 174 165 177 187 195 187 202 213 222 213
230
243 253 240 258 273 285 265 286 301 314
LO PR 64 68 75 80 68 72 79 84 71 75 82 87 74
79
86 92 78 83 90 96 80 86 93 99
MBh 25.7 26.5 28.7 30.8 25.1 25.9 28.0 30.1 24.5 25.3 27.3 29.4 23.9
24.6
26.7 28.6 22.7 23.4 25.3 27.2 21.1 21.7 23.5 25.2
S/T 0.78 0.70 0.53 0.34 0.81 0.73 0.55 0.35 0.83 0.74 0.56 0.36 0.86
0.77
0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39
Delta T2018 15 1020191511201915 11 20
19
15 11 20 19 15 10 19 17 14 10
927 KW 2.01 2.05 2.11 2.18 2.16 2.21 2.27 2.35 2.29 2.34 2.41 2.49 2.41
2.46
2.54 2.62 2.51 2.56 2.64 2.73 2.59 2.65 2.74 2.83
AMPS 7.4 7.6 7.9 8.2 8.1 8.3 8.5 8.9 8.8 9.0 9.3 9.6 9.4
9.6
9.9 10.3 10.0 10.2 10.6 11.0 10.6 10.9 11.2 11.7
HI PR 144 155 164 171 161 174 184 191 184 198 209 218 209
225
238 248 235 253 267 279 260 280 295 308
LO PR 63 67 73 78 67 71 77 82 69 74 80 86 73
77
84 90 76 81 88 94 79 84 91 97
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
