6
COOLING PERFORMANCE DATA
ASH130181A*
EXPANDED PERFORMANCE DATA
MODEL: ASH130181A* & ARUF032-00*-1* / ARUF18241A* COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 17.6 18.3 20.0 - 17.2 17.9 19.6 - 16.8 17.4 19.1 - 16.4 17.0 18.6 - 15.6 16.2 17.7 - 14.4 15.0 16.4 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.84 0.70 0.48 -
DT 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
662 KW 1.23 1.25 1.29 - 1.32 1.35 1.39 - 1.40 1.43 1.48 - 1.48 1.51 1.56 - 1.54 1.57 1.62 - 1.59 1.62 1.68 -
AMPS 4.8 5.0 5.1 - 5.2 5.3 5.5 - 5.7 5.8 6.0 - 6.0 6.2 6.4 - 6.4 6.5 6.8 - 6.8 6.9 7.2 -
HI PR 139 150 158 - 156 168 178 - 178 191 202 - 203 218 230 - 228 245 259 - 252 271 286 -
LO PR 61 65 71 - 65 69 75 - 67 72 78 - 71 75 82 - 74 79 86 - 77 82 89 -
MBh 17.1 17.7 19.4 - 16.7 17.3 19.0 - 16.3 16.9 18.5 - 15.9 16.5 18.1 - 15.1 15.7 17.2 - 14.0 14.5 15.9 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
DT 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
70 589 KW 1.22 1.24 1.28 - 1.31 1.34 1.38 - 1.39 1.42 1.47 - 1.46 1.49 1.54 - 1.52 1.56 1.61 - 1.58 1.61 1.66 -
AMPS 4.8 4.9 5.1 - 5.2 5.3 5.5 - 5.6 5.7 5.9 - 6.0 6.1 6.3 - 6.3 6.5 6.7 - 6.7 6.9 7.1 -
HI PR 138 149 157 - 155 167 176 - 176 190 200 - 201 216 228 - 226 243 256 - 249 268 283 -
LO PR 61 65 71 - 64 68 75 - 67 71 78 - 70 75 82 - 74 78 85 - 76 81 88 -
MBh 15.8 16.4 17.9 - 15.4 16.0 17.5 - 15.1 15.6 17.1 - 14.7 15.2 16.7 - 14.0 14.5 15.9 - 12.9 13.4 14.7 -
S/T 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.43 - 0.76 0.64 0.44 - 0.77 0.64 0.45 -
DT 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 16 12 - 18 15 12 -
515 KW 1.19 1.22 1.25 - 1.28 1.31 1.35 - 1.36 1.39 1.43 - 1.43 1.46 1.51 - 1.49 1.52 1.57 - 1.54 1.57 1.62 -
AMPS 4.7 4.8 4.9 - 5.0 5.2 5.3 - 5.5 5.6 5.8 - 5.8 5.9 6.1 - 6.2 6.3 6.5 - 6.5 6.7 6.9 -
HI PR 134 144 152 - 150 162 171 - 171 184 194 - 195 209 221 - 219 236 249 - 242 260 275 -
LO PR 59 63 69 - 62 66 72 - 65 69 75 - 68 72 79 - 71 76 83 - 74 79 86 -
MBh 17.9 18.5 20.0 21.5 17.5 18.0 19.5 21.0 17.1 17.6 19.1 20.5 16.7 17.2 18.6 20.0 15.9 16.3 17.7 19.0 14.7 15.1 16.4 17.6
S/T 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.61 0.40 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41
DT 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10
662 KW 1.24 1.26 1.30 1.34 1.33 1.36 1.40 1.45 1.41 1.44 1.49 1.54 1.49 1.52 1.57 1.62 1.55 1.58 1.63 1.69 1.60 1.64 1.69 1.75
AMPS 4.9 5.0 5.2 5.3 5.3 5.4 5.6 5.8 5.7 5.8 6.0 6.2 6.1 6.2 6.4 6.7 6.5 6.6 6.8 7.1 6.8 7.0 7.2 7.5
HI PR 141 152 160 167 158 170 180 187 180 193 204 213 205 220 233 243 230 248 262 273 254 274 289 302
LO PR 62 66 72 77 66 70 76 81 68 73 79 84 72 76 83 89 75 80 87 93 78 83 90 96
MBh 17.4 17.9 19.4 20.8 17.0 17.5 19.0 20.3 16.6 17.1 18.5 19.9 16.2 16.7 18.1 19.4 15.4 15.8 17.2 18.4 14.3 14.7 15.9 17.1
S/T 0.79 0.71 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.37 0.87 0.77 0.59 0.38 0.90 0.80 0.61 0.39 0.91 0.81 0.61 0.39
DT 21 20 16 11 22 20 16 11 22 20 16 11 22
20
17 11 22 20 16 11 20 19 15 11
75 589 KW 1.23 1.25 1.29 1.33 1.32 1.35 1.39 1.44 1.40 1.43 1.48 1.53 1.48
1.51
1.56 1.61 1.54 1.57 1.62 1.68 1.59 1.62 1.68 1.73
AMPS 4.8 5.0 5.1 5.3 5.2 5.3 5.5 5.7 5.7 5.8 6.0 6.2 6.0 6.2 6.4 6.6 6.4 6.5 6.8 7.0 6.8 6.9 7.2 7.4
HI PR 139 150 158 165 156 168 178 185 178 192 202 211 203 218 230 240 228 245 259 270 252 271 286 299
LO PR 61 65 71 76 65 69 75 80 67 72 78 83 71
75
82 88 74 79 86 92 77 82 89 95
MBh 16.1 16.5 17.9 19.2 15.7 16.2 17.5 18.8 15.3 15.8 17.1 18.3 15.0 15.40 16.7 17.9 14.2 14.6 15.8 17.0 13.2 13.5 14.7 15.7
S/T 0.76 0.68 0.52 0.33 0.79 0.71 0.53 0.34 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.36 0.87 0.78 0.59 0.38 0.87 0.78 0.59 0.38
DT 22 20 16 11 22 20 17 12 22 20 17 12 22 21 17 12 22 20 17 11 21 19 15 11
515 KW 1.20 1.23 1.26 1.30 1.29 1.32 1.36 1.40 1.37 1.40 1.44 1.49 1.44 1.47 1.52 1.57 1.50 1.53 1.58 1.63 1.55 1.58 1.64 1.69
AMPS 4.7 4.8 5.0 5.2 5.1 5.2 5.4 5.6 5.5 5.6 5.8 6.0 5.9 6.0 6.2 6.4 6.2 6.4 6.6 6.8 6.6 6.7 7.0 7.2
HI PR 135 146 154 160 152 163 172 180 173 186 196 205 197 212 223 233 221 238 251 262 244 263 278 290
LO PR 60 63 69 74 63 67 73 78 65 70 76 81 69 73 80 85 72 77 84 89 75 79 87 92
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
