High pressure is measured at the suction service valve ( the larger valve). AMPS = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connection. KW = Total system power
Calculations are based on nominal CFM and 70 °F indoor dry bulb.
HEATING PERFORMANCE DATA
EXPANDED PERFORMANCE DATA
MODEL: GSH13048-4A* / ARUF61-00*-1* / ARUF48601A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 54.1 51.2 48.2 45.0 43.0 41.7 38.7 35.7 43.6 40.3 37.1 35.0 33.7 30.2 26.8 23.4 20.0 16.3
Delta T 31.3 29.6 27.9 26.1 24.9 24.1 22.4 20.7 25.2 23.3 21.4 20.3 19.5 17.5 15.5 13.5 11.5 9.5
KW 3.87 3.78 3.70 3.61
3.56
3.52 3.44 3.36 3.29 3.20 3.12 3.07 3.03 2.95 2.86 2.78 2.69 2.61
AMPS 3.7 3.5 3.3 3.1 3.0 3.0 2.8 2.7 2.6 2.5 2.4 2.3 2.3 2.2 2.1 2.0 1.9 1.7
COP 4.093.963.813.653.533.463.293.113.883.683.483.343.253.002.742.462.171.84
EER 14.0 13.5 13.0 12.5 12.1 11.8 11.2 10.6 13.3 12.6 11.9 11.4 11.1 10.3 9.4 8.4 7.4 6.3
HI PR 180 172 166 158 155 152 146 140 134 128 123 120 118 113 109 105 101 97
LO PR 74 68 64 59 56 53 49 44 39 35 31 29 28 23 20 17 15 12
*Note: Shaded area is AHRI Rating Conditions at 47° outdoor ambient temperature.
EXPANDED PERFORMANCE DATA
MODEL: GSH130483A* / ARUF61-00*-1* / ARUF48601A
HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 54.1 51.2 48.2 45.0
43.0
41.738.735.733.631.128.627.026.023.320.718.015.412.6
Delta T31.329.627.926.124.924.122.420.719.518.016.515.615.013.512.010.4 8.9 7.3
KW 3.71 3.64 3.57 3.50
3.45
3.42 3.35 3.28 3.34 3.26 3.19 3.14 3.11 3.04 2.96 2.89 2.81 2.74
AMPS 14.6 13.6 12.7 12.0 11.6 11.3 10.7 10.2 9.8 9.3 8.9 8.7 8.6 8.2 7.7 7.2 6.7 6.1
COP 4.264.113.953.773.643.563.383.182.952.792.632.512.442.252.041.831.601.35
EER 14.6 14.1 13.5 12.9 12.4 12.2 11.5 10.9 10.1 9.5 9.0 8.6 8.4 7.7 7.0 6.2 5.5 4.6
HI PR 224 215 206 197 193 189 182 174 167 159 153 149 147 141 136 130 126 121
LO PR 73 68 64 58 55 53 49 44 39 35 31 29 28 23 20 17 15 12
High pressure is measured at the suction service valve ( the larger valve). AMPS = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connection. KW = Total system power
Calculations are based on nominal CFM and 70 °F indoor dry bulb.
*Note: Shaded area is AHRI Rating Conditions at 47° outdoor ambient temperature.
