COOLING PERFORMANCE DATA
GSH130181B*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSH130181B* / AR*F182416** Design Subcooling 9 ±3 °F @ the liquid service valve, AHRI 95 test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 17.6 18.3 20.0 - 17.2 17.9 19.6 - 16.8 17.4 19.1 - 16.4 17.0 18.6 - 15.6 16.2 17.7 - 14.4 15.0 16.4 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
Delta T 16 14 11 - 16 14 11 - 16 14 11 - 16 14 11 - 16 14 11 - 15 13 10 -
731 KW 1.24 1.26 1.30 - 1.33 1.35 1.40 - 1.41 1.43 1.48 - 1.48 1.51 1.55 - 1.53 1.57 1.61 - 1.58 1.62 1.67 -
AMPS 4.7 4.8 4.9 - 5.0 5.1 5.3 - 5.4 5.6 5.8 - 5.8 5.9 6.1 - 6.2 6.3 6.5 - 6.5 6.7 6.9 -
HI PR 135 146 154 - 152 164 173 - 173 186 196 - 197 212 224 - 221 238 252 - 245 263 278 -
LO PR 63 67 73 - 66 71 77 - 69 73 80 - 72 77 84 - 76 81 88 - 79 84 91 -
MBh 17.1 17.7 19.4 - 16.7 17.3 19.0 - 16.3 16.9 18.5 - 15.9 16.5 18.1 - 15.1 15.7 17.2 - 14.0 14.5 15.9 -
S/T 0.69 0.58 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.79 0.66 0.45 - 0.79 0.66 0.46 -
Delta T 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
70 650 KW 1.23 1.25 1.29 - 1.32 1.34 1.38 - 1.40 1.42 1.47 - 1.46 1.49 1.54 - 1.52 1.55 1.60 - 1.57 1.61 1.66 -
AMPS 4.6 4.7 4.9 - 5.0 5.1 5.3 - 5.4 5.5 5.7 - 5.8 5.9 6.1 - 6.1 6.3 6.5 - 6.5 6.6 6.9 -
HI PR 134 144 152 - 150 162 171 - 171 184 194 - 195 210 221 - 219 236 249 - 242 261 275 -
LO PR 62 66 72 - 66 70 76 - 68 73 79 - 72 76 83 - 75 80 87 - 78 83 90 -
MBh 15.8 16.4 17.9 - 15.4 16.0 17.5 - 15.1 15.6 17.1 - 14.7 15.2 16.7 - 14.0 14.5 15.9 - 12.9 13.4 14.7 -
S/T 0.67 0.56 0.38 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.76 0.64 0.44 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
569 KW 1.20 1.23 1.26 - 1.29 1.31 1.35 - 1.36 1.39 1.43 - 1.43 1.46 1.50 - 1.49 1.52 1.56 - 1.53 1.57 1.62 -
AMPS 4.5 4.6 4.7 - 4.8 5.0 5.1 - 5.3 5.4 5.6 - 5.6 5.7 5.9 - 6.0 6.1 6.3 - 6.3 6.5 6.7 -
HI PR 130 140 148 - 146 157 166 - 166 179 189 - 189 203 215 - 213 229 242 - 235 253 267 -
LO PR 60 64 70 - 64 68 74 - 66 70 77 - 70 74 81 - 73 78 85 - 75 80 88 -
MBh 17.9 18.5 20.0 21.5 17.5 18.0 19.5 21.0 17.1 17.6 19.1 20.5 16.7 17.2 18.6 20.0 15.9 16.3 17.7 19.0 14.7 15.1 16.4 17.6
S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.94 0.84 0.63 0.41 0.94 0.84 0.64 0.41
Delta T19 17141019171410191714 101917141019171410171613 9
731 KW 1.25 1.27 1.31 1.35 1.34 1.37 1.41 1.45 1.42 1.45 1.49 1.54 1.49 1.52 1.56 1.61 1.55 1.58 1.63 1.68 1.60 1.63 1.68 1.74
AMPS 4.7 4.8 5.0 5.1 5.1 5.2 5.4 5.5 5.5 5.6 5.8 6.0 5.9 6.0 6.2 6.4 6.2 6.4 6.6 6.8 6.6 6.8 7.0 7.2
HI PR 137 147 155 162 154 165 174 182 175 188 198 207 199 214 226 236 224 241 254 265 247 266 281 293
LO PR 63 67 74 78 67 71 78 83 70 74 81 86 73 78 85 91 77 82 89 95 79 84 92 98
MBh 17.4 17.9 19.4 20.8 17.0 17.5 19.0 20.3 16.6 17.1 18.5 19.9 16.2
16.7
18.1 19.4 15.4 15.8 17.2 18.4 14.3 14.7 15.9 17.1
S/T 0.78 0.70 0.53 0.34 0.81 0.73 0.55 0.35 0.83 0.75 0.56 0.36 0.86
0.77
0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.81 0.61 0.39
Delta T19 18151020181510201815 1020
18
15 10 19 18 15 10 18 17 14 9
75 650 KW 1.24 1.26 1.30 1.34 1.33 1.35 1.40 1.44 1.41 1.44 1.48 1.53 1.48
1.51
1.55 1.60 1.53 1.57 1.62 1.67 1.58 1.62 1.67 1.72
AMPS 4.7 4.8 4.9 5.1 5.0 5.1 5.3 5.5 5.4 5.6 5.8 6.0 5.8
5.9
6.1 6.4 6.2 6.3 6.5 6.8 6.5 6.7 6.9 7.2
HI PR 135 146 154 161 152 164 173 180 173 186 196 205 197
212
224 233 222 238 252 263 245 263 278 290
LO PR 63 67 73 78 66 71 77 82 69 73 80 85 72
77
84 90 76 81 88 94 79 84 91 97
MBh 16.1 16.5 17.9 19.2 15.7 16.2 17.5 18.8 15.3 15.8 17.1 18.3 15.0 15.40 16.7 17.9 14.2 14.6 15.8 17.0 13.2 13.5 14.7 15.7
S/T 0.76 0.68 0.51 0.33 0.78 0.70 0.53 0.34 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.87 0.78 0.59 0.38
Delta T20 18151020181510201815 10201815102018151018171410
569 KW 1.21 1.24 1.27 1.31 1.30 1.32 1.36 1.40 1.37 1.40 1.44 1.49 1.44 1.47 1.52 1.56 1.50 1.53 1.58 1.63 1.55 1.58 1.63 1.68
AMPS 4.5 4.6 4.8 5.0 4.9 5.0 5.2 5.4 5.3 5.4 5.6 5.8 5.7 5.8 6.0 6.2 6.0 6.2 6.4 6.6 6.4 6.5 6.7 7.0
HI PR 131 141 149 156 147 159 168 175 168 180 191 199 191 206 217 226 215 231 244 255 237 255 270 281
LO PR 61 65 71 75 64 68 75 80 67 71 78 83 70 75 82 87 74 78 86 91 76 81 88 94
Shaded area i s ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total s
y
stem powe
r
AMPS=outdoor unit amps (comp.+fan)
High and low pressures ar e measured at the liquid and suction service valves.
