COOLING PERFORMANCE DATA

ASH130601A*

EXPANDED PERFORMANCE DATA

MODEL: ASH130601A* & ARUF061-00*-1* / ARUF48601A* COOLING OPERATION

Outdoor Ambient Temperature

65 75 85 95 105 115

Entering Indoor Wet Bulb Temperature

IDB Airflow 59 6

67 71 59 6

67 71 59 63 67 71 59 6

67 71

MBh 54.4 56.4 61.8 - 53.1 55.1 60.3 - 51.9 53.7 58.9 - 50.6 52.4 57.5 - 48.1 49.8 54.6 - 44.5 46.1 50.6 -

S/T 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.83 0.69 0.48 -

DT 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -

1983 KW 3.84 3.92 4.03 - 4.12 4.20 4.32 - 4.36 4.45 4.58 - 4.57 4.67 4.81 - 4.75 4.85 5.00 - 4.91 5.01 5.17 -

AMPS 13.8 14.1 14.6 - 14.9 15.2 15.7 - 16.2 16.6 17.1 - 17.3 17.7 18.3 - 18.4 18.8 19.5 - 19.5 20.0 20.6 -

HI PR 140 151 159 - 157 169 179 - 179 193 204 - 204 220 232 - 229 247 261 - 254 273 288 -

LO PR 59 63 68 - 62 66 72 - 65 69 75 - 68 72 79 - 71 76 82 - 73 78 85 -

MBh 52.8 54.7 60.0 - 51.6 53.5 58.6 - 50.3 52.2 57.2 - 49.1 50.9 55.8 - 46.7 48.4 53.0 - 43.2 44.8 49.1 -

S/T 0.69 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -

DT 19 16 12 - 19 17 13 - 19 17 13 - 19 17 13 - 19 16 13 - 18 15 12 -

70 1763 KW 3.81 3.89 4.00 - 4.09 4.17 4.29 - 4.32 4.41 4.55 - 4.54 4.63 4.77 - 4.72 4.81 4.96 - 4.87 4.97 5.13 -

AMPS 13.7 14.0 14.4 - 14.8 15.1 15.6 - 16.0 16.4 17.0 - 17.1 17.5 18.1 - 18.2 18.7 19.3 - 19.3 19.8 20.5 -

HI PR 139 150 158 - 156 168 177 - 177 191 202 - 202 217 230 - 227 245 258 - 251 270 285 -

LO PR 58 62 68 - 61 65 71 - 64 68 74 - 67 71 78 - 70 75 82 - 73 77 84 -

MBh 48.7 50.5 55.3 - 47.6 49.3 54.1 - 46.5 48.2 52.8 - 45.3 47.0 51.5 - 43.1 44.6 48.9 - 39.9 41.4 45.3 -

S/T 0.66 0.55 0.38 - 0.69 0.57 0.40 - 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.76 0.64 0.44 -

DT 19 17 13 - 19 17 13 - 19 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -

1542 KW 3.73 3.80 3.91 - 3.99 4.07 4.19 - 4.23 4.31 4.44 - 4.43 4.52 4.66 - 4.60 4.70 4.85 - 4.75 4.85 5.01 -

AMPS 13.3 13.6 14.0 - 14.4 14.7 15.2 - 15.6 16.0 16.5 - 16.7 17.1 17.6 - 17.7 18.2 18.8 - 18.8 19.2 19.9 -

HI PR 135 145 153 - 151 163 172 - 172 185 195 - 196 211 223 - 220 237 250 - 244 262 277 -

LO PR 56 60 66 - 60 63 69 - 62 66 72 - 65 69 76 - 68 73 79 - 71 75 82 -

MBh 55.3 56.9 61.6 66.2 54.0 55.6 60.2 64.6 52.7 54.3 58.8 63.1 51.4 53.0 57.3 61.5 48.9 50.3 54.5 58.5 45.3 46.6 50.5 54.2

S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.41 0.94 0.84 0.64 0.41

DT 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 19 16 11 20 18 15 10

1983 KW 3.87 3.95 4.06 4.18 4.15 4.23 4.36 4.49 4.39 4.48 4.62 4.76 4.61 4.70 4.85 5.00 4.79 4.89 5.04 5.21 4.95 5.05 5.21 5.38

AMPS 13.9 14.2 14.7 15.2 15.0 15.4 15.9 16.5 16.3 16.7 17.3 17.9 17.4 17.9 18.5 19.2 18.6 19.0 19.7 20.4 19.7 20.2 20.8 21.6

HI PR 142 153 161 168 159 171 181 189 181 195 206 214 206 222 234 244 232 249 263 275 256 276 291 304

LO PR 59 63 69 73 63 67 73 78 65 69 76 81 68 73 80 85 72 76 83 89 74 79 86 92

MBh 53.7 55.3 59.8 64.2 52.4 54.0 58.4 62.7 51.2 52.7 57.1 61.2 50.0

51.4

55.7 59.7 47.5 48.9 52.9 56.8 44.0 45.3 49.0 52.6

S/T 0.78 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39

DT 22 20 16 11 22 20 17 12 22 20 17 12 22 21 17 12 22 20 17 11 21 19 16 11

75 1763 KW 3.84 3.92 4.03 4.15 4.12 4.20 4.32 4.46 4.36 4.45 4.58 4.73 4.57 4.67 4.81 4.96 4.75 4.85 5.00 5.16 4.91 5.01 5.17 5.34

AMPS 13.8 14.1 14.6 15.1 14.9 15.2 15.7 16.3 16.2 16.6 17.1 17.8 17.3 17.7 18.3 19.0 18.4 18.8 19.5 20.2 19.5 20.0 20.6 21.4

HI PR 140 151 160 166 158 170 179 187 179 193 204 212 204 220 232 242 230 247 261 272 254 273 288 301

LO PR 59 63 68 73 62 66 72 77 65 69 75 80 68 72 79 84 71 76 82 88 73 78 85 91

MBh 49.6 51.0 55.2 59.3 48.4 49.8 53.9 57.9 47.3 48.7 52.7 56.5 46.1 47.47 51.4 55.1 43.8 45.1 48.8 52.4 40.6 41.8 45.2 48.5

S/T 0.75 0.67 0.51 0.33 0.78 0.70 0.53 0.34 0.80 0.72 0.54 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.86 0.77 0.59 0.38

DT 22 20 17 12 23 21 17 12 23 21 17 12 23 21 17 12 22 21 17 12 21 19 16 11

1542 KW 3.76 3.83 3.94 4.06 4.02 4.10 4.23 4.35 4.26 4.34 4.48 4.61 4.46 4.56 4.70 4.84 4.64 4.74 4.88 5.04 4.79 4.89 5.05 5.21

AMPS 13.4 13.7 14.2 14.7 14.5 14.8 15.3 15.9 15.7 16.1 16.6 17.3 16.8 17.2 17.8 18.5 17.9 18.3 18.9 19.7 19.0 19.4 20.1 20.8

HI PR 136 147 155 161 153 164 174 181 174 187 197 206 198 213 225 235 223 240 253 264 246 265 280 292

LO PR 57 61 66 71 60 64 70 74 63 67 73 77 66 70 76 81 69 73 80 85 71 76 83 88

Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)

High and low pressures are measured at the liquid and suction service valves.
