6
GSH101203AC
HEAT PUMP SPECIFICATIONS
(1)
Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection: Must use fuses or HACR-type Circuit Breakers of the same size as noted.
NOTES:
* Always check the S&R plate for electrical data on the unit being installed.
* Installer will need to supply 7/8" to 1 1/8" adapters for suction line connections.
* Unit is charged with refrigerant for 15' of 3/8" liquid line. System charge must be adjusted per Installation Instructions Final Charge Procedure.
* Installation of these units that require a TXV Kit to be installed on the indoor coil: PLEASE NOTE: THE SPECIFIED TXV IS DETERMINED BY THE OUTDOOR UNIT
NOT THE INDOOR COIL
GSH101203AC
Cooling Capacity, BTUH 110,000
Compressor
R.L. Amps 30.1
L.R. Amps 225
Loss of Charge Pressure Switch
Open / Close 7 PSIG/25 PSIG
Condenser Fan Motor
Horsepower 1
F.L. Amps 5.6
Liquid Line, Inches O.D. ⅝"
Suction Line, Inches O.D. 1⅛"
Refrigerant Charge 30
Design Subcooling Cooling (°F) 9 +
3
Power Supply 208/230-60-3
Minimum Circuit Ampacity
(1)
43.2
Maximum Overcurrent Device
(2)
70
Electrical Conduit Size
Power Supply (Inches) ½" or ¾"
Approximate Shipping Weight 296
