HEATING PERFORMANCE DATA
High pressure is measured at the suction service valve ( the larger valve). AMPS = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connection. KW = Total system power
Calculations are based on nominal CFM and 70 °F indoor dry bulb.
*Note: Shaded area is AHRI Rating Conditions at 47° outdoor ambient temperature
EXPANDED PERFORMANCE DATA
MODEL: GSH130301A* / ARUF42-00*-01* / ARUF30301A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 33.7 31.9 30.0 28.1
26.8
26.0 24.1 22.2 17.4 16.1 14.8 14.0 13.5 12.1 10.7 9.4 8.0 6.5
Delta T29.728.126.524.723.622.921.319.615.414.213.112.311.910.7 9.5 8.2 7.0 5.8
KW 2.41 2.36 2.32 2.27
2.24
2.22 2.18 2.13 2.08 2.04 1.99 1.96 1.95 1.90 1.85 1.81 1.76 1.72
AMPS 11.1 10.3 9.6 9.1 8.7 8.6 8.1 7.7 7.3 7.0 6.7 6.5 6.4 6.1 5.7 5.3 4.9 4.4
COP 4.09 3.95 3.79 3.62 3.50 3.42 3.24 3.05 2.45 2.31 2.18 2.09 2.03 1.86 1.69 1.51 1.32 1.11
EER 14.0 13.5 13.0 12.4 11.9 11.7 11.1 10.4 8.4 7.9 7.4 7.1 6.9 6.4 5.8 5.2 4.5 3.8
HI PR 234 224 216 206 202 198 190 182 175 167 160 156 154 148 142 136 131 127
LO PR 76 70 66 61 57 55 51 45 41 36 32 30 29 24 21 18 15 12
EXPANDED PERFORMANCE DATA
MODEL: GSH130301BA / AR*F303016** HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 33.2 31.4 29.6 27.6
26.4
25.6 23.8 21.9 17.4 16.1 14.8 14.0 13.5 12.1 10.7 9.4 8.0 6.5
Delta T 29.3 27.7 26.1 24.4 23.3 22.6 21.0 19.3 15.4 14.2 13.1 12.3 11.9 10.7 9.5 8.2 7.0 5.8
KW 2.41 2.36 2.32 2.27
2.24
2.22 2.18 2.13 2.02 1.98 1.94 1.91 1.89 1.85 1.80 1.76 1.72 1.67
AMPS 11.1 10.3 9.6 9.1 8.7 8.6 8.1 7.6 7.3 7.0 6.6 6.5 6.4 6.1 5.6 5.3 4.9 4.4
COP 4.03 3.89 3.74 3.56 3.44 3.37 3.19 3.01 2.52 2.38 2.24 2.15 2.08 1.92 1.74 1.55 1.36 1.14
EER 13.8 13.3 12.8 12.2 11.8 11.5 10.9 10.3 8.6 8.1 7.7 7.3 7.1 6.5 5.9 5.3 4.6 3.9
HI PR 234 224 216 206 202 198 190 182 175 167 160 156 154 148 142 136 131 127
LO PR 76 70 66 61 57 55 51 45 41 36 32 30 29 24 21 18 15 12
EXPANDED PERFORMANCE DATA
MODEL: GSH130251A* / AWB36-XX / AWUF36XX1A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 28.4 26.9 25.3 23.7
22.6
21.9 20.3 18.8 17.1 15.7 14.5 13.7 13.2 11.8 10.5 9.1 7.8 6.4
Delta T32.130.428.626.725.524.723.021.219.317.816.415.514.913.411.810.3 8.8 7.2
KW 2.31 2.27 2.23 2.18
2.16
2.14 2.10 2.05 1.90 1.86 1.82 1.80 1.78 1.74 1.70 1.66 1.62 1.58
AMPS11.110.39.79.18.88.78.27.87.57.26.96.86.76.46.05.75.34.9
COP 3.59 3.47 3.33 3.17 3.07 3.00 2.84 2.67 2.62 2.48 2.33 2.23 2.17 1.99 1.81 1.61 1.41 1.19
EER 12.3 11.8 11.4 10.8 10.5 10.2 9.7 9.1 9.0 8.5 8.0 7.6 7.4 6.8 6.2 5.5 4.8 4.0
HI PR 178 170 164 157 153 150 144 138 133 127 122 119 117 112 108 103 100 96
LO PR 76 71 66 61 58 55 51 45 41 37 32 30 29 24 21 18 15 12
EXPANDED PERFORMANCE DATA
MODEL: GSH130241B* / AR*F182416** HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 27.7 26.2 24.6 23.0
22.0
21.3 19.8 18.3 15.0 13.8 12.7 12.0 11.6 10.4 9.2 8.0 6.8 5.6
Delta T30.128.526.825.124.023.221.619.916.315.013.813.112.611.310.0 8.7 7.5 6.1
KW 1.99 1.95 1.91 1.87
1.85
1.84 1.80 1.76 1.70 1.66 1.62 1.60 1.59 1.55 1.51 1.48 1.44 1.40
AMPS9.08.37.87.37.16.96.56.25.95.75.45.35.24.94.64.34.03.6
COP 4.07 3.93 3.77 3.60 3.47 3.40 3.22 3.03 2.58 2.44 2.29 2.19 2.13 1.96 1.78 1.59 1.39 1.17
EER 13.9 13.4 12.9 12.3 11.9 11.6 11.0 10.4 8.8 8.3 7.8 7.5 7.3 6.7 6.1 5.4 4.8 4.0
HI PR 238 228 220 210 205 201 193 186 178 170 163 159 156 150 145 139 134 129
LO PR 80 74 69 63 60 58 53 47 43 38 33 31 30 25 22 18 16 13
