COOLING PERFORMANCE DATA
GSH130181A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSH130181A* / ARUF32-00*-1* / ARUF18241A*
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 17.6 18.3 20.0 - 17.2 17.9 19.6 - 16.8 17.4 19.1 - 16.4 17.0 18.6 - 15.6 16.2 17.7 - 14.4 15.0 16.4 -
S/T 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -
Delta T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 15 12 - 17 14 11 -
675 KW 1.26 1.29 1.33 - 1.36 1.39 1.43 - 1.44 1.47 1.52 - 1.51 1.55 1.59 - 1.57 1.61 1.66 - 1.63 1.66 1.72 -
AMPS 4.8 4.9 5.1 - 5.2 5.3 5.5 - 5.6 5.7 5.9 - 6.0 6.1 6.3 - 6.4 6.5 6.7 - 6.7 6.9 7.1 -
HI PR 137 147 156 - 154 165 175 - 175 188 199 - 199 214 226 - 224 241 255 - 248 266 281 -
LO PR 63 67 73 - 66 70 77 - 69 73 80 - 72 77 84 - 76 81 88 - 78 83 91 -
MBh 17.1 17.7 19.4 - 16.7 17.3 19.0 - 16.3 16.9 18.5 - 15.9 16.5 18.1 - 15.1 15.7 17.2 - 14.0 14.5 15.9 -
S/T 0.70 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.45 - 0.80 0.67 0.46 - 0.81 0.67 0.47 -
Delta T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
70 600 KW 1.26 1.28 1.32 - 1.35 1.38 1.42 - 1.43 1.46 1.50 - 1.50 1.53 1.58 - 1.56 1.60 1.65 - 1.61 1.65 1.70 -
AMPS 4.8 4.9 5.0 - 5.1 5.2 5.4 - 5.6 5.7 5.9 - 5.9 6.1 6.3 - 6.3 6.4 6.7 - 6.7 6.8 7.1 -
HI PR 136 146 154 - 152 164 173 - 173 186 197 - 197 212 224 - 222 239 252 - 245 264 279 -
LO PR 62 66 72 - 66 70 76 - 68 72 79 - 72 76 83 - 75 80 87 - 78 83 90 -
MBh 15.8 16.4 17.9 - 15.4 16.0 17.5 - 15.1 15.6 17.1 - 14.7 15.2 16.7 - 14.0 14.5 15.9 - 12.9 13.4 14.7 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.78 0.65 0.45 -
Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 17 13 - 19 16 12 - 18 15 12 -
525 KW 1.23 1.25 1.29 - 1.32 1.34 1.38 - 1.40 1.42 1.47 - 1.47 1.50 1.54 - 1.52 1.56 1.61 - 1.58 1.61 1.66 -
AMPS 4.6 4.7 4.9 - 5.0 5.1 5.3 - 5.4 5.5 5.7 - 5.8 5.9 6.1 - 6.1 6.3 6.5 - 6.5 6.6 6.9 -
HI PR 132 142 150 - 148 159 168 - 168 181 191 - 191 206 217 - 215 232 245 - 238 256 270 -
LO PR 60 64 70 - 64 68 74 - 66 70 77 - 69 74 81 - 73 77 84 - 75 80 87 -
MBh 17.9 18.5 20.0 21.5 17.5 18.0 19.5 21.0 17.1 17.6 19.1 20.5 16.7 17.2 18.6 20.0 15.9 16.3 17.7 19.0 14.7 15.1 16.4 17.6
S/T 0.84 0.75 0.57 0.36 0.87 0.78 0.59 0.38 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.65 0.42 0.96 0.86 0.65 0.42
Delta T20 1915112119161121191611211916112119161119181510
675 KW 1.27 1.30 1.34 1.38 1.37 1.40 1.44 1.49 1.45 1.48 1.53 1.58 1.53 1.56 1.61 1.66 1.59 1.62 1.67 1.73 1.64 1.68 1.73 1.79
AMPS 4.8 4.9 5.1 5.3 5.2 5.3 5.5 5.7 5.7 5.8 6.0 6.2 6.0 6.2 6.4 6.6 6.4 6.6 6.8 7.0 6.8 7.0 7.2 7.5
HI PR 138 149 157 164 155 167 177 184 177 190 201 209 201 217 229 238 226 244 257 268 250 269 284 296
LO PR 63 67 74 78 67 71 78 83 70 74 81 86 73 78 85 90 77 81 89 95 79 84 92 98
MBh 17.4 17.9 19.4 20.8 17.0 17.5 19.0 20.3 16.6 17.1 18.5 19.9 16.2 16.7 18.1 19.4 15.4 15.8 17.2 18.4 14.3 14.7 15.9 17.1
S/T 0.80 0.71 0.54 0.35 0.83 0.74 0.56 0.36 0.85 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.91 0.81 0.62 0.40 0.92 0.82 0.62 0.40
Delta T21 201611222016112220161122
20
16 11 21 20 16 11 20 18 15 10
75 600 KW 1.27 1.29 1.33 1.37 1.36 1.39 1.43 1.47 1.44 1.47 1.52 1.57 1.51 1.55 1.59 1.65 1.58 1.61 1.66 1.71 1.63 1.66 1.72 1.77
AMPS 4.8 4.9 5.1 5.2 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 6.0 6.1 6.3 6.6 6.4 6.5 6.7 7.0 6.7 6.9 7.1 7.4
HI PR 137 147 156 162 154 166 175 182 175 188 199 207 199 214 226 236 224 241 255 266 248 266 281 293
LO PR 63 67 73 78 66 70 77 82 69 73 80 85 72 77 84 89 76 81 88 94 78 83 91 97
MBh 16.1 16.5 17.9 19.2 15.7 16.2 17.5 18.8 15.3 15.8 17.1 18.3 15.0 15.40 16.7 17.9 14.2 14.6 15.8 17.0 13.2 13.5 14.7 15.7
S/T 0.77 0.69 0.52 0.34 0.80 0.71 0.54 0.35 0.82 0.73 0.55 0.36 0.84 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.88 0.79 0.60 0.38
Delta T22 2016112220171122201711222017122220161120191511
525 KW 1.24 1.26 1.30 1.34 1.33 1.35 1.40 1.44 1.41 1.44 1.48 1.53 1.48 1.51 1.56 1.61 1.54 1.57 1.62 1.67 1.59 1.62 1.68 1.73
AMPS 4.7 4.8 4.9 5.1 5.0 5.1 5.3 5.5 5.5 5.6 5.8 6.0 5.8 6.0 6.2 6.4 6.2 6.3 6.5 6.8 6.5 6.7 6.9 7.2
HI PR 133 143 151 158 149 161 170 177 170 183 193 201 193 208 220 229 217 234 247 258 240 258 273 285
LO PR 61 65 71 75 64 68 75 79 67 71 78 83 70 75 81 87 73 78 85 91 76 81 88 94
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system powe
AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
