16
COOLING PERFORMANCE DATA
GSH130241A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSH13024-1A* / ARUF32-00*-1* / ARUF18241A*
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 22.5 23.4 25.6 - 22.0 22.8 25.0 - 21.5 22.3 24.4 - 21.0 21.7 23.8 - 19.9 20.6 22.6 - 18.4 19.1 21.0 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
Delta T 17 14 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
923 KW 1.64 1.67 1.72 - 1.76 1.79 1.85 - 1.86 1.90 1.96 - 1.96 2.00 2.06 - 2.04 2.08 2.15 - 2.10 2.15 2.22 -
AMPS 6.1 6.3 6.5 - 6.6 6.8 7.0 - 7.2 7.4 7.6 - 7.7 7.9 8.1 - 8.2 8.4 8.6 - 8.6 8.8 9.1 -
HI PR 137 148 156 - 154 166 175 - 175 189 199 - 200 215 227 - 224 242 255 - 248 267 282 -
LO PR 61 65 71 - 64 69 75 - 67 71 78 - 70 75 82 - 74 78 86 - 76 81 89 -
MBh 21.9 22.7 24.8 - 21.4 22.2 24.3 - 20.9 21.6 23.7 - 20.4 21.1 23.1 - 19.3 20.0 22.0 - 17.9 18.6 20.3 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -
Delta T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
70 820 KW 1.62 1.66 1.71 - 1.74 1.78 1.83 - 1.85 1.89 1.95 - 1.94 1.98 2.04 - 2.02 2.06 2.13 - 2.09 2.13 2.20 -
AMPS 6.1 6.2 6.4 - 6.6 6.7 6.9 - 7.1 7.3 7.5 - 7.6 7.8 8.0 - 8.1 8.3 8.6 - 8.6 8.8 9.1 -
HI PR 136 146 154 - 153 164 173 - 173 187 197 - 198 213 224 - 222 239 253 - 246 264 279 -
LO PR 60 64 70 - 64 68 74 - 66 71 77 - 70 74 81 - 73 78 85 - 75 80 88 -
MBh 20.2 20.9 22.9 - 19.7 20.4 22.4 - 19.3 20.0 21.9 - 18.8 19.5 21.3 - 17.8 18.5 20.3 - 16.5 17.1 18.8 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
Delta T 18 15 12 - 18 15 12 - 18 15 12 - 18 16 12 - 18 15 12 - 17 14 11 -
718 KW 1.59 1.62 1.67 - 1.70 1.74 1.79 - 1.80 1.84 1.90 - 1.89 1.93 2.00 - 1.97 2.01 2.08 - 2.04 2.08 2.15 -
AMPS 5.9 6.1 6.2 - 6.4 6.5 6.7 - 6.9 7.1 7.3 - 7.4 7.6 7.8 - 7.9 8.1 8.3 - 8.3 8.5 8.8 -
HI PR 132 142 150 - 148 159 168 - 168 181 191 - 192 206 218 - 216 232 245 - 238 256 271 -
LO PR 59 62 68 - 62 66 72 - 64 68 75 - 68 72 78 - 71 75 82 - 73 78 85 -
MBh 22.92 23.60 25.54 27.41 22.39 23.05 24.95 26.78 21.85 22.50 24.36 26.14 21.32 21.95 23.76 25.50 20.25 20.85 22.57 24.23 18.76 19.32 20.91 22.44
S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
Delta T19 181510201815102018151020181510191815101817149
923 KW 1.65 1.68 1.73 1.79 1.77 1.81 1.86 1.92 1.88 1.92 1.98 2.04 1.97 2.01 2.08 2.15 2.05 2.10 2.16 2.24 2.12 2.17 2.24 2.31
AMPS 6.2 6.3 6.5 6.8 6.7 6.8 7.1 7.3 7.2 7.4 7.7 7.9 7.7 7.9 8.2 8.5 8.2 8.4 8.7 9.0 8.7 8.9 9.2 9.6
HI PR 139 149 158 164 156 167 177 184 177 190 201 210 202 217 229 239 227 244 258 269 251 270 285 297
LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 74 79 86 92 77 82 89 95
MBh 22.3 22.9 24.8 26.6 21.7 22.4 24.2 26.0 21.2 21.8 23.6 25.4 20.7
21.3
23.1 24.8 19.7 20.2 21.9 23.5 18.2 18.8 20.3 21.8
S/T 0.80 0.72 0.54 0.35 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.37 0.88
0.79
0.60 0.38 0.92 0.82 0.62 0.40 0.92 0.83 0.63 0.40
Delta T20 181510201915112019151120
19
15 11 20 19 15 11 19 17 14 10
75 820 KW 1.64 1.67 1.72 1.77 1.76 1.79 1.85 1.91 1.86 1.90 1.96 2.02 1.96
2.00
2.06 2.13 2.04 2.08 2.15 2.22 2.10 2.15 2.22 2.29
AMPS 6.1 6.3 6.5 6.7 6.6 6.8 7.0 7.3 7.2 7.4 7.6 7.9 7.7
7.9
8.1 8.4 8.2 8.4 8.6 9.0 8.6 8.8 9.1 9.5
HI PR 137 148 156 163 154 166 175 183 175 189 199 208 200
215
227 237 225 242 255 266 248 267 282 294
LO PR 61 65 71 75 64 69 75 80 67 71 78 83 70
75
82 87 74 78 86 91 76 81 89 94
MBh 20.5 21.1 22.9 24.6 20.1 20.7 22.4 24.0 19.6 20.2 21.8 23.4 19.1 19.67 21.3 22.9 18.2 18.7 20.2 21.7 16.8 17.3 18.7 20.1
S/T 0.78 0.69 0.53 0.34 0.80 0.72 0.54 0.35 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.89 0.80 0.60 0.39
Delta T20 1915112119161121191611211916112119161119181410
718 KW 1.60 1.63 1.68 1.73 1.72 1.75 1.80 1.86 1.82 1.86 1.91 1.98 1.91 1.95 2.01 2.08 1.99 2.03 2.09 2.16 2.05 2.10 2.17 2.24
AMPS 6.0 6.1 6.3 6.5 6.4 6.6 6.8 7.1 7.0 7.2 7.4 7.7 7.5 7.6 7.9 8.2 7.9 8.1 8.4 8.7 8.4 8.6 8.9 9.2
HI PR 133 143 151 158 149 161 170 177 170 183 193 201 194 208 220 229 218 234 247 258 241 259 273 285
LO PR 59 63 69 73 63 67 73 77 65 69 75 80 68 73 79 84 72 76 83 88 74 79 86 92
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total s
stem powe
AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
