74
HEATING PERFORMANCE DATA
PERFORMANCE TEST
All data based upon listed indoor dry bulb temperature. .00 inches external static pressure on coil of outdoor section. Indoor
air cubic feet per minute (CFM) as listed in the Performance Data Sheets:
If conditions vary from this, results will change as follows:
1. As indoor dry bulb temperatures increase, a slight increase will occur in indoor air temperature drop (Delta T). Low and
high side pressures and power will not change.
2. As indoor CFM decreases, a slight increase will occur in indoor temperature drop (Delta T). A slight decrease will
occur in low and high side pressures and power.
A properly operating unit should be within plus or minus 2 degrees of the subcooling value shown in the Heat Pump
Specifications.
A properly operating unit should be within plus or minus 3 degrees of the typical (Delta T) value shown.
A properly operating unit should be within plus or minus 7 PSIG of the HI PR shown.
A properly operating unit should be within plus or minus 3 PSIG of the LO PR shown.
A properly operating unit should be within plus or minus 3 Amps of the typical value shown.
EXPANDED PERFORMANCE DATA
MODEL: VSH130481A* / AR*F486016B* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 54.1 51.2 48.2 45.0
43.0
41.7 38.7 35.7 33.6 31.1 28.6 27.0 26.0 23.3 20.7 18.0 15.4 12.6
Delta T31.329.627.926.124.924.122.420.719.518.016.515.615.013.512.010.4 8.9 7.3
KW 3.84 3.77 3.70 3.63
3.59
3.56 3.49 3.42 3.34 3.27 3.20 3.16 3.13 3.06 3.00 2.93 2.86 2.79
AMPS 18.1 16.8 15.7 14.8 14.3 14.0 13.2 12.5 12.0 11.5 10.9 10.7 10.5 10.0 9.3 8.8 8.1 7.3
COP 4.12 3.98 3.81 3.63 3.51 3.43 3.24 3.05 2.95 2.78 2.62 2.50 2.43 2.23 2.02 1.80 1.58 1.32
EER 14.1 13.6 13.0 12.4 12.0 11.7 11.1 10.4 10.1 9.5 8.9 8.5 8.3 7.6 6.9 6.2 5.4 4.5
HI PR 224 215 207 198 193 189 182 175 167 160 154 150 147 142 136 131 126 121
LO PR 74 69 64 59 56 54 49 44 40 35 31 29 28 24 20 17 15 12
EXPANDED PERFORMANCE DATA
MODEL: VSH130601A* / AR*F486016B* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 69.8 66.0 62.2 58.1
55.5
53.8 50.0 46.1 43.6 40.3 37.1 35.0 33.7 30.2 26.8 23.4 20.0 16.3
Delta T 35.9 34.0 32.0 29.9 28.5 27.7 25.7 23.7 22.4 20.7 19.1 18.0 17.3 15.6 13.8 12.0 10.3 8.4
KW 5.04 4.95 4.85 4.75
4.70
4.66 4.57 4.47 4.30 4.21 4.11 4.06 4.02 3.93 3.84 3.75 3.65 3.56
AMPS 22.7 21.0 19.6 18.4 17.8 17.4 16.4 15.6 14.9 14.2 13.5 13.2 13.0 12.4 11.5 10.8 10.0 9.0
COP 4.05 3.91 3.75 3.58 3.46 3.38 3.20 3.02 2.97 2.80 2.64 2.52 2.45 2.25 2.05 1.83 1.60 1.34
EER 13.8 13.4 12.8 12.2 11.8 11.5 10.9 10.3 10.1 9.6 9.0 8.6 8.4 7.7 7.0 6.2 5.5 4.6
HI PR 255 244 235 225 219 215 207 198 190 182 174 170 167 161 155 148 143 138
LO PR 75 70 65 60 57 54 50 45 40 36 32 29 28 24 21 17 15 12
