COOLING PERFORMANCE DATA
GSH130311A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSH130311A* / AWB36-XX / AWUF36XX1A*
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 26.5 27.4 30.0 - 25.8 26.8 29.3 - 25.2 26.1 28.6 - 24.6 25.5 28.0 - 23.4 24.2 26.6 - 21.7 22.4 24.6 -
S/T 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.83 0.69 0.48 - 0.85 0.71 0.49 - 0.89 0.74 0.51 - 0.89 0.75 0.52 -
Delta T 16 14 11 - 16 14 11 - 16 14 11 - 16 14 11 - 16 14 11 - 15 13 10 -
1173 KW 1.81 1.85 1.91 - 1.96 2.00 2.07 - 2.09 2.13 2.21 - 2.20 2.25 2.33 - 2.30 2.35 2.43 - 2.38 2.44 2.52 -
AMPS 8.0 8.1 8.4 - 8.6 8.8 9.0 - 9.3 9.5 9.8 - 9.9 10.1 10.4 - 10.5 10.7 11.0 - 11.0 11.3 11.7 -
HI PR 147 159 168 - 165 178 188 - 188 202 214 - 214 231 244 - 241 259 274 - 266 287 303 -
LO PR 61 65 71 - 65 69 75 - 67 72 78 - 71 75 82 - 74 79 86 - 77 82 89 -
MBh 26.1 27.0 29.6 - 25.5 26.4 28.9 - 24.9 25.8 28.2 - 24.2 25.1 27.5 - 23.0 23.9 26.2 - 21.3 22.1 24.2 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
70 1050 KW 1.80 1.84 1.90 - 1.95 1.99 2.06 - 2.07 2.12 2.19 - 2.19 2.24 2.31 - 2.28 2.34 2.42 - 2.37 2.42 2.51 -
AMPS 7.9 8.1 8.3 - 8.5 8.7 9.0 - 9.2 9.4 9.7 - 9.8 10.0 10.3 - 10.4 10.6 11.0 - 11.0 11.2 11.6 -
HI PR 146 158 166 - 164 177 187 - 187 201 212 - 213 229 242 - 239 258 272 - 265 285 301 -
LO PR 61 65 71 - 64 69 75 - 67 71 78 - 70 75 82 - 74 78 86 - 76 81 89 -
MBh 24.8 25.7 28.1 - 24.2 25.1 27.5 - 23.6 24.5 26.8 - 23.0 23.9 26.2 - 21.9 22.7 24.9 - 20.3 21.0 23.0 -
S/T 0.71 0.60 0.41 - 0.74 0.62 0.43 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.82 0.68 0.47 -
DT 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
927 KW 1.77 1.81 1.87 - 1.91 1.96 2.02 - 2.04 2.09 2.16 - 2.15 2.20 2.27 - 2.24 2.30 2.38 - 2.33 2.38 2.46 -
AMPS 7.8 8.0 8.2 - 8.4 8.6 8.8 - 9.0 9.3 9.5 - 9.6 9.8 10.2 - 10.2 10.4 10.8 - 10.8 11.0 11.4 -
HI PR 143 154 163 - 161 173 183 - 183 197 208 - 209 224 237 - 235 253 267 - 259 279 295 -
LO PR 60 64 69 - 63 67 73 - 66 70 76 - 69 73 80 - 72 77 84 - 75 80 87 -
MBh 26.9 27.7 30.0 32.2 26.3 27.1 29.3 31.4 25.7 26.4 28.6 30.7 25.0 25.8 27.9 29.9 23.8 24.5 26.5 28.4 22.0 22.7 24.5 26.3
S/T 0.88 0.79 0.60 0.38 0.92 0.82 0.62 0.40 0.94 0.84 0.64 0.41 0.97
0.87
0.66 0.42 1.00 0.90 0.68 0.44 1.00 0.91 0.69 0.44
Delta T19171410191714101917141019 18 14 10 19 17 14 10 17 16 13 9
1173 KW 1.83 1.87 1.93 1.99 1.97 2.02 2.09 2.16 2.11 2.15 2.23 2.30 2.22 2.27 2.35 2.43 2.32 2.37 2.45 2.54 2.40 2.46 2.54 2.63
AMPS 8.0 8.2 8.5 8.8 8.6 8.8 9.1 9.4 9.3 9.6 9.8 10.2 9.9 10.2 10.5 10.9 10.5 10.8 11.1 11.5 11.1 11.4 11.8 12.2
HI PR 149 160 169 177 167 180 190 198 190 205 216 225 216 233 246 257 244 262 277 289 269 290 306 319
LO PR 62 66 72 77 66 70 76 81 68 72 79 84 72 76 83 89 75 80 87 93 78 83 90 96
MBh 26.5 27.3 29.5 31.7 25.9 26.7 28.9 31.0 25.3 26.0 28.2 30.2 24.7 25.4 27.5 29.5 23.4 24.1 26.1 28.0 21.7 22.3 24.2 26.0
S/T 0.85 0.76 0.57 0.37 0.88 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
Delta T2018151020181510201815102018.5 15 10 20 18 15 10 18 17 14 10
75 1050 KW 1.82 1.86 1.92 1.98 1.96 2.01 2.07 2.15 2.09 2.14 2.21 2.29 2.21 2.26 2.34 2.42 2.30 2.36 2.44 2.52 2.39 2.44 2.53 2.62
AMPS 8.0 8.2 8.4 8.7 8.6 8.8 9.1 9.4 9.3 9.5 9.8 10.1 9.9
10.1
10.4 10.8 10.5 10.7 11.1 11.5 11.1 11.3 11.7 12.1
HI PR 148 159 168 175 166 179 189 197 189 203 215 224 215 231 244 255 242 260 275 287 267 288 304 317
LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 74 79 86 92 77 82 89 95
MBh 25.2 25.9 28.1 30.1 24.6 25.3 27.4 29.4 24.0 24.7 26.8 28.7 23.4 24.1 26.1 28.0 22.3 22.9 24.8 26.6 20.6 21.2 23.0 24.7
S/T 0.81 0.72 0.55 0.35 0.84 0.75 0.57 0.37 0.86 0.77 0.58 0.38 0.89
0.80
0.60 0.39 0.92 0.83 0.62 0.40 0.93 0.83 0.63 0.41
Delta T20191511201915112119151121 19 16 11 20 19 15 11 19 18 14 10
927 KW 1.79 1.83 1.89 1.95 1.93 1.97 2.04 2.11 2.06 2.10 2.17 2.25 2.17 2.22 2.29 2.37 2.26 2.32 2.40 2.48 2.35 2.40 2.48 2.57
AMPS 7.9 8.0 8.3 8.6 8.4 8.6 8.9 9.2 9.1 9.3 9.6 10.0 9.7 9.9 10.2 10.6 10.3 10.5 10.9 11.3 10.9 11.1 11.5 11.9
HI PR 145 156 165 172 163 175 185 193 185 199 210 219 211 227 239 250 237 255 269 281 262 282 298 310
LO PR 60 64 70 75 64 68 74 79 66 71 77 82 70 74 81 86 73 78 85 90 75 80 88 93
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
