22
High pressure is measured at the liquid service valve (the smaller valve). AMPS = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connection. KW = Total system power
Calculations are based on nominal CFM and 70 °F indoor dry bulb.
HEATING PERFORMANCE DATA
EXPANDED PERFORMANCE DATA
MODEL: ASH130601A* & ARUF061-00*-1* / ARUF48601A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 69.8 66.0 62.2 58.1 55.5 53.8 50.0 46.1 42.7 39.4 36.3 34.3 33.0 29.6 26.2 22.9 19.5 16.0
Delta T 36.6 34.7 32.7 30.5 29.2 28.2 26.2 24.2 22.4 20.7 19.1 18.0 17.3 15.5 13.8 12.0 10.3 8.4
KW 5.04 4.95 4.85 4.75 4.70 4.66 4.57 4.47 4.30 4.21 4.11 4.06 4.02 3.93 3.84 3.75 3.65 3.56
AMPS 22.7 21.0 19.6 18.4 17.8 17.4 16.4 15.6 14.9 14.2 13.5 13.2 13.0 12.4 11.5 10.8 10.0 9.0
COP 4.053.913.753.583.463.383.203.022.902.742.582.472.402.202.001.791.561.32
EER 13.8 13.4 12.8 12.2 11.8 11.5 10.9 10.3 9.9 9.4 8.8 8.4 8.2 7.5 6.8 6.1 5.3 4.5
HI PR 255 244 235 225 219 215 207 198 190 182 174 170 167 161 155 148 143 138
LO PR 75 70 65 60 57 54 50 45 40 36 32 29 28 24 21 17 15 12
