HEATING PERFORMANCE DATA
High pressure is measured at the suction service valve ( the larger valve). AMPS = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connection. KW = Total system power
Calculations are based on nominal CFM and 70 °F indoor dry bulb.
*Note: Shaded area is AHRI Rating Conditions at 47° outdoor ambient temperature
EXPANDED PERFORMANCE DATA
MODEL: VSH130301A* / AR*F303016B* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 33.7 31.9 30.0 28.1
26.8
26.0 24.1 22.2 17.4 16.1 14.8 14.0 13.5 12.1 10.7 9.4 8.0 6.5
Delta T29.728.126.524.723.622.921.319.615.414.213.112.311.910.7 9.5 8.2 7.0 5.8
KW 2.41 2.36 2.32 2.27
2.24
2.22 2.18 2.13 2.08 2.04 1.99 1.96 1.95 1.90 1.85 1.81 1.76 1.72
AMPS11.110.39.69.18.78.68.17.77.37.06.76.56.46.15.75.34.94.4
COP 4.09 3.95 3.79 3.62 3.50 3.42 3.24 3.05 2.45 2.31 2.18 2.09 2.03 1.86 1.69 1.51 1.32 1.11
EER 14.0 13.5 13.0 12.4 11.9 11.7 11.1 10.4 8.4 7.9 7.4 7.1 6.9 6.4 5.8 5.2 4.5 3.8
HI PR 234 224 216 206 202 198 190 182 175 167 160 156 154 148 142 136 131 127
LO PR 76 70 66 61 57 55 51 45 41 36 32 30 29 24 21 18 15 12
EXPANDED PERFORMANCE DATA
MODEL: VSH130311A* / AWUF36XX1A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 32.2 30.5 28.7 26.8
25.6
24.8 23.0 21.2 23.7 21.8 20.1 19.0 18.3 16.4 14.5 12.7 10.8 8.9
Delta T28.426.925.323.622.621.920.318.720.919.317.716.716.114.512.811.2 9.5 7.8
KW 2.55 2.49 2.44 2.39
2.36
2.33 2.28 2.23 2.00 1.95 1.90 1.87 1.86 1.81 1.76 1.71 1.66 1.62
AMPS 12.6 11.7 11.0 10.3 10.0 9.8 9.3 8.8 8.5 8.1 7.7 7.6 7.5 7.1 6.7 6.3 5.9 5.3
COP 3.70 3.58 3.44 3.29 3.18 3.11 2.96 2.79 3.47 3.28 3.09 2.97 2.89 2.66 2.42 2.17 1.90 1.61
EER 12.6 12.2 11.8 11.2 10.9 10.6 10.1 9.5 11.8 11.2 10.6 10.1 9.9 9.1 8.3 7.4 6.5 5.5
HI PR 254 243 234 224 218 214 206 198 189 181 174 170 166 160 154 148 142 137
LO PR 76 71 66 61 57 55 51 45 41 36 32 30 29 24 21 18 15 12
EXPANDED PERFORMANCE DATA
MODEL: VSH130361A* / AR*F364216B* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 40.2 38.1 35.8 33.5
32.0
31.0 28.8 26.6 19.9 18.4 16.9 16.0 15.4 13.8 12.3 10.7 9.1 7.5
Delta T29.227.726.024.323.222.520.919.314.513.412.311.611.210.0 8.9 7.8 6.6 5.4
KW 2.90 2.84 2.79 2.73
2.70
2.68 2.63 2.58 2.42 2.37 2.32 2.29 2.27 2.22 2.17 2.12 2.07 2.02
AMPS 13.0 12.1 11.3 10.7 10.3 10.1 9.5 9.1 8.7 8.3 7.9 7.7 7.6 7.3 6.8 6.4 5.9 5.4
COP 4.07 3.92 3.76 3.59 3.46 3.39 3.21 3.02 2.41 2.27 2.14 2.05 1.99 1.82 1.65 1.48 1.29 1.08
EER 13.9 13.4 12.9 12.3 11.8 11.6 11.0 10.3 8.2 7.8 7.3 7.0 6.8 6.2 5.7 5.0 4.4 3.7
HI PR 230 221 212 203 198 194 187 179 172 164 158 154 151 145 140 134 129 125
LO PR 80 74 70 64 60 58 54 48 43 38 34 31 30 26 22 19 16 13
EXPANDED PERFORMANCE DATA
MODEL: VSH130421A* / AR*F364216B* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 49.0 46.4 43.7 40.8
39.0
37.8 35.1 32.4 28.7 26.5 24.4 23.0 22.1 19.9 17.6 15.4 13.1 10.7
Delta T30.328.627.025.224.123.321.720.017.716.315.014.213.712.310.9 9.5 8.1 6.6
KW 3.59 3.52 3.46 3.39
3.35
3.32 3.26 3.19 3.08 3.01 2.95 2.91 2.88 2.82 2.75 2.69 2.62 2.56
AMPS 16.7 15.5 14.5 13.6 13.1 12.9 12.1 11.5 11.0 10.5 10.0 9.8 9.7 9.2 8.6 8.1 7.4 6.7
COP 4.00 3.86 3.70 3.53 3.41 3.33 3.15 2.97 2.72 2.57 2.42 2.31 2.25 2.06 1.87 1.67 1.46 1.23
EER 13.7 13.2 12.6 12.1 11.6 11.4 10.8 10.1 9.3 8.8 8.3 7.9 7.7 7.1 6.4 5.7 5.0 4.2
HI PR 237 227 218 209 204 200 192 184 177 169 162 158 155 149 144 138 133 128
LO PR 75 70 65 60 57 54 50 45 40 36 32 29 28 24 21 17 15 12
