EXPANDED PERFORMANCE DATA
MODEL: GSH130601A* / ARUF61-00*-1* / ARUF48601A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 69.8 66.0 62.2 58.1 55.5 53.8 50.0 46.1 43.6 40.3 37.1 35.0 33.7 30.2 26.8 23.4 20.0 16.3
Delta T 35.9 34.0 32.0 29.9 28.5 27.7 25.7 23.7 22.4 20.7 19.1 18.0 17.3 15.6 13.8 12.0 10.3 8.4
KW 5.04 4.95 4.85 4.75 4.70 4.66 4.57 4.47 4.30 4.21 4.11 4.06 4.02 3.93 3.84 3.75 3.65 3.56
AMPS 22.7 21.0 19.6 18.4 17.8 17.4 16.4 15.6 14.9 14.2 13.5 13.2 13.0 12.4 11.5 10.8 10.0 9.0
COP 4.053.913.753.583.463.383.203.022.972.802.642.522.452.252.051.831.601.34
EER 13.8 13.4 12.8 12.2 11.8 11.5 10.9 10.3 10.1 9.6 9.0 8.6 8.4 7.7 7.0 6.2 5.5 4.6
HI PR 255 244 235 225 219 215 207 198 190 182 174 170 167 161 155 148 143 138
LO PR 75 70 65 60 57 54 50 45 40 36 32 29 28 24 21 17 15 12
High pressure is measured at the suction service valve ( the larger valve). AMPS = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connection. KW = Total system power
Calculations are based on nominal CFM and 70 °F indoor dry bulb.
EXPANDED PERFORMANCE DATA
MODEL: GSH130363A* / ARUF49-00*-1* / ARUF36421A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 40.2 38.1 35.8 33.5
32.0
31.0 28.8 26.6 19.9 18.4 16.9 16.0 15.4 13.8 12.3 10.7 9.1 7.5
Delta T 29.2 27.7 26.0 24.3 23.2 22.5 20.9 19.3 14.5 13.4 12.3 11.6 11.2 10.0 8.9 7.8 6.6 5.4
KW 2.80 2.75 2.70 2.64 2.61 2.59 2.54 2.49 2.47 2.41 2.36 2.33 2.31 2.25 2.20 2.15 2.09 2.04
AMPS 11.0 10.2 9.6 9.1 8.7 8.6 8.1 7.7 7.4 7.1 6.8 6.6 6.5 6.2 5.8 5.5 5.1 4.7
COP 4.204.053.893.713.583.503.323.132.362.232.102.011.951.791.631.461.271.07
EER 14.4 13.9 13.3 12.7 12.2 12.0 11.3 10.7 8.1 7.6 7.2 6.9 6.7 6.1 5.6 5.0 4.4 3.7
HI PR 219 210 202 193 189 185 178 171 164 156 150 146 144 138 133 128 123 119
LO PR 78 72 67 62 58 56 52 46 42 37 33 30 29 25 21 18 16 12
HEATING PERFORMANCE DATA
*Note: Shaded area is AHRI Rating Conditions at 47° outdoor ambient temperature
EXPANDED PERFORMANCE DATA
MODEL: GSH130481A* / ARUF61-00*-1* / ARUF48601A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 54.1 51.2 48.2 45.0 43.0 41.7 38.7 35.7 33.6 31.1 28.6 27.0 26.0 23.3 20.7 18.0 15.4 12.6
Delta T 31.3 29.6 27.9 26.1 24.9 24.1 22.4 20.7 19.5 18.0 16.5 15.6 15.0 13.5 12.0 10.4 8.9 7.3
KW 3.84 3.77 3.70 3.63
3.59
3.56 3.49 3.42 3.34 3.27 3.20 3.16 3.13 3.06 3.00 2.93 2.86 2.79
AMPS 18.1 16.8 15.7 14.8 14.3 14.0 13.2 12.5 12.0 11.5 10.9 10.7 10.5 10.0 9.3 8.8 8.1 7.3
COP 4.123.983.813.633.513.433.243.052.952.782.622.502.432.232.021.801.581.32
EER 14.1 13.6 13.0 12.4 12.0 11.7 11.1 10.4 10.1 9.5 8.9 8.5 8.3 7.6 6.9 6.2 5.4 4.5
HI PR 224 215 207 198 193 189 182 175 167 160 154 150 147 142 136 131 126 121
LO PR 74 69 64 59 56 54 49 44 40 35 31 29 28 24 20 17 15 12
