COOLING PERFORMANCE DATA
ASH130301A*
EXPANDED PERFORMANCE DATA
MODEL: ASH130301A* & ARUF042-00*-1* / ARUF30301A* COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 27.4 28.4 31.2 - 26.8 27.8 30.4 - 26.2 27.1 29.7 - 25.5 26.5 29.0 - 24.2 25.1 27.5 - 22.5 23.3 25.5 -
S/T 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.86 0.72 0.50 -
DT 16 14 11 - 17 14 11 - 17 14 11 - 17 14 11 - 16 14 11 - 15 13 10 -
1165 KW 1.87 1.91 1.97 - 2.01 2.05 2.11 - 2.13 2.18 2.24 - 2.24 2.28 2.36 - 2.33 2.38 2.45 - 2.41 2.46 2.54 -
AMPS 7.0 7.1 7.4 - 7.5 7.7 8.0 - 8.2 8.4 8.6 - 8.7 8.9 9.2 - 9.3 9.5 9.8 - 9.9 10.1 10.4 -
HI PR 146 157 166 - 164 176 186 - 186 200 212 - 212 228 241 - 239 257 271 - 264 284 299 -
LO PR 63 67 74 - 67 71 78 - 70 74 81 - 73 78 85 - 77 81 89 - 79 84 92 -
MBh 26.6 27.6 30.3 - 26.0 27.0 29.5 - 25.4 26.3 28.8 - 24.8 25.7 28.1 - 23.5 24.4 26.7 - 21.8 22.6 24.8 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
DT 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
70 1036 KW 1.86 1.90 1.95 - 1.99 2.04 2.10 - 2.11 2.16 2.22 - 2.22 2.27 2.34 - 2.31 2.36 2.43 - 2.39 2.44 2.51 -
AMPS 6.9 7.1 7.3 - 7.5 7.6 7.9 - 8.1 8.3 8.6 - 8.7 8.9 9.2 - 9.2 9.4 9.8 - 9.8 10.0 10.3 -
HI PR 144 155 164 - 162 174 184 - 184 198 209 - 210 226 239 - 236 254 268 - 261 281 297 -
LO PR 63 67 73 - 66 70 77 - 69 73 80 - 72 77 84 - 76 81 88 - 78 83 91 -
MBh 24.6 25.5 27.9 - 24.0 24.9 27.3 - 23.4 24.3 26.6 - 22.9 23.7 26.0 - 21.7 22.5 24.7 - 20.1 20.9 22.9 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.80 0.66 0.46 -
DT 17 15 11 - 17 15 11 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
906 KW 1.82 1.85 1.91 - 1.95 1.99 2.05 - 2.06 2.11 2.17 - 2.17 2.21 2.28 - 2.25 2.30 2.37 - 2.33 2.38 2.45 -
AMPS 6.7 6.9 7.1 - 7.2 7.4 7.7 - 7.9 8.1 8.3 - 8.4 8.6 8.9 - 9.0 9.2 9.5 - 9.5 9.7 10.0 -
HI PR 140 151 159 - 157 169 179 - 179 192 203 - 204 219 231 - 229 247 260 - 253 272 288 -
LO PR 61 65 71 - 64 68 75 - 67 71 78 - 70 75 81 - 74 78 85 - 76 81 88 -
MBh 27.9 28.7 31.1 33.4 27.3 28.1 30.4 32.6 26.6 27.4 29.6 31.8 26.0 26.7 28.9 31.0 24.7 25.4 27.5 29.5 22.8 23.5 25.5 27.3
S/T 0.86 0.77 0.58 0.37 0.89 0.79 0.60 0.39 0.91 0.81 0.62 0.40 0.94 0.84 0.64 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.67 0.43
DT 19 17 14 10 19 18 14 10 19 18 14 10 19 18 15 10 19 17 14 10 18 16 13 9
1165 KW 1.89 1.93 1.98 2.04 2.03 2.07 2.13 2.20 2.15 2.19 2.26 2.33 2.25 2.30 2.38 2.45 2.35 2.40 2.47 2.55 2.42 2.48 2.56 2.64
AMPS 7.0 7.2 7.4 7.7 7.6 7.8 8.0 8.3 8.2 8.4 8.7 9.1 8.8 9.0 9.3 9.7 9.4 9.6 9.9 10.3 9.9 10.2 10.5 10.9
HI PR 147 159 167 175 165 178 188 196 188 202 214 223 214 230 243 254 241 259 274 286 266 286 303 316
LO PR 64 68 74 79 68 72 79 84 70 75 82 87 74 79 86 91 77 82 90 96 80 85 93 99
MBh 27.1 27.9 30.2 32.4 26.5 27.2 29.5 31.6 25.8 26.6 28.8 30.9 25.2
25.9
28.1 30.1 23.9 24.6 26.7 28.6 22.2 22.8 24.7 26.5
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
DT 20 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 18 17 14 10
75 1036 KW 1.87 1.91 1.97 2.03 2.01 2.05 2.11 2.18 2.13 2.18 2.24 2.31 2.24 2.28 2.36 2.43 2.33 2.38 2.45 2.53 2.41 2.46 2.54 2.62
AMPS 7.0 7.1 7.4 7.6 7.5 7.7 8.0 8.3 8.2 8.4 8.6 9.0 8.7 8.9 9.2 9.6 9.3 9.5 9.8 10.2 9.9 10.1 10.4 10.8
HI PR 146 157 166 173 164 176 186 194 186 200 212 221 212
228
241 251 239 257 271 283 264 284 300 312
LO PR 63 67 74 78 67 71 78 83 70 74 81 86 73
78
85 90 77 81 89 95 79 84 92 98
MBh 25.0 25.7 27.9 29.9 24.4 25.1 27.2 29.2 23.8 24.5 26.6 28.5 23.3 23.95 25.9 27.8 22.1 22.8 24.6 26.4 20.5 21.1 22.8 24.5
S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39
DT 20 18 15 10 20 19 15 11 20 19 15 11 20 19 15 11 20 19 15 10 19 17 14 10
906 KW 1.83 1.87 1.92 1.98 1.96 2.00 2.06 2.13 2.08 2.12 2.19 2.26 2.18 2.23 2.30 2.37 2.27 2.32 2.39 2.47 2.35 2.40 2.47 2.55
AMPS 6.8 6.9 7.2 7.4 7.3 7.5 7.7 8.0 7.9 8.1 8.4 8.7 8.5 8.7 9.0 9.3 9.0 9.3 9.6 9.9 9.6 9.8 10.1 10.5
HI PR 142 152 161 168 159 171 180 188 181 194 205 214 206 221 234 244 231 249 263 274 256 275 291 303
LO PR 61 65 71 76 65 69 75 80 67 72 78 83 71 75 82 88 74 79 86 92 77 82 89 95
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
