COOLING PERFORMANCE DATA
ASH130301A*
EXPANDED PERFORMANCE DATA
MODEL: ASH130301A* & ARUF042-00*-1* / ARUF30301A* COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB
Airflow 5963677159636771596367715963 67715963677159636771
MBh 28.4 29.0 31.0 33.1 27.7 28.3 30.3 32.4 27.1 27.7 29.6 31.6 26.4 27.0 28.8 30.8 25.1 25.6 27.4 29.3 23.2 23.8 25.4 27.1
S/T 0.94 0.88 0.72 0.54 1.00 0.91 0.74 0.56 1.00 0.94 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.82 0.62
DT 21 20 18 14 22 20 18 14 21 20 18 14 21 21 18 14 20 20 18 14 18 19 16 13
1165 KW 1.90 1.94 2.00 2.06 2.04 2.08 2.15 2.21 2.16 2.21 2.28 2.35 2.27 2.32 2.39 2.47 2.37 2.42 2.49 2.57 2.44 2.50 2.58 2.66
AMPS 7.1 7.3 7.5 7.8 7.7 7.8 8.1 8.4 8.3 8.5 8.8 9.1 8.9 9.1 9.4 9.8 9.5 9.7 10.0 10.4 10.0 10.3 10.6 11.0
HI PR 149 160 169 176 167 180 190 198 190 204 216 225 216 233 246 256 243 262 277 288 269 289 306 319
LO PR 65 69 75 80 68 73 79 84 71 76 82 88 75 79 87 92 78 83 91 97 81 86 94 100
MBh 27.6 28.2 30.1 32.2 26.9 27.5 29.4 31.4 26.3 26.9 28.7 30.7 25.6 26.2
28.0
29.9 24.4 24.9 26.6 28.4 22.6 23.1 24.6 26.3
S/T 0.90 0.84 0.68 0.51 0.93 0.87 0.71 0.53 0.95 0.89 0.73 0.54 0.98 0.92
0.75
0.56 1.00 0.96 0.78 0.58 1.00 0.96 0.78 0.59
DT 22 21 18 15 22 21 18 15 22 21 19 15 22 21 19 15 22 21 18 15 20 20 17 14
80 1036 KW 1.89 1.93 1.98 2.04 2.03 2.07 2.13 2.20 2.15 2.19 2.26 2.33 2.26 2.30 2.38 2.45 2.35 2.40 2.47 2.55 2.43 2.48 2.56 2.64
AMPS 7.0 7.2 7.4 7.7 7.6 7.8 8.0 8.3 8.2 8.4 8.7 9.1 8.8 9.0 9.3 9.7 9.4 9.6 9.9 10.3 9.9 10.2 10.5 10.9
HI PR 147 159 167 175 165 178 188 196 188 202 214 223 214 231 243 254 241 259 274 286 266 287 303 316
LO PR 64 68 74 79 68 72 79 84 70 75 82 87 74 79 8
91 77 82 90 96 80 85 93 99
MBh 25.4 26.0 27.8 29.7 24.9 25.4 27.1 29.0 24.3 24.8 26.5 28.3 23.7 24.2 25.8 27.6 22.5 23.0 24.6 26.2 20.8 21.3 22.7 24.3
S/T 0.86 0.81 0.66 0.49 0.90 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.76 0.57
DT 22 21 19 15 23 22 19 15 23 22 19 15 23 22 19 15 22 22 19 15 21 20 17 14
906 KW 1.85 1.88 1.94 2.00 1.98 2.02 2.08 2.15 2.10 2.14 2.21 2.28 2.20 2.25 2.32 2.39 2.29 2.34 2.41 2.49 2.37 2.42 2.49 2.58
AMPS 6.8 7.0 7.2 7.5 7.4 7.6 7.8 8.1 8.0 8.2 8.5 8.8 8.6 8.8 9.1 9.4 9.1 9.3 9.7 10.0 9.7 9.9 10.2 10.6
HI PR 143 154 162 169 160 173 182 190 182 196 207 216 208 224 236 246 234 252 266 277 258 278 293 306
LO PR 62 66 72 77 66 70 76 81 68 73 79 84 72 76 83 89 75 80 87 93 78 83 90 96
MBh 28.9 29.5 30.8 32.9 28.2 28.8 30.1 32.1 27.6 28.1 29.4 31.4 26.9 27.4 28.7 30.6 25.5 26.0 27.3 29.1 23.7 24.1 25.3 26.9
S/T 0.98 0.95 0.86 0.70 1.00 0.98 0.89 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.98 0.79 1.00 1.00 0.98 0.80
DT 22 22 21 18 22 22 21 18 22 22 21 18 21 22 21 18 20 21 21 18 19 19 20 17
1165 KW 1.92 1.96 2.01 2.08 2.06 2.10 2.16 2.23 2.18 2.23 2.30 2.37 2.29 2.34 2.41 2.49 2.38 2.44 2.51 2.60 2.46 2.52 2.60 2.68
AMPS 7.1 7.3 7.6 7.8 7.7 7.9 8.2 8.5 8.4 8.6 8.9 9.2 9.0 9.2 9.5 9.9 9.6 9.8 10.1 10.5 10.1 10.4 10.7 11.1
HI PR 150 162 171 178 169 182 192 200 192 206 218 227 219 235 248 259 246 265 279 291 272 292 309 322
LO PR 65 69 76 81 69 73 80 85 72 76 83 89 75 80 87 93 79 84 92 98 82 87 95 101
MBh 28.1 28.6 29.9 32.0 27.4 27.9 29.3 31.2 26.7 27.3 28.6 30.5 26.1 26.6 27.9 29.7 24.8 25.3 26.5 28.2 23.0 23.4 24.5 26.2
S/T 0.94 0.91 0.82 0.66 0.97 0.94 0.85 0.69 1.00 0.96 0.87 0.71 1.00 0.99 0.90 0.73 1.00 1.00 0.93 0.76 1.00 1.00 0.94 0.76
DT 23 23 22 19 24 23 22 19 24 23 22 19 23 23 22 19 22 22 22 19 20 21 20 18
85 1036 KW 1.90 1.94 2.00 2.06 2.04 2.08 2.15 2.21 2.16 2.21 2.28 2.35 2.27 2.32 2.39 2.47 2.37 2.42 2.49 2.57 2.44 2.50 2.58 2.66
AMPS 7.1 7.3 7.5 7.8 7.7 7.8 8.1 8.4 8.3 8.5 8.8 9.1 8.9 9.1 9.4 9.8 9.5 9.7 10.0 10.4 10.0 10.3 10.6 11.0
HI PR 149 160 169 176 167 180 190 198 190 204 216 225 216 233 246 256 243 262 277 288 269 289 306 319
LO PR 65 69 75 80 68 73 79 84 71 76 82 88 75 79 87 92 78 83 91 97 81 86 94 100
MBh 25.9 26.4 27.6 29.5 25.3 25.8 27.0 28.8 24.7 25.2 26.4 28.1 24.1 24.6 25.7 27.4 22.9 23.3 24.4 26.1 21.2 21.6 22.6 24.1
S/T 0.91 0.87 0.79 0.64 0.94 0.91 0.82 0.66 0.96 0.93 0.84 0.68 0.99 0.96 0.86 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.91 0.73
DT 24 23 22 19 24 24 22 19 24 24 22 19 24 24 23 20 23 24 22 19 22 22 21 18
906 KW 1.86 1.90 1.95 2.01 1.99 2.04 2.10 2.16 2.11 2.16 2.22 2.29 2.22 2.27 2.34 2.41 2.31 2.36 2.43 2.51 2.39 2.44 2.51 2.60
AMPS 6.9 7.1 7.3 7.6 7.4 7.6 7.9 8.2 8.1 8.3 8.6 8.9 8.7 8.9 9.2 9.5 9.2 9.4 9.8 10.1 9.8 10.0 10.3 10.7
HI PR 144 155 164 171 162 174 184 192 184 198 209 218 210 226 238 249 236 254 268 280 261 281 296 309
LO PR 63 67 73 78 66 70 77 82 69 73 80 85 72 77 84 89 76 81 88 94 78 83 91 97
Shaded area is ARI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
