18
COOLING PERFORMANCE DATA
GSH130241B*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSH130241B* / AR*F182416** Design Subcooling 9 ±3 °F @ the liquid service valve, AHRI 95 test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 22.5 23.4 25.6 - 22.0 22.8 25.0 - 21.5 22.3 24.4 - 21.0 21.7 23.8 - 19.9 20.6 22.6 - 18.4 19.1 21.0 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.81 0.68 0.47 - 0.85 0.71 0.49 - 0.85 0.71 0.49 -
Delta T 16 14 11 - 16 14 11 - 16 14 11 - 16 14 11 - 16 14 11 - 15 13 10 -
956 KW 1.59 1.63 1.68 - 1.71 1.75 1.80 - 1.81 1.85 1.91 - 1.91 1.95 2.01 - 1.98 2.03 2.09 - 2.05 2.09 2.16 -
AMPS 5.8 6.0 6.2 - 6.3 6.4 6.7 - 6.8 7.0 7.2 - 7.3 7.5 7.7 - 7.8 8.0 8.2 - 8.2 8.4 8.7 -
HI PR 140 151 159 - 157 169 179 - 179 193 203 - 204 219 232 - 229 247 261 - 253 273 288 -
LO PR 62 66 72 - 65 69 76 - 68 72 79 - 71 76 83 - 75 79 87 - 77 82 90 -
MBh 21.9 22.7 24.8 - 21.4 22.2 24.3 - 20.9 21.6 23.7 - 20.4 21.1 23.1 - 19.3 20.0 22.0 - 17.9 18.6 20.3 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.81 0.67 0.47 - 0.81 0.68 0.47 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
70 850 KW 1.58 1.61 1.66 - 1.70 1.73 1.79 - 1.80 1.84 1.90 - 1.89 1.93 1.99 - 1.97 2.01 2.07 - 2.03 2.08 2.14 -
AMPS 5.8 5.9 6.1 - 6.2 6.4 6.6 - 6.8 6.9 7.2 - 7.2 7.4 7.7 - 7.7 7.9 8.1 - 8.2 8.4 8.6 -
HI PR 139 149 158 - 156 168 177 - 177 191 201 - 202 217 229 - 227 244 258 - 251 270 285 -
LO PR 61 65 71 - 65 69 75 - 67 71 78 - 70 75 82 - 74 79 86 - 76 81 89 -
MBh 20.2 20.9 22.9 - 19.7 20.4 22.4 - 19.3 20.0 21.9 - 18.8 19.5 21.3 - 17.8 18.5 20.3 - 16.5 17.1 18.8 -
S/T 0.68 0.57 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.78 0.65 0.45 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 11 -
744 KW 1.55 1.58 1.62 - 1.66 1.69 1.74 - 1.76 1.79 1.85 - 1.85 1.88 1.94 - 1.92 1.96 2.02 - 1.98 2.03 2.09 -
AMPS 5.6 5.7 5.9 - 6.1 6.2 6.4 - 6.6 6.7 7.0 - 7.0 7.2 7.4 - 7.5 7.7 7.9 - 7.9 8.1 8.4 -
HI PR 135 145 153 - 151 163 172 - 172 185 195 - 196 211 222 - 220 237 250 - 243 262 276 -
LO PR 59 63 69 - 63 67 73 - 65 69 76 - 68 73 79 - 72 76 83 - 74 79 86 -
MBh 22.92 23.60 25.54 27.41 22.39 23.05 24.95 26.78 21.85 22.50 24.36 26.14 21.32 21.95 23.76 25.50 20.25 20.85 22.57 24.23 18.76 19.32 20.91 22.44
S/T 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.40 0.96 0.86 0.65 0.42 0.97 0.87 0.66 0.42
Delta T19 17141019171410191714101917 1410191714101716139
956 KW 1.61 1.64 1.69 1.74 1.72 1.76 1.81 1.87 1.83 1.87 1.93 1.99 1.92 1.96 2.02 2.09 2.00 2.04 2.11 2.18 2.07 2.11 2.18 2.25
AMPS 5.9 6.0 6.2 6.4 6.3 6.5 6.7 7.0 6.9 7.1 7.3 7.6 7.4 7.5 7.8 8.1 7.8 8.0 8.3 8.6 8.3 8.5 8.8 9.1
HI PR 142 152 161 168 159 171 181 188 181 195 205 214 206 222 234 244 232 249 263 275 256 275 291 303
LO PR 62 66 72 77 66 70 76 81 68 73 79 85 72 76 83 89 75 80 87 93 78 83 91 96
MBh 22.3 22.9 24.8 26.6 21.7 22.4 24.2 26.0 21.2 21.8 23.6 25.4 20.7
21.3
23.1 24.8 19.7 20.2 21.9 23.5 18.2 18.8 20.3 21.8
S/T 0.80 0.72 0.54 0.35 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.37 0.88
0.79
0.60 0.38 0.92 0.82 0.62 0.40 0.92 0.83 0.63 0.40
Delta T19 181510201815102018151020
18
15 10 19 18 15 10 18 17 14 9
75 850 KW 1.60 1.63 1.68 1.73 1.71 1.75 1.80 1.86 1.81 1.85 1.91 1.97 1.91
1.95
2.01 2.07 1.98 2.03 2.09 2.16 2.05 2.09 2.16 2.23
AMPS 5.8 6.0 6.2 6.4 6.3 6.4 6.7 6.9 6.8 7.0 7.2 7.5 7.3
7.5
7.7 8.0 7.8 8.0 8.2 8.5 8.2 8.4 8.7 9.1
HI PR 140 151 159 166 157 169 179 187 179 193 203 212 204
219
232 242 229 247 261 272 253 273 288 300
LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71
76
83 88 75 79 87 92 77 82 90 95
MBh 20.5 21.1 22.9 24.6 20.1 20.7 22.4 24.0 19.6 20.2 21.8 23.4 19.1 19.67 21.3 22.9 18.2 18.7 20.2 21.7 16.8 17.3 18.7 20.1
S/T 0.78 0.69 0.53 0.34 0.80 0.72 0.54 0.35 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.89 0.80 0.60 0.39
Delta T20 18151020181510201815102019 15102018151019171410
744 KW 1.56 1.59 1.64 1.69 1.67 1.71 1.76 1.81 1.77 1.81 1.86 1.92 1.86 1.90 1.96 2.02 1.94 1.98 2.04 2.11 2.00 2.04 2.11 2.18
AMPS 5.7 5.8 6.0 6.2 6.1 6.3 6.5 6.7 6.6 6.8 7.0 7.3 7.1 7.3 7.5 7.8 7.6 7.7 8.0 8.3 8.0 8.2 8.5 8.8
HI PR 136 146 155 161 153 164 173 181 174 187 197 206 198 213 225 234 222 239 253 264 246 265 279 291
LO PR 60 64 70 74 63 67 73 78 66 70 76 81 69 73 80 85 72 77 84 89 75 80 87 93
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan )
High and low pressures are measured at the l iquid and suction service val ves.
