9
High pressure is measured at the suction service valve ( the larger valve). AMPS = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connection. KW = Total system power
Calculations are based on nominal CFM and 70 °F indoor dry bulb.
HEATING PERFORMANCE DATA
*Note: Shaded area is AHRI Rating Conditions at 47° outdoor ambient temperature
PERFORMANCE TEST
All data based upon listed indoor dry bulb temperature. .00 inches exter-
nal static pressure on coil of outdoor section. Indoor air cubic feet per
minute (CFM) as listed in the Performance Data Sheets:
If conditions vary from this, results will change as follows:
1. As indoor dry bulb temperatures increase, a slight increase will
occur in indoor air temperature drop (Delta T). Low and high side
pressures and power will not change.
2. As indoor CFM decreases, a slight increase will occur in indoor
temperature drop (Delta T). A slight decrease will occur in low and
high side pressures and power.
A properly operating unit should be within plus or minus 2 degrees of
the subcooling value shown in the Heat Pump Specifications.
A properly operating unit should be within plus or minus 3 degrees of
the typical (Delta T) value shown.
A properly operating unit should be within plus or minus 7 PSIG of the HI
PR shown.
A properly operating unit should be within plus or minus 3 PSIG of the LO
PR shown.
A properly operating unit should be within plus or minus 3 Amps of the
typical value shown.
GSH101203AC
EXPANDED PERFORMANCE DATA
MODEL: GSH101203AC / AR120 HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 125700.0 119000.0 112000.0 104700.0
100000.0
96900.0 90000.0 83000.0 74.8 69.0 63.5 60.0 57.8 51.8 46.0 40.1 34.2 28.0
Delta T 34506.0 32666.8 30745.2 28741.3 27451.1 26600.1 24706.0 22784.4 20.5 18.9 17.4 16.5 15.9 14.2 12.6 11.0 9.4 7.7
KW 9.58 9.40 9.21 9.03 8.93 8.85 8.67 8.49 9.48 9.26 9.05 8.93 8.84 8.62 8.41 8.20 7.98 7.77
AMPS 33.3 31.0 2 9.1 27.4 26.5 26.0 24.6 23 .4 22.5 21.6 20.6 20.2 19.9 19.0 17.8 16.9 15.7 14.3
COP 3840.54 3706.53 3 557.68 3393.08 32 79.04 3205.15 3037.22 2861.2 8 2.31 2.18 2.05 1.97 1.91 1.76 1.60 1.43 1.25 1.06
EER 13123.1 12665.2 12156.6 11594.2 11 204.5 10952.0 10378.2 9777.0 7.9 7.4 7.0 6.7 6.5 6.0 5.5 4.9 4.3 3.6
HI PR 189 182 175 167 163 160 1 54 1 48 141 135 130 126 1 24 1 19 115 110 106 1 03
LO PR 67 62 58 53 50 48 45 40 36 32 28 26 25 21 18 15 14 11
