HEAT PUMP SPECIFICATIONS ASH130[18-60]*A*
(1)
Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes.
(2)
Maximum Overcurrent Protection Device: MUST use Time Delay Fuse or HACR type Circuit Breaker of the same size as noted.
ASH130[18-60]1A*
ASH130181A* ASH130241A* ASH130301A* ASH130361A* ASH130421A* ASH130481A* ASH130601A*
Cooling Capacity, BTUH 18,000 23,600 28,000 35,000 40,000 45,000 55,500
Compressor
R.L. Amps 9.0 10.9 12.2 13.4 16.5 17.9 25.0
L.R. Amps 41 54 63 73 95 104 148
Loss of Charge Pressure Switch
Open / Close 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG 7 PSIG/25 PSIG
Condenser Fan Motor
Horsepower 1/6 1/6 1/6 1/4 1/4 1/4 1/6
F.L. Amps 0.9 0.9 0.9 1.5 1.5 1.5 1.1
Liquid Line, Inches O.D. 3/8" 3/8" 3/8" 3/8" 3/8" 3/8" 3/8"
Suction Line, Inches O.D. 3/4" 3/4" 3/4" 7/8" 7/8" 7/8" 7/8"
Refrigerant Charge 115 117 153 188 213 223 233
Design Subcooling Cooling (°F) 9 +
39 + 39 + 39 + 39 + 39 + 39 + 3
Power Supply 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity
(1)
12.1 14.5 16.1 18.3 22.2 23.9 32.3
Maximum Overcurrent Device
(2)
20 20 20 30 30 40 50
Electrical Conduit Size
Power Supply (Inches) 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4 1/2 or 3/4
Approximate Shipping Weight 193 193 199 207 219 225 266
Unit specifications are subject to change without notice. ALWAYS refer to the units serial plate for the most up-to-date general and electrical information.
NOTE: This data is provided as a guide, it is important to electrically connect the unit and properly size fuses/circuit breakers and wires in
accordance with all national and/or local electrical codes. Use copper wire only.
