COOLING PERFORMANCE DATA
ASH130361A*
EXPANDED PERFORMANCE DATA
MODEL: ASH130361A* & ARUF049-00*-1* / ARUF36421A* COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 6
3
67 71 59 6
3
67 71 59 6
3
67 71 59 6
3
67 71 59 63 67 71 59 6
3
67 71
MBh 34.3 35.5 38.9 - 33.5 34.7 38.0 - 32.7 33.9 37.1 - 31.9 33.1 36.2 - 30.3 31.4 34.4 - 28.1 29.1 31.9 -
S/T 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.87 0.73 0.50 -
DT 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 10 -
1418 KW 2.38 2.43 2.50 - 2.56 2.61 2.69 - 2.71 2.77 2.86 - 2.85 2.91 3.01 - 2.97 3.04 3.13 - 3.07 3.14 3.24 -
AMPS 9.2 9.4 9.7 - 9.9 10.2 10.5 - 10.8 11.0 11.4 - 11.5 11.8 12.1 - 12.2 12.5 12.9 - 12.9 13.2 13.7 -
HI PR 142 153 162 - 160 172 182 - 182 196 206 - 207 223 235 - 233 251 265 - 257 277 292 -
LO PR 65 69 76 - 69 73 80 - 72 76 83 - 75 80 88 - 79 84 92 - 82 87 95 -
MBh 33.3 34.5 37.8 - 32.5 33.7 36.9 - 31.7 32.9 36.1 - 31.0 32.1 35.2 - 29.4 30.5 33.4 - 27.3 28.3 31.0 -
S/T 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
DT 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 18 15 12 - 16 14 11 -
70 1260 KW 2.36 2.41 2.48 - 2.54 2.59 2.67 - 2.69 2.75 2.84 - 2.83 2.89 2.98 - 2.95 3.01 3.11 - 3.05 3.11 3.22 -
AMPS 9.1 9.3 9.6 - 9.8 10.1 10.4 - 10.7 10.9 11.3 - 11.4 11.7 12.0 - 12.1 12.4 12.8 - 12.8 13.1 13.6 -
HI PR 141 152 160 - 158 170 180 - 180 194 204 - 205 220 233 - 230 248 262 - 255 274 289 -
LO PR 65 69 75 - 68 73 79 - 71 76 82 - 75 79 87 - 78 83 91 - 81 86 94 -
MBh 30.7 31.9 34.9 - 30.0 31.1 34.1 - 29.3 30.4 33.3 - 28.6 29.6 32.5 - 27.2 28.2 30.8 - 25.2 26.1 28.6 -
S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
DT 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 14 11 -
1103 KW 2.31 2.35 2.42 - 2.48 2.53 2.61 - 2.63 2.68 2.77 - 2.76 2.82 2.91 - 2.87 2.94 3.03 - 2.97 3.04 3.14 -
AMPS 8.9 9.1 9.4 - 9.6 9.8 10.1 - 10.4 10.6 11.0 - 11.1 11.3 11.7 - 11.8 12.1 12.4 - 12.5 12.8 13.2 -
HI PR 137 147 155 - 153 165 174 - 174 188 198 - 199 214 226 - 224 241 254 - 247 266 281 -
LO PR 63 67 73 - 66 71 77 - 69 73 80 - 72 77 84 - 76 81 88 - 78 83 91 -
MBh 34.9 35.9 38.9 41.7 34.1 35.1 38.0 40.7 33.3 34.2 37.1 39.8 32.4 33.4 36.2 38.8 30.8 31.7 34.4 36.9 28.6 29.4 31.8 34.2
S/T 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.91 0.82 0.62 0.40 0.94 0.84 0.64 0.41 0.98 0.88 0.66 0.43 0.99 0.88 0.67 0.43
DT 19 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 20 18 15 10 18 17 14 10
1418 KW 2.40 2.45 2.52 2.60 2.58 2.63 2.71 2.80 2.74 2.79 2.88 2.98 2.88 2.94 3.03 3.13 3.00 3.06 3.16 3.27 3.10 3.17 3.27 3.38
AMPS 9.3 9.5 9.8 10.2 10.0 10.2 10.6 11.0 10.9 11.1 11.5 11.9 11.6 11.9 12.3 12.7 12.3 12.6 13.0 13.5 13.0 13.4 13.8 14.3
HI PR 144 155 163 170 161 174 183 191 184 198 209 218 209 225 238 248 235 253 267 279 260 280 295 308
LO PR 66 70 77 82 70 74 81 86 72 77 84 90 76 81 88 94 80 85 93 99 83 88 96 102
MBh 33.9 34.9 37.7 40.5 33.1 34.1 36.9 39.6 32.3 33.2 36.0 38.6 31.5
32.4
35.1 37.7 29.9 30.8 33.3 35.8 27.7 28.5 30.9 33.2
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.41 0.94 0.84 0.64 0.41
DT 20 19 15 11 21 19 15 11 21 19 15 11 21 19 16 11 20 19 15 11 19 18 14 10
75 1260 KW 2.38 2.43 2.50 2.58 2.56 2.61 2.69 2.78 2.71 2.77 2.86 2.95 2.85 2.91 3.01 3.11 2.97 3.04 3.13 3.24 3.07 3.14 3.24 3.35
AMPS 9.2 9.4 9.7 10.1 9.9 10.2 10.5 10.9 10.8 11.0 11.4 11.8 11.5 11.8 12.1 12.6 12.2 12.5 12.9 13.4 12.9 13.2 13.7 14.2
HI PR 142 153 162 169 160 172 182 189 182 196 207 215 207 223 235 245 233 251 265 276 257 277 292 305
LO PR 65 70 76 81 69 73 80 85 72 76 83 89 75 80 88 93 79 84 92 98 82 87 95 101
MBh 31.3 32.2 34.8 37.4 30.5 31.4 34.0 36.5 29.8 30.7 33.2 35.6 29.1 29.94 32.4 34.8 27.6 28.4 30.8 33.0 25.6 26.3 28.5 30.6
S/T 0.79 0.71 0.54 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.91 0.81 0.61 0.40
DT 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 21 19 16 11 19 18 15 10
1103 KW 2.32 2.37 2.44 2.52 2.50 2.55 2.63 2.71 2.65 2.71 2.79 2.88 2.78 2.84 2.93 3.03 2.90 2.96 3.06 3.16 3.00 3.06 3.16 3.27
AMPS 9.0 9.2 9.5 9.8 9.7 9.9 10.2 10.6 10.5 10.7 11.1 11.5 11.2 11.4 11.8 12.3 11.9 12.2 12.6 13.0 12.6 12.9 13.3 13.8
HI PR 138 149 157 164 155 167 176 184 176 190 200 209 201 216 228 238 226 243 257 268 250 269 284 296
LO PR 63 67 74 78 67 71 78 83 70 74 81 86 73 78 85 90 77 81 89 95 79 84 92 98
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.
