COOLING PERFORMANCE DATA
ASH130361A*
EXPANDED PERFORMANCE DATA
MODEL: ASH130361A* & ARUF049-00*-1* / ARUF36421A* COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB* Airflo
w
59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 35.5 36.3 38.8 41.4 34.7 35.4 37.9 40.5 33.8 34.6 37.0 39.5 33.0 33.7 36.1 38.5 31.4 32.1 34.2 36.6 29.1 29.7 31.7 33.9
S/T 0.94 0.88 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.94 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.83 0.62
DT 22 21 18 14 22 21 18 15 22 21 18 15 21 21 18 15 20 21 18 15 19 19 17 14
1418 KW 2.42 2.47 2.54 2.62 2.60 2.65 2.74 2.82 2.76 2.82 2.91 3.00 2.90 2.96 3.06 3.16 3.02 3.09 3.19 3.29 3.12 3.19 3.30 3.41
AMPS 9.4 9.6 9.9 10.2 10.1 10.3 10.7 11.1 11.0 11.2 11.6 12.0 11.7 12.0 12.4 12.8 12.4 12.7 13.2 13.6 13.2 13.5 13.9 14.5
HI PR 145 156 165 172 163 175 185 193 185 200 211 220 211 227 240 250 238 256 270 282 262 282 298 311
LO PR 67 71 77 82 70 75 82 87 73 78 85 91 77 82 89 95 81 86 94 100 83 89 97 103
MBh 34.5 35.2 37.6 40.2 33.7 34.4 36.8 39.3 32.9 33.6 35.9 38.4 32.1 32.8 35.0 37.4 30.5 31.1 33.3 35.5 28.2 28.8 30.8 32.9
S/T 0.90 0.84 0.69 0.51 0.93 0.87 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.92
0.75
0.56 1.00 0.96 0.78 0.58 1.00 0.97 0.79 0.59
DT 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 22 22 19 15 21 20 18 14
80 1260 KW 2.40 2.45 2.52 2.60 2.58 2.63 2.71 2.80 2.74 2.79 2.88 2.98 2.88 2.94
3.03
3.13 3.00 3.06 3.16 3.27 3.10 3.17 3.27 3.38
AMPS 9.3 9.5 9.8 10.2 10.0 10.2 10.6 11.0 10.9 11.1 11.5 11.9 11.6 11.9 12.3 12.7 12.3 12.6 13.0 13.5 13.0 13.4 13.8 14.3
HI PR 144 155 163 170 161 174 183 191 184 198 209 218 209 225
238
248 235 253 267 279 260 280 295 308
LO PR 66 70 77 82 70 74 81 86 72 77 84 90 76 81 88 94 80 85 93 99 83 88 96 102
MBh 31.8 32.5 34.7 37.1 31.1 31.7 33.9 36.3 30.3 31.0 33.1 35.4 29.6 30.2 32.3 34.5 28.1 28.7 30.7 32.8 26.0 26.6 28.4 30.4
S/T 0.87 0.81 0.66 0.49 0.90 0.84 0.69 0.51 0.92 0.86 0.70 0.53 0.95 0.89 0.73 0.54 0.99 0.93 0.75 0.56 1.00 0.93 0.76 0.57
DT 23 22 19 15 23 22 19 15 23 22 19 16 23 22 20 16 23 22 19 15 22 21 18 14
1103 KW 2.34 2.39 2.46 2.54 2.52 2.57 2.65 2.73 2.67 2.73 2.81 2.90 2.81 2.87 2.96 3.06 2.92 2.99 3.08 3.18 3.02 3.09 3.19 3.29
AMPS 9.0 9.2 9.5 9.9 9.7 10.0 10.3 10.7 10.6 10.8 11.2 11.6 11.3 11.5 11.9 12.4 12.0 12.3 12.7 13.2 12.7 13.0 13.4 13.9
HI PR 140 150 159 165 157 168 178 186 178 192 202 211 203 218 230 240 228 246 259 270 252 271 286 299
LO PR 64 68 74 79 68 72 79 84 70 75 82 87 74 79 86 91 77 82 90 96 80 85 93 99
MBh 36.1 36.8 38.6 41.1 35.3 36.0 37.7 40.2 34.4 35.1 36.8 39.2 33.6 34.2 35.9 38.3 31.9 32.5 34.1 36.4 29.6 30.1 31.6 33.7
S/T 0.99 0.95 0.86 0.70 1.00 0.99 0.89 0.72 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.77 1.00 1.00 0.98 0.79 1.00 1.00 0.99 0.80
DT 23 23 22 19 23 23 22 19 22 23 22 19 22 22 22 19 21 21 22 19 19 20 20 18
1418 KW 2.43 2.48 2.56 2.64 2.62 2.67 2.76 2.85 2.78 2.84 2.93 3.03 2.92 2.99 3.08 3.19 3.04 3.11 3.21 3.32 3.15 3.22 3.33 3.44
AMPS 9.4 9.7 10.0 10.3 10.2 10.4 10.8 11.2 11.1 11.3 11.7 12.1 11.8 12.1 12.5 12.9 12.5 12.9 13.3 13.8 13.3 13.6 14.1 14.6
HI PR 147 158 167 174 165 177 187 195 187 202 213 222 213 230 242 253 240 258 273 284 265 285 301 314
LO PR 67 72 78 83 71 76 83 88 74 79 86 91 78 83 90 96 81 87 95 101 84 90 98 104
MBh 35.1 35.7 37.4 39.9 34.3 34.9 36.6 39.0 33.4 34.1 35.7 38.1 32.6 33.3 34.8 37.2 31.0 31.6 33.1 35.3 28.7 29.3 30.6 32.7
S/T 0.94 0.91 0.82 0.67 0.98 0.94 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.93 0.76 1.00 1.00 0.94 0.76
DT 24 24 22 19 24 24 23 20 24 24 23 20 24 24 23 20 23 23 23 20 21 21 21 18
85 1260 KW 2.42 2.47 2.54 2.62 2.60 2.65 2.74 2.82 2.76 2.82 2.91 3.00 2.90 2.96 3.06 3.16 3.02 3.09 3.19 3.29 3.12 3.19 3.30 3.41
AMPS 9.4 9.6 9.9 10.2 10.1 10.3 10.7 11.1 11.0 11.2 11.6 12.0 11.7 12.0 12.4 12.8 12.4 12.7 13.2 13.6 13.2 13.5 13.9 14.5
HI PR 145 156 165 172 163 175 185 193 185 200 211 220 211 227 240 250 238 256 270 282 262 282 298 311
LO PR 67 71 77 82 70 75 82 87 73 78 85 91 77 82 89 95 81 86 94 100 83 89 97 103
MBh 32.4 33.0 34.6 36.9 31.6 32.2 33.8 36.0 30.9 31.5 32.9 35.1 30.1 30.7 32.1 34.3 28.6 29.2 30.5 32.6 26.5 27.0 28.3 30.2
S/T 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.67 0.97 0.93 0.84 0.68 1.00 0.96 0.87 0.70 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74
DT 25 24 23 20 25 24 23 20 25 24 23 20 25 25 23 20 24 24 23 20 22 23 21 19
1103 KW 2.36 2.41 2.48 2.56 2.54 2.59 2.67 2.76 2.69 2.75 2.84 2.93 2.83 2.89 2.98 3.08 2.95 3.01 3.11 3.21 3.05 3.11 3.21 3.32
AMPS 9.1 9.3 9.6 10.0 9.8 10.1 10.4 10.8 10.7 10.9 11.3 11.7 11.4 11.6 12.0 12.5 12.1 12.4 12.8 13.3 12.8 13.1 13.5 14.1
HI PR 141 152 160 167 158 170 180 187 180 194 204 213 205 220 233 243 230 248 262 273 255 274 289 302
LO PR 65 69 75 80 68 73 79 84 71 76 82 88 75 79 87 92 78 83 91 97 81 86 94 100
Shaded area is ARI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
