8
COOLING PERFORMANCE DATA
ASH130241A*
EXPANDED PERFORMANCE DATA
MODEL: ASH130241A* & ARUF032-00*-1* / ARUF18241A* COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 23.1 24.0 26.3 - 22.6 23.4 25.7 - 22.1 22.9 25.0 - 21.5 22.3 24.4 - 20.4 21.2 23.2 - 18.9 19.6 21.5 -
S/T 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.77 0.64 0.45 - 0.80 0.66 0.46 - 0.83 0.69 0.48 - 0.83 0.70 0.48 -
DT 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -
899 KW 1.59 1.63 1.68 - 1.72 1.76 1.81 - 1.83 1.87 1.93 - 1.92 1.97 2.03 - 2.01 2.05 2.12 - 2.08 2.12 2.20 -
AMPS 6.4 6.5 6.7 - 6.9 7.0 7.3 - 7.4 7.6 7.9 - 7.9 8.1 8.4 - 8.4 8.7 8.9 - 8.9 9.2 9.5 -
HI PR 142 153 161 - 159 172 181 - 181 195 206 - 206 222 235 - 232 250 264 - 257 276 292 -
LO PR 60 64 69 - 63 67 73 - 66 70 76 - 69 73 80 - 72 77 84 - 75 80 87 -
MBh 22.5 23.3 25.5 - 21.9 22.7 24.9 - 21.4 22.2 24.3 - 20.9 21.6 23.7 - 19.8 20.6 22.5 - 18.4 19.1 20.9 -
S/T 0.69 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.61 0.43 - 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.79 0.66 0.46 -
DT 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
70 799 KW 1.58 1.62 1.67 - 1.70 1.74 1.80 - 1.81 1.85 1.91 - 1.91 1.95 2.02 - 1.99 2.03 2.10 - 2.06 2.11 2.18 -
AMPS 6.3 6.5 6.7 - 6.8 7.0 7.2 - 7.4 7.6 7.8 - 7.9 8.1 8.3 - 8.4 8.6 8.9 - 8.9 9.1 9.4 -
HI PR 141 151 160 - 158 170 179 - 179 193 204 - 204 220 232 - 230 247 261 - 254 273 289 -
LO PR 59 63 69 - 63 67 73 - 65 69 76 - 68 73 79 - 72 76 83 - 74 79 86 -
MBh 20.7 21.5 23.5 - 20.2 21.0 23.0 - 19.8 20.5 22.4 - 19.3 20.0 21.9 - 18.3 19.0 20.8 - 17.0 17.6 19.3 -
S/T 0.67 0.56 0.39 - 0.69 0.58 0.40 - 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.77 0.64 0.44 -
DT 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
699 KW 1.54 1.58 1.63 - 1.66 1.70 1.75 - 1.77 1.81 1.87 - 1.86 1.90 1.96 - 1.94 1.98 2.05 - 2.01 2.05 2.12 -
AMPS 6.1 6.3 6.5 - 6.6 6.8 7.0 - 7.2 7.4 7.6 - 7.7 7.8 8.1 - 8.1 8.3 8.6 - 8.6 8.8 9.1 -
HI PR 136 147 155 - 153 165 174 - 174 187 198 - 198 213 225 - 223 240 253 - 246 265 280 -
LO PR 57 61 67 - 61 65 70 - 63 67 73 - 66 70 77 - 69 74 81 - 72 76 83 -
MBh 23.5 24.2 26.2 28.1 23.0 23.7 25.6 27.5 22.4 23.1 25.0 26.8 21.9 22.5 24.4 26.2 20.8 21.4 23.2 24.9 19.3 19.8 21.5 23.0
S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.88 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.94 0.84 0.64 0.41 0.95 0.85 0.64 0.41
DT 20 18 15 10 20 19 15 10 20 19 15 10 20 19 15 11 20 18 15 10 19 17 14 10
899 KW 1.61 1.64 1.69 1.75 1.73 1.77 1.83 1.89 1.84 1.88 1.95 2.01 1.94 1.98 2.05 2.12 2.02 2.07 2.14 2.21 2.09 2.14 2.21 2.29
AMPS 6.4 6.6 6.8 7.0 6.9 7.1 7.3 7.6 7.5 7.7 7.9 8.2 8.0 8.2 8.5 8.8 8.5 8.7 9.0 9.4 9.0 9.2 9.6 9.9
HI PR 143 154 163 170 161 173 183 191 183 197 208 217 209 224 237 247 235 253 267 278 259 279 295 307
LO PR 60 64 70 75 64 68 74 79 66 71 77 82 70 74 81 86 73 78 85 90 76 80 88 93
MBh 22.8 23.5 25.4 27.3 22.3 23.0 24.9 26.7 21.8 22.4 24.3 26.0 21.2 21.9 23.7 25.4 20.2 20.8 22.5 24.1 18.7 19.2 20.8 22.4
S/T 0.79 0.70 0.53 0.34 0.82 0.73 0.55 0.36 0.84 0.75 0.57 0.36 0.86 0.77 0.58 0.38 0.90 0.80 0.61 0.39 0.90 0.81 0.61 0.39
DT 21 19 16 11 21 19 16 11 21 19 16 11 21
19
16 11 21 19 16 11 19 18 15 10
75 799 KW 1.60 1.63 1.68 1.74 1.72 1.76 1.81 1.87 1.83 1.87 1.93 1.99 1.92
1.97
2.03 2.10 2.01 2.05 2.12 2.19 2.08 2.12 2.20 2.27
AMPS 6.4 6.5 6.7 7.0 6.9 7.0 7.3 7.5 7.4 7.6 7.9 8.2 7.9 8.1 8.4 8.7 8.4 8.7 8.9 9.3 8.9 9.2 9.5 9.8
HI PR 142 153 161 168 159 172 181 189 181 195 206 215 207 222 235 245 232 250 264 275 257 276 292 304
LO PR 60 64 69 74 63 67 73 78 66 70 76 81 69
73
80 85 72 77 84 89 75 80 87 93
MBh 21.1 21.7 23.5 25.2 20.6 21.2 22.9 24.6 20.1 20.7 22.4 24.0 19.6 20.18 21.8 23.4 18.6 19.2 20.8 22.3 17.3 17.8 19.2 20.6
S/T 0.76 0.68 0.51 0.33 0.79 0.70 0.53 0.34 0.81 0.72 0.55 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.38 0.87 0.78 0.59 0.38
DT 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 19 16 11 20 18 15 10
699 KW 1.56 1.59 1.64 1.69 1.68 1.71 1.77 1.83 1.78 1.82 1.88 1.94 1.88 1.92 1.98 2.05 1.96 2.00 2.07 2.14 2.02 2.07 2.14 2.21
AMPS 6.2 6.3 6.5 6.8 6.7 6.8 7.1 7.3 7.2 7.4 7.7 7.9 7.7 7.9 8.2 8.5 8.2 8.4 8.7 9.0 8.7 8.9 9.2 9.5
HI PR 138 148 157 163 155 166 176 183 176 189 200 208 200 216 228 237 225 243 256 267 249 268 283 295
LO PR 58 62 67 72 61 65 71 76 64 68 74 79 67 71 78 83 70 75 81 87 73 77 84 90
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
