COOLING PERFORMANCE DATA
ASH130181A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSH130181A* / ARUF32-00*-1* / ARUF18241A*
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB
*
Airflow 5963677159636771596367715963 67715963677159636771
MBh 18.3 18.7 19.9 21.3 17.8 18.2 19.5 20.8 17.4 17.8 19.0 20.3 17.0 17.4 18.5 19.8 16.1 16.5 17.6 18.8 14.9 15.3 16.3 17.4
S/T 0.91 0.85 0.69 0.52 0.94 0.88 0.72 0.54 0.97 0.91 0.74 0.55 1.00 0.93 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.80 0.59
DT 23 22 19 15 23 22 19 16 23 22 19 16 24 23 20 16 22 22 19 15 21 21 18 14
662 KW 1.25 1.27 1.31 1.36 1.34 1.37 1.41 1.46 1.43 1.46 1.50 1.55 1.50 1.53 1.58 1.63 1.56 1.60 1.65 1.70 1.62 1.65 1.71 1.76
AMPS 4.9 5.0 5.2 5.4 5.3 5.4 5.6 5.8 5.8 5.9 6.1 6.3 6.1 6.3 6.5 6.7 6.5 6.7 6.9 7.1 6.9 7.1 7.3 7.6
HI PR 142 153 162 169 160 172 181 189 182 195 206 215 207 223 235 245 233 250 264 276 257 277 292 305
LO PR 63 67 73 78 66 70 77 82 69 73 80 85 72 77 84 89 76 81 88 94 78 83 91 97
MBh 17.7 18.1 19.4 20.7 17.3 17.7 18.9 20.2 16.9 17.3 18.5 19.7 16.5 16.8
18.0
19.2 15.7 16.0 17.1 18.3 14.5 14.8 15.8 16.9
S/T 0.87 0.81 0.66 0.49 0.90 0.84 0.69 0.51 0.92 0.86 0.70 0.53 0.95 0.89
0.73
0.54 0.99 0.92 0.75 0.56 0.99 0.93 0.76 0.57
DT 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 23 22 19 15
80 589 KW 1.24 1.26 1.30 1.34 1.33 1.36 1.40 1.45 1.41 1.45 1.49 1.54 1.49 1.52 1.57 1.62 1.55 1.58 1.64 1.69 1.60 1.64 1.69 1.75
AMPS 4.9 5.0 5.2 5.3 5.3 5.4 5.6 5.8 5.7 5.8 6.0 6.2 6.1 6.2 6.4 6.7 6.5 6.6 6.8 7.1 6.8 7.0 7.2 7.5
HI PR 141 152 160 167 158 170 180 187 180 193 204 213 205 220 233 243 230 248 262 273 254 274 289 302
LO PR 62 66 72 77 66 70 76 81 68 73 79 84 72 76 83 89 75 80 87 93 78 83 90 96
MBh 16.4 16.7 17.9 19.1 16.0 16.3 17.4 18.6 15.6 15.9 17.0 18.2 15.2 15.6 16.6 17.8 14.5 14.8 15.8 16.9 13.4 13.7 14.6 15.6
S/T 0.84 0.78 0.64 0.48 0.87 0.81 0.66 0.49 0.89 0.83 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.73 0.54 0.96 0.90 0.73 0.55
DT 24 23 20 16 25 24 21 16 25 24 21 16 25 24 21 17 25 24 20 16 23 22 19 15
515 KW 1.21 1.23 1.27 1.31 1.30 1.33 1.37 1.41 1.38 1.41 1.45 1.50 1.45 1.48 1.53 1.58 1.51 1.54 1.59 1.65 1.56 1.60 1.65 1.70
AMPS 4.8 4.9 5.0 5.2 5.1 5.2 5.4 5.6 5.6 5.7 5.9 6.1 5.9 6.1 6.3 6.5 6.3 6.4 6.6 6.9 6.6 6.8 7.0 7.3
HI PR 137 147 155 162 153 165 174 182 174 188 198 207 199 214 226 235 223 240 254 265 247 266 281 293
LO PR 60 64 70 74 64 68 74 79 66 70 77 82 69 74 81 86 73 77 85 90 75 80 87 93
MBh 18.6 18.9 19.8 21.2 18.1 18.5 19.4 20.7 17.7 18.1 18.9 20.2 17.3 17.6 18.4 19.7 16.4 16.7 17.5 18.7 15.2 15.5 16.2 17.3
S/T 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.98 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.77 1.00 1.00 0.95 0.77
DT 25 24 23 20 25 24 23 20 25 24 23 20 24 24 23 20 23 23 23 20 21 22 21 19
662 KW 1.26 1.28 1.32 1.37 1.35 1.38 1.43 1.47 1.44 1.47 1.52 1.57 1.51 1.54 1.60 1.65 1.57 1.61 1.66 1.72 1.63 1.67 1.72 1.78
AMPS 5.0 5.1 5.2 5.4 5.4 5.5 5.7 5.9 5.8 5.9 6.1 6.4 6.2 6.3 6.5 6.8 6.6 6.7 6.9 7.2 6.9 7.1 7.3 7.6
HI PR 144 155 163 170 161 174 183 191 183 197 208 217 209 225 237 248 235 253 267 278 260 279 295 308
LO PR 63 67 74 78 67 71 78 83 70 74 81 86 73 78 85 90 77 81 89 95 79 84 92 98
MBh 18.0 18.4 19.3 20.5 17.6 18.0 18.8 20.1 17.2 17.5 18.4 19.6 16.8 17.1 17.9 19.1 15.9 16.2 17.0 18.2 14.8 15.0 15.8 16.8
S/T 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.66 0.97 0.93 0.84 0.68 1.00 0.96 0.87 0.70 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74
DT 26 25 24 21 26 25 24 21 26 25 24 21 26 26 24 21 25 25 24 21 23 24 22 19
85 589 KW 1.25 1.27 1.31 1.36 1.34 1.37 1.41 1.46 1.43 1.46 1.50 1.55 1.50 1.53 1.58 1.63 1.56 1.60 1.65 1.70 1.62 1.65 1.71 1.76
AMPS 4.9 5.0 5.2 5.4 5.3 5.4 5.6 5.8 5.8 5.9 6.1 6.3 6.1 6.3 6.5 6.7 6.5 6.7 6.9 7.1 6.9 7.1 7.3 7.6
HI PR 142 153 162 169 160 172 181 189 182 195 206 215 207 223 235 245 233 250 264 276 257 277 292 305
LO PR 63 67 73 78 66 70 77 82 69 73 80 85 72 77 84 89 76 81 88 94 78 83 91 97
MBh 16.6 17.0 17.8 19.0 16.3 16.6 17.4 18.5 15.9 16.2 16.9 18.1 15.5 15.8 16.5 17.6 14.7 15.0 15.7 16.8 13.6 13.9 14.5 15.5
S/T 0.88 0.84 0.76 0.62 0.91 0.88 0.79 0.64 0.93 0.90 0.81 0.66 0.96 0.93 0.84 0.68 1.00 0.96 0.87 0.70 1.00 0.97 0.88 0.71
DT 26 26 24 21 26 26 24 21 26 26 25 21 27 26 25 21 26 26 24 21 24 24 23 20
515 KW 1.22 1.24 1.28 1.32 1.31 1.34 1.38 1.42 1.39 1.42 1.47 1.51 1.46 1.49 1.54 1.59 1.52 1.56 1.61 1.66 1.58 1.61 1.66 1.72
AMPS 4.8 4.9 5.1 5.2 5.2 5.3 5.5 5.7 5.6 5.7 5.9 6.1 6.0 6.1 6.3 6.5 6.3 6.5 6.7 6.9 6.7 6.9 7.1 7.3
HI PR 138 149 157 164 155 167 176 184 176 190 200 209 201 216 228 238 226 243 256 267 249 268 283 295
LO PR 61 65 71 75 64 68 75 79 67 71 78 83 70 75 81 87 74 78 85 91 76 81 88 94
Shaded area is ARI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.
