54
COOLING PERFORMANCE DATA
VSH130301A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: VSH130301A* / AR*F303016B* Design Subcooling 9 ±3 °F @ the liquid service valve, AHRI 95 test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 63 67 71 59 63 67 71 59 6
67 71 59 63 67 71 59 63 67 71 59 63 67 71
MBh 27.0 28.0 30.7 - 26.4 27.4 30.0 - 25.8 26.7 29.3 - 25.2 26.1 28.6 - 23.9 24.8 27.1 - 22.1 22.9 25.1 -
S/T 0.75 0.63 0.43 - 0.78 0.65 0.45 - 0.80 0.67 0.46 - 0.82 0.69 0.48 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -
DELTA T161410 - 161411 - 161411 - 16 14 11 - 161411 - 151310 -
1173 KW 2.04 2.08 2.14 - 2.19 2.24 2.31 - 2.32 2.37 2.45 - 2.44 2.49 2.57 - 2.54 2.60 2.68 - 2.63 2.69 2.77 -
AMPS 7.6 7.8 8.1 - 8.2 8.4 8.7 - 9.0 9.2 9.5 - 9.6 9.8 10.2 - 10.2 10.5 10.8 - 10.8 11.1 11.5 -
HI PR 141 152 161 - 159 171 180 - 181 194 205 - 206 221 234 - 231 249 263 - 256 275 290 -
LO PR 62 66 73 - 66 70 77 - 69 73 80 - 72 77 84 - 75 80 88 - 78 83 91 -
MBh 26.6 27.6 30.3 - 26.0 27.0 29.5 - 25.4 26.3 28.8 - 24.8 25.7 28.1 - 23.5 24.4 26.7 - 21.8 22.6 24.8 -
S/T 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.82 0.69 0.48 -
DELTA T171511 - 171511 - 171511 - 17 15 11 - 171511 - 161410 -
70 1050 KW 2.03 2.07 2.13 - 2.18 2.22 2.29 - 2.31 2.36 2.43 - 2.43 2.48 2.56 - 2.53 2.58 2.67 - 2.61 2.67 2.76 -
AMPS 7.6 7.8 8.0 - 8.2 8.4 8.7 - 8.9 9.1 9.4 - 9.5 9.8 10.1 - 10.1 10.4 10.7 - 10.8 11.0 11.4 -
HI PR 140 151 160 - 158 170 179 - 179 193 204 - 204 220 232 - 230 247 261 - 254 273 288 -
LO PR 62 66 72 - 66 70 76 - 68 72 79 - 72 76 83 - 75 80 87 - 78 82 90 -
MBh 25.3 26.2 28.7 - 24.7 25.6 28.1 - 24.1 25.0 27.4 - 23.5 24.4 26.7 - 22.4 23.2 25.4 - 20.7 21.5 23.5 -
S/T 0.69 0.57 0.40 - 0.71 0.60 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.44 - 0.78 0.65 0.45 - 0.79 0.66 0.46 -
DELTA T171511 - 171511 - 181512 - 18 15 12 - 171511 - 161411 -
927 KW 2.00 2.04 2.10 - 2.14 2.19 2.26 - 2.27 2.32 2.40 - 2.39 2.44 2.52 - 2.49 2.54 2.62 - 2.57 2.63 2.71 -
AMPS 7.4 7.6 7.9 - 8.0 8.2 8.5 - 8.7 9.0 9.3 - 9.3 9.6 9.9 - 10.0 10.2 10.5 - 10.6 10.8 11.2 -
HI PR 138 148 156 - 154 166 176 - 176 189 200 - 200 215 227 - 225 242 256 - 249 268 283 -
LO PR 61 65 71 - 64 68 75 - 67 71 78 - 70 75 81 - 73 78 85 - 76 81 88 -
MBh 27.50 28.31 30.64 32.89 26.86 27.65 29.93 32.12 26.22 26.99 29.22 31.36 25.58 26.34 28.51 30.59 24.30 25.02 27.08 29.06 22.51 23.17 25.08 26.92
S/T 0.85 0.76 0.58 0.37 0.88 0.79 0.60 0.38 0.91 0.81 0.61 0.39 0.94 0.84 0.63 0.41 0.97 0.87 0.66 0.42 0.98 0.88 0.66 0.43
DELTA T18171410191714101917141019 17 14 1018171410171613 9
1173 KW 2.05 2.10 2.16 2.23 2.21 2.25 2.32 2.40 2.34 2.39 2.47 2.55 2.46 2.52 2.60 2.68 2.56 2.62 2.70 2.79 2.65 2.71 2.80 2.89
AMPS 7.7 7.9 8.1 8.4 8.3 8.5 8.8 9.1 9.0 9.3 9.6 9.9 9.7 9.9 10.3 10.6 10.3 10.6 10.9 11.3 10.9 11.2 11.6 12.0
HI PR 143 154 162 169 160 173 182 190 182 196 207 216 208 224 236 246 234 251 266 277 258 278 293 306
LO PR 63 67 73 78 67 71 77 82 69 74 80 86 73 77 85 90 76 81 89 94 79 84 92 98
MBh 27.1 27.9 30.2 32.4 26.5 27.2 29.5 31.6 25.8 26.6 28.8 30.9 25.2
25.9
28.1 30.1 23.9 24.6 26.7 28.6 22.2 22.8 24.7 26.5
S/T 0.820.730.550.360.850.760.570.370.870.780.590.380.90
0.80
0.61 0.39 0.93 0.83 0.63 0.40 0.94 0.84 0.63 0.41
DELTA T19181510201815102018151020
18
15 10 19 18 15 10 18 17 14 9
75 1050 KW 2.042.082.152.222.192.242.312.382.332.382.452.532.45
2.50
2.58 2.67 2.55 2.60 2.69 2.78 2.64 2.69 2.78 2.87
AMPS7.67.88.18.48.38.58.89.19.09.29.59.99.6
9.9
10.2 10.6 10.2 10.5 10.8 11.3 10.9 11.1 11.5 11.9
HI PR 142 153 161 168 159 171 181 189 181 195 206 215 206
222
234 244 232 250 264 275 256 276 291 304
LO PR 63 67 73 77 66 70 77 82 69 73 80 85 72
77
84 89 76 81 88 94 78 83 91 97
MBh 25.7 26.5 28.7 30.8 25.1 25.9 28.0 30.1 24.5 25.3 27.3 29.4 23.9 24.65 26.7 28.6 22.7 23.4 25.3 27.2 21.1 21.7 23.5 25.2
S/T 0.78 0.70 0.53 0.34 0.81 0.73 0.55 0.35 0.83 0.74 0.56 0.36 0.86 0.77 0.58 0.37 0.89 0.80 0.60 0.39 0.90 0.80 0.61 0.39
DELTA T20181510201915112019151120 19 15 112019151019171410
927 KW 2.01 2.05 2.11 2.18 2.16 2.21 2.27 2.35 2.29 2.34 2.41 2.49 2.41 2.46 2.54 2.62 2.51 2.56 2.64 2.73 2.59 2.65 2.74 2.83
AMPS 7.5 7.7 7.9 8.2 8.1 8.3 8.6 8.9 8.8 9.0 9.3 9.7 9.4 9.7 10.0 10.4 10.0 10.3 10.6 11.1 10.7 10.9 11.3 11.7
HI PR 139 150 158 165 156 168 177 185 177 191 202 210 202 218 230 240 227 245 258 270 251 270 286 298
LO PR 61 65 71 76 65 69 75 80 67 72 78 83 71 75 82 88 74 79 86 92 77 82 89 95
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
