21
HEATING PERFORMANCE DATA
High pressure is measured at the liquid service valve (the smaller valve). AMPS = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connection. KW = Total system power
Calculations are based on nominal CFM and 70 °F indoor dry bulb.
EXPANDED PERFORMANCE DATA
MODEL: ASH130361A* & ARUF049-00*-1* / ARUF36421A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 42.7 40.5 38.1 35.6 34.0 32.9 30.6 28.2 20.0 18.5 17.0 16.1 15.5 13.9 12.3 10.7 9.2 7.5
Delta T 31.4 29.7 28.0 26.2 25.0 24.2 22.5 20.7 14.7 13.6 12.5 11.8 11.4 10.2 9.0 7.9 6.7 5.5
KW 2.90 2.85 2.79 2.74 2.70 2.68 2.63 2.57 2.43 2.37 2.32 2.29 2.27 2.21 2.16 2.11 2.05 2.00
AMPS 13.0 12.1 11.3 10.7 10.3 10.1 9.5 9.1 8.7 8.3 7.9 7.7 7.6 7.3 6.8 6.4 5.9 5.4
COP 4.314.163.993.813.683.603.413.212.412.282.152.052.001.841.671.491.301.10
EER 14.7 14.2 13.6 13.0 12.6 12.3 11.7 11.0 8.2 7.8 7.3 7.0 6.8 6.3 5.7 5.1 4.5 3.7
HI PR 230 221 212 203 198 194 187 179 172 164 158 154 151 145 140 134 129 125
LO PR 80 74 70 64 60 58 54 48 43 38 34 31 30 26 22 19 16 13
EXPANDED PERFORMANCE DATA
MODEL: ASH130421A* & ARUF049-00*-1* / ARUF36421A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 49.0 46.4 43.7 40.8 39.0 37.8 35.1 32.4 28.4 26.2 24.1 22.8 21.9 19.7 17.4 15.2 13.0 10.6
Delta T 30.5 28.9 27.2 25.4 24.3 23.5 21.8 20.1 17.6 16.3 15.0 14.2 13.6 12.2 10.8 9.5 8.1 6.6
KW 3.49 3.42 3.36 3.29 3.25 3.22 3.16 3.09 3.09 3.02 2.95 2.91 2.88 2.81 2.75 2.68 2.61 2.54
AMPS 16.7 15.5 14.5 13.6 13.1 12.9 12.1 11.5 11.0 10.5 10.0 9.8 9.7 9.2 8.6 8.1 7.4 6.7
COP 4.113.973.813.633.513.433.253.072.692.542.392.292.232.051.861.661.461.22
EER 14.0 13.6 13.0 12.4 12.0 11.7 11.1 10.5 9.2 8.7 8.2 7.8 7.6 7.0 6.3 5.7 5.0 4.2
HI PR 237 227 218 209 204 200 192 184 177 169 162 158 155 149 144 138 133 128
LO PR 75 70 65 60 57 54 50 45 40 36 32 29 28 24 21 17 15 12
EXPANDED PERFORMANCE DATA
MODEL: ASH130481A* & ARUF061-00*-1* / ARUF48601A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 54.1 51.2 48.2 45.0 43.0 41.7 38.7 35.7 33.2 30.7 28.2 26.7 25.7 23.0 20.4 17.8 15.2 12.5
Delta T 30.2 28.6 26.9 25.1 24.0 23.3 21.6 19.9 18.6 17.1 15.8 14.9 14.3 12.9 11.4 10.0 8.5 7.0
KW 3.84 3.77 3.70 3.63
3.59
3.56 3.49 3.42 3.34 3.27 3.20 3.16 3.13 3.06 2.99 2.92 2.85 2.78
AMPS 18.1 16.8 15.7 14.8 14.3 14.0 13.2 12.5 12.0 11.5 10.9 10.7 10.5 10.0 9.3 8.8 8.1 7.3
COP 4.113.973.813.633.513.433.253.062.912.742.582.472.402.202.001.791.561.31
EER 14.1 13.6 13.0 12.4 12.0 11.7 11.1 10.4 9.9 9.4 8.8 8.4 8.2 7.5 6.8 6.1 5.3 4.5
HI PR 224 215 207 198 193 189 182 175 167 160 154 150 147 142 136 131 126 121
LO PR 74 69 64 59 56 54 49 44 40 35 31 29 28 24 20 17 15 12
