32
COOLING PERFORMANCE DATA
GSH130481A*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: GSH130481A* / ARUF61-00*-1* / ARUF48601A*
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67 715963677159636771
MBh 44.1 45.7 50.1 - 43.1 44.6 48.9 - 42.0 43.6 47.7 - 41.0 42.5 46.6 - 39.0 40.4 44.3 - 36.1 37.4 41.0 -
S/T 0.76 0.63 0.44 - 0.79 0.66 0.46 - 0.81 0.67 0.47 - 0.83 0.70 0.48 - 0.86 0.72 0.50 - 0.87 0.73 0.50 -
Delta T 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 17 15 11 - 16 14 11 -
1800 KW 3.22 3.28 3.37 - 3.44 3.51 3.61 - 3.64 3.71 3.82 - 3.81 3.89 4.01 - 3.96 4.04 4.17 - 4.09 4.17 4.30 -
AMPS 12.1 12.4 12.8 - 13.0 13.4 13.8 - 14.2 14.5 15.0 - 15.1 15.5 16.0 - 16.1 16.5 17.0 - 17.1 17.5 18.1 -
HI PR 142 153 161 - 159 172 181 - 181 195 206 - 207 222 235 - 232 250 264 - 257 276 292 -
LO PR 64 68 74 - 67 72 78 - 70 75 81 - 74 78 86 - 77 82 90 - 80 85 93 -
MBh 42.8 44.4 48.6 - 41.8 43.3 47.5 - 40.8 42.3 46.4 - 39.8 41.3 45.2 - 37.8 39.2 43.0 - 35.0 36.3 39.8 -
S/T 0.72 0.60 0.42 - 0.75 0.63 0.43 - 0.77 0.64 0.45 - 0.79 0.66 0.46 - 0.82 0.69 0.48 - 0.83 0.69 0.48 -
Delta T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 14 11 -
70 1600 KW 3.20 3.26 3.35 - 3.42 3.48 3.58 - 3.61 3.68 3.79 - 3.78 3.86 3.98 - 3.93 4.01 4.13 - 4.06 4.14 4.27 -
AMPS 12.0 12.3 12.7 - 12.9 13.2 13.7 - 14.0 14.4 14.8 - 15.0 15.4 15.9 - 16.0 16.3 16.9 - 16.9 17.3 17.9 -
HI PR 141 151 160 - 158 170 179 - 180 193 204 - 205 220 232 - 230 248 261 - 254 274 289 -
LO PR 63 67 73 - 67 71 78 - 69 74 81 - 73 78 85 - 76 81 89 - 79 84 92 -
MBh 39.5 41.0 44.9 - 38.6 40.0 43.8 - 37.7 39.1 42.8 - 36.8 38.1 41.7 - 34.9 36.2 39.7 - 32.3 33.5 36.7 -
S/T 0.70 0.58 0.40 - 0.72 0.60 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.46 - 0.80 0.67 0.46 -
Delta T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
1400 KW 3.13 3.19 3.28 - 3.34 3.41 3.50 - 3.53 3.60 3.71 - 3.70 3.77 3.89 - 3.84 3.92 4.04 - 3.96 4.04 4.17 -
AMPS 11.7 11.9 12.3 - 12.6 12.9 13.3 - 13.7 14.0 14.4 - 14.6 14.9 15.4 - 15.5 15.9 16.4 - 16.4 16.8 17.4 -
HI PR 136 147 155 - 153 165 174 - 174 187 198 - 198 213 225 - 223 240 254 - 247 265 280 -
LO PR 61 65 71 - 65 69 75 - 67 72 78 - 71 75 82 - 74 79 86 - 77 82 89 -
MBh 44.8 46.2 50.0 53.6 43.8 45.1 48.8 52.4 42.8 44.0 47.7 51.1 41.7 42.9 46.5 49.9 39.6 40.8 44.2 47.4 36.7 37.8 40.9 43.9
S/T 0.86 0.77 0.58 0.38 0.89 0.80 0.61 0.39 0.92 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.98 0.88 0.66 0.43 0.99 0.89 0.67 0.43
Delta T20181510201815102018151020 19 15 11 20 18 15 10 19 17 14 10
1800 KW 3.24 3.30 3.40 3.50 3.47 3.54 3.64 3.75 3.67 3.74 3.85 3.97 3.84 3.92 4.04 4.16 3.99 4.07 4.20 4.33 4.12 4.21 4.34 4.47
AMPS 12.2 12.5 12.9 13.4 13.2 13.5 13.9 14.4 14.3 14.6 15.1 15.7 15.3 15.6 16.2 16.8 16.2 16.6 17.2 17.9 17.2 17.6 18.2 18.9
HI PR 144 154 163 170 161 173 183 191 183 197 208 217 209 225 237 247 235 253 267 278 259 279 295 307
LO PR 65 69 75 80 68 73 79 84 71 75 82 88 74 79 86 92 78 83 91 96 81 86 94 100
MBh 43.5 44.8 48.5 52.1 42.5 43.8 47.4 50.9 41.5 42.7 46.3 49.7 40.5 41.7 45.1 48.4 38.5 39.6 42.9 46.0 35.6 36.7 39.7 42.6
S/T 0.82 0.74 0.56 0.36 0.85 0.76 0.58 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.94 0.84 0.63 0.41 0.94 0.84 0.64 0.41
Delta T21191611211916112119161121 19 16 11 21 19 16 11 19 18 15 10
75 1600 KW 3.22 3.28 3.37 3.47 3.44 3.51 3.61 3.72 3.64 3.71 3.82 3.94 3.81 3.89 4.01 4.13 3.96 4.04 4.17 4.30 4.09 4.17 4.30 4.44
AMPS 12.1 12.4 12.8 13.2 13.0 13.4 13.8 14.3 14.2 14.5 15.0 15.5 15.1 15.5 16.0 16.6 16.1 16.5 17.0 17.7 17.1 17.5 18.1 18.7
HI PR 142 153 162 168 159 172 181 189 181 195 206 215 207 222 235 245 232 250 264 275 257 276 292 304
LO PR 64 68 74 79 68 72 78 83 70 75 81 87 74 78 86 91 77 82 90 96 80 85 93 99
MBh 40.2 41.4 44.8 48.1 39.3 40.4 43.7 46.9 38.3 39.5 42.7 45.8 37.4 38.5 41.7 44.7 35.5 36.6 39.6 42.5 32.9 33.9 36.7 39.3
S/T 0.79 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.81 0.62 0.40
Delta T21191611212016112120161121 20 16 11 21 19 16 11 20 18 15 10
1400 KW 3.15 3.21 3.30 3.40 3.37 3.43 3.53 3.64 3.56 3.63 3.74 3.85 3.73 3.80 3.92 4.04 3.87 3.95 4.07 4.20 3.99 4.08 4.20 4.33
AMPS 11.8 12.0 12.4 12.9 12.7 13.0 13.4 13.9 13.8 14.1 14.6 15.1 14.7 15.1 15.6 16.2 15.7 16.0 16.6 17.2 16.6 17.0 17.6 18.2
HI PR 138 148 157 163 155 166 176 183 176 189 200 209 200 216 228 238 225 243 256 267 249 268 283 295
LO PR 62 66 72 77 65 70 76 81 68 72 79 84 71 76 83 88 75 80 87 93 77 82 90 96
Shaded area is ACCA (TVA) conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.
