COOLING PERFORMANCE DATA
VSH130251A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: VSH130251A* / AWUF24XX16A* Design Subcooling 9 ±3 °F @ the liquid service valve, AHRI 95 test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB Airflow 59 6
3
6
7
71 59 63 67 71 59 6
3
6
7
71 59 6
3
67 71 59 63 6
7
71 59 6
3
67 71
MBh 23.5 24.4 26.7 - 23.0 23.8 26.1 - 22.4 23.2 25.5 - 21.9 22.7 24.8 - 20.8 21.5 23.6 - 19.3 20.0 21.9 -
S/T 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.79 0.66 0.45 - 0.81 0.68 0.47 - 0.84 0.70 0.49 - 0.85 0.71 0.49 -
DELTA T 17 15 11 - 18 15 12 - 18 15 12 - 18 15 12 - 17 15 11 - 16 14 11 -
923 KW 1.68 1.71 1.76 - 1.79 1.83 1.88 - 1.90 1.93 1.99 - 1.99 2.03 2.09 - 2.06 2.11 2.17 - 2.13 2.18 2.24 -
AMPS 6.7 6.8 7.0 - 7.2 7.3 7.5 - 7.7 7.9 8.1 - 8.2 8.4 8.6 - 8.7 8.9 9.1 - 9.1 9.3 9.6 -
HI PR 139 150 158 - 156 168 177 - 177 191 202 - 202 217 230 - 227 245 258 - 251 270 285 -
LO PR 59 63 69 - 63 67 73 - 65 69 76 - 68 73 80 - 72 76 83 - 74 79 86 -
MBh 22.8 23.7 25.9 - 22.3 23.1 25.3 - 21.8 22.6 24.7 - 21.2 22.0 24.1 - 20.2 20.9 22.9 - 18.7 19.4 21.2 -
S/T 0.71 0.59 0.41 - 0.73 0.61 0.42 - 0.75 0.63 0.43 - 0.77 0.65 0.45 - 0.80 0.67 0.46 - 0.81 0.68 0.47 -
DELTA T 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
70 820 KW 1.66 1.70 1.74 - 1.78 1.81 1.87 - 1.88 1.92 1.98 - 1.97 2.01 2.07 - 2.05 2.09 2.15 - 2.11 2.16 2.23 -
AMPS 6.6 6.8 7.0 - 7.1 7.3 7.5 - 7.6 7.8 8.0 - 8.1 8.3 8.5 - 8.6 8.8 9.0 - 9.0 9.3 9.5 -
HI PR 138 148 156 - 154 166 175 - 176 189 200 - 200 215 227 - 225 242 256 - 249 267 282 -
LO PR 59 63 68 - 62 66 72 - 65 69 75 - 68 72 79 - 71 76 83 - 73 78 85 -
MBh 21.1 21.8 23.9 - 20.6 21.3 23.4 - 20.1 20.8 22.8 - 19.6 20.3 22.3 - 18.6 19.3 21.1 - 17.3 17.9 19.6 -
S/T 0.68 0.57 0.39 - 0.70 0.59 0.41 - 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.78 0.65 0.45 -
DELTA T 18 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
718 KW 1.63 1.66 1.71 - 1.74 1.77 1.83 - 1.84 1.88 1.93 - 1.93 1.97 2.02 - 2.00 2.04 2.10 - 2.07 2.11 2.17 -
AMPS 6.5 6.6 6.8 - 6.9 7.1 7.3 - 7.5 7.6 7.8 - 7.9 8.1 8.3 - 8.4 8.6 8.8 - 8.8 9.0 9.3 -
HI PR 133 144 152 - 150 161 170 - 170 183 194 - 194 209 220 - 218 235 248 - 241 259 274 -
LO PR 57 61 66 - 60 64 70 - 63 67 73 - 66 70 76 - 69 73 80 - 71 76 83 -
MBh 23.92 24.62 26.65 28.61 23.36 24.05 26.03 27.94 22.80 23.48 25.41 27.28 22.25 22.91 24.79 26.61 21.14 21.76 23.55 25.28 19.58 20.16 21.82 23.42
S/T 0.840.750.570.370.870.780.590.380.890.800.600.390.92 0.82 0.62 0.400.960.860.650.420.970.860.650.42
DELTA T20181510201915112019151120 19 15 112019151119171410
923 KW 1.69 1.72 1.77 1.82 1.81 1.84 1.90 1.95 1.91 1.95 2.01 2.07 2.00 2.04 2.11 2.17 2.08 2.12 2.19 2.26 2.15 2.19 2.26 2.33
AMPS 6.7 6.9 7.1 7.3 7.2 7.4 7.6 7.8 7.8 7.9 8.2 8.5 8.3 8.4 8.7 9.0 8.7 8.9 9.2 9.5 9.2 9.4 9.7 10.0
HI PR 140 151 160 166 158 170 179 187 179 193 204 212 204 220 232 242 230 247 261 272 254 273 288 301
LO PR 60 64 70 74 63 67 74 78 66 70 76 81 69 74 80 86 72 77 84 90 75 80 87 93
MBh 23.223.925.927.822.723.425.327.122.122.824.726.521.6
22.2
24.1 25.8 20.5 21.1 22.9 24.5 19.0 19.6 21.2 22.7
S/T 0.800.720.540.350.830.740.560.360.850.760.580.370.88
0.79
0.60 0.38 0.91 0.82 0.62 0.40 0.92 0.82 0.62 0.40
DELTA T21191611211916112119161121
20
16 11 21 19 16 11 20 18 15 10
75 820 KW 1.68 1.71 1.76 1.81 1.79 1.83 1.88 1.94 1.90 1.93 1.99 2.05 1.99
2.03
2.09 2.15 2.06 2.11 2.17 2.24 2.13 2.18 2.24 2.31
AMPS6.76.87.07.37.27.37.57.87.77.98.18.48.2
8.4
8.6 8.9 8.7 8.9 9.1 9.4 9.1 9.3 9.6 10.0
HI PR 139 150 158 165 156 168 177 185 177 191 202 210 202
217
230 239 227 245 258 269 251 270 285 298
LO PR 59 63 69 73 63 67 73 78 65 69 76 81 68
73
80 85 72 76 83 89 74 79 86 92
MBh 21.4 22.1 23.9 25.6 20.9 21.6 23.3 25.0 20.4 21.0 22.8 24.4 19.9 20.53 22.2 23.8 18.9 19.5 21.1 22.7 17.5 18.1 19.6 21.0
S/T 0.770.690.520.340.800.720.540.350.820.730.560.360.85 0.76 0.57 0.370.880.790.600.380.890.790.600.39
DELTA T21201611212016112220161122 20 16 112120161120181510
718 KW 1.64 1.67 1.72 1.77 1.75 1.79 1.84 1.89 1.85 1.89 1.95 2.01 1.94 1.98 2.04 2.10 2.02 2.06 2.12 2.19 2.08 2.12 2.19 2.26
AMPS 6.5 6.7 6.9 7.1 7.0 7.1 7.3 7.6 7.5 7.7 7.9 8.2 8.0 8.2 8.4 8.7 8.4 8.6 8.9 9.2 8.9 9.1 9.4 9.7
HI PR 135 145 153 160 151 163 172 179 172 185 196 204 196 211 223 232 220 237 251 261 244 262 277 289
LO PR 58 61 67 71 61 65 71 75 63 67 73 78 66 71 77 82 70 74 81 86 72 77 84 89
Shaded area is ACCA (TVA) conditions IDB: Enteri ng Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.
