HEATING PERFORMANCE DATA
High pressure is measured at the suction service valve ( the larger valve). AMPS = Outdoor unit amps (comp.+fan)
Low pressure is measured at the gauge port connection. KW = Total system power
Calculations are based on nominal CFM and 70 °F indoor dry bulb.
EXPANDED PERFORMANCE DATA
MODEL: GSH130181A* / ARUF32-00*-1* / ARUF18241A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 21.1 20.0 18.8 17.6
16.8
16.3 15.1 13.9 10.7 9.9 9.1 8.6 8.3 7.4 6.6 5.7 4.9 4.0
Delta T 32.6 30.9 29.0 27.1 25.9 25.1 23.3 21.5 16.5 15.3 14.1 13.3 12.8 11.5 10.2 8.9 7.6 6.2
KW 1.57 1.54 1.51 1.48
1.46
1.45 1.42 1.39 1.30 1.27 1.24 1.23 1.22 1.19 1.16 1.13 1.10 1.08
AMPS 7.3 6.8 6.4 6.0 5.8 5.7 5.4 5.1 4.9 4.7 4.4 4.3 4.3 4.1 3.8 3.6 3.3 3.0
COP 3.943.803.653.483.363.293.122.942.412.282.142.051.991.831.661.491.301.09
EER 13.5 13.0 12.5 11.9 11.5 11.2 10.6 10.0 8.2 7.8 7.3 7.0 6.8 6.3 5.7 5.1 4.4 3.7
HI PR 241 231 222 213 208 204 196 188 180 172 165 161 158 152 146 140 135 131
LO PR 83 77 72 66 62 60 55 49 44 40 35 32 31 26 23 19 17 13
EXPANDED PERFORMANCE DATA
MODEL: GSH130241A* / ARUF32-00*-1* / ARUF18241A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 27.7 26.2 24.6 23.0
22.0
21.3 19.8 18.3 15.0 13.8 12.7 12.0 11.6 10.4 9.2 8.0 6.8 5.6
Delta T 31.2 29.6 27.8 26.0 24.8 24.1 22.4 20.6 16.9 15.6 14.3 13.6 13.0 11.7 10.4 9.1 7.7 6.3
KW 2.09 2.05 2.01 1.97
1.95
1.93 1.89 1.85 1.76 1.73 1.69 1.66 1.65 1.61 1.57 1.53 1.49 1.46
AMPS 9.6 8.9 8.3 7.8 7.6 7.4 7.0 6.6 6.4 6.1 5.8 5.7 5.6 5.3 4.9 4.7 4.3 3.9
COP 3.873.733.583.423.303.233.062.892.482.342.202.112.051.891.711.531.341.13
EER 13.2 12.8 12.2 11.7 11.3 11.0 10.5 9.9 8.5 8.0 7.5 7.2 7.0 6.4 5.9 5.2 4.6 3.9
HI PR 261 250 240 230 224 220 212 203 195 186 178 174 171 164 158 152 146 141
LO PR 80 74 70 64 61 58 54 48 43 38 34 31 30 26 22 19 16 13
*Note: Shaded area is AHRI Rating Conditions at 47° outdoor ambient temperature
EXPANDED PERFORMANCE DATA
MODEL: GSH130191A* / AWB24-XX / AWUF18XX1A* HEATING OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 21.1 20.0 18.8 17.6
16.8
16.3 15.1 13.9 10.7 9.9 9.1 8.6 8.3 7.4 6.6 5.7 4.9 4.0
Delta T32.630.929.027.125.925.123.321.516.515.314.113.312.811.510.2 8.9 7.6 6.2
KW 1.66 1.63 1.60 1.57 1.55 1.54 1.51 1.48 1.51 1.47 1.44 1.42 1.41 1.38 1.35 1.32 1.28 1.25
AMPS6.35.95.55.25.15.04.74.54.34.24.03.93.93.73.53.33.12.8
COP 3.73 3.59 3.45 3.29 3.17 3.10 2.94 2.76 2.08 1.96 1.85 1.77 1.72 1.58 1.43 1.28 1.12 0.94
EER 12.7 12.3 11.8 11.2 10.8 10.6 10.0 9.4 7.1 6.7 6.3 6.0 5.9 5.4 4.9 4.4 3.8 3.2
HI PR 186 178 171 164 160 157 151 145 139 132 127 124 122 117 113 108 104 101
LO PR 84 78 73 67 64 61 56 50 45 40 36 33 32 27 23 20 17 13
EXPANDED PERFORMANCE DAT
A
MODEL
:
GSH130181B*
/
AR*F182416**
HEATING
OPERATION
Outdoor Ambient Temperature
65 60 55 50 47 45 40 35 30 25 20 17 15 10 5 0 -5 -10
MBh 21.1 20.0 18.8 17.6
16.8
16.3 15.1 13.9 10.8 10.0 9.2 8.7 8.4 7.5 6.7 5.8 5.0 4.1
Delta T30.128.526.825.123.923.221.519.915.414.313.112.411.910.7 9.5 8.3 7.1 5.8
KW 1.55 1.53 1.50 1.47 1.45 1.44 1.41 1.38 1.36 1.33 1.30 1.28 1.27 1.24 1.21 1.18 1.15 1.12
AMPS7.26.76.35.95.75.65.35.04.84.64.44.34.24.03.73.53.33.0
COP 3.98 3.84 3.68 3.51 3.39 3.31 3.14 2.96 2.34 2.21 2.08 1.99 1.93 1.78 1.61 1.44 1.26 1.06
EER 13.6 13.1 12.6 12.0 11.6 11.3 10.7 10.1 8.0 7.5 7.1 6.8 6.6 6.1 5.5 4.9 4.3 3.6
HI PR 252 242 232 222 217 213 205 196 188 180 173 168 165 159 153 147 141 136
LO PR 82 76 72 66 62 60 55 49 44 39 35 32 31 26 23 19 17 13
GSH13
