COOLING PERFORMANCE DATA
ASH130241A*
EXPANDED PERFORMANCE DATA
MODEL: ASH130241A* & ARUF032-00*-1* / ARUF18241A* COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB
*
Airflow 59 6
3
67 71 59 6
3
6
7
71 59 6
3
67 71 59 6
3
6
7
71 59 63 67 71 59 6
3
6
7
71
MBh 23.9 24.5 26.1 27.9 23.4 23.9 25.5 27.3 22.8 23.3 24.9 26.6 22.3 22.8 24.3 26.0 21.2 21.6 23.1 24.7 19.6 20.0 21.4 22.9
S/T 0.90 0.85 0.69 0.52 0.94 0.88 0.72 0.53 0.96 0.90 0.73 0.55 1.00 0.93 0.76 0.57 1.00 0.97 0.79 0.59 1.00 1.00 0.79 0.59
DT 22 21 18 15 22 21 19 15 22 22 19 15 23 22 19 15 22 21 19 15 20 20 17 14
899 KW 1.62 1.66 1.71 1.76 1.75 1.79 1.84 1.90 1.86 1.90 1.96 2.03 1.96 2.00 2.07 2.14 2.04 2.09 2.16 2.23 2.11 2.16 2.23 2.31
AMPS 6.5 6.6 6.8 7.1 7.0 7.2 7.4 7.7 7.6 7.8 8.0 8.3 8.1 8.3 8.6 8.9 8.6 8.8 9.1 9.4 9.1 9.3 9.6 10.0
HI PR 145 156 165 172 163 175 185 193 185 199 210 219 211 227 239 250 237 255 269 281 262 282 298 310
LO PR 61 65 71 75 64 69 75 80 67 71 78 83 70 75 82 87 74 78 86 91 76 81 89 94
MBh 23.2 23.7 25.4 27.1 22.7 23.2 24.8 26.5 22.2 22.6 24.2 25.9 21.6 22.1 23.6 25.2 20.5 21.0 22.4 24.0 19.0 19.4 20.8 22.2
S/T 0.86 0.81 0.66 0.49 0.89 0.84 0.68 0.51 0.92 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.76 0.57
DT 23 22 19 15 23 22 19 16 23 22 19 16 24 23
20
16 23 22 19 15 22 21 18 14
80 799 KW 1.61 1.64 1.69 1.75 1.73 1.77 1.83 1.89 1.84 1.88 1.95 2.01 1.94 1.98 2.05 2.12 2.02 2.07 2.14 2.21 2.10 2.14 2.21 2.29
AMPS 6.4 6.6 6.8 7.0 6.9 7.1 7.3 7.6 7.5 7.7 7.9 8.2 8.0 8.2 8.5 8.8 8.5 8.7 9.0 9.4 9.0 9.2 9.6 9.9
HI PR 144 154 163 170 161 173 183 191 183 197 208 217 209 224 237 247 235 253 267 278 259 279 295 307
LO PR 60 64 70 75 64 68 74 79 66 71 77 82 70 74 81 86 73 78 85 90 76 80 88 93
MBh 21.4 21.9 23.4 25.0 21.0 21.4 22.9 24.5 20.5 20.9 22.3 23.9 20.0 20.4 21.8 23.3 19.0 19.4 20.7 22.1 17.6 17.9 19.2 20.5
S/T 0.83 0.78 0.64 0.47 0.86 0.81 0.66 0.49 0.88 0.83 0.67 0.50 0.91 0.86 0.70 0.52 0.95 0.89 0.72 0.54 0.96 0.90 0.73 0.54
DT 23 22 20 16 24 23 20 16 24 23 20 16 24 23 20 16 24 23 20 16 22 21 18 15
699 KW 1.57 1.60 1.65 1.71 1.69 1.73 1.78 1.84 1.80 1.84 1.90 1.96 1.89 1.93 2.00 2.07 1.97 2.02 2.08 2.15 2.04 2.09 2.16 2.23
AMPS 6.3 6.4 6.6 6.8 6.7 6.9 7.1 7.4 7.3 7.5 7.7 8.0 7.8 8.0 8.3 8.6 8.3 8.5 8.8 9.1 8.8 9.0 9.3 9.6
HI PR 139 150 158 165 156 168 178 185 178 191 202 211 202 218 230 240 228 245 259 270 252 271 286 298
LO PR 59 62 68 73 62 66 72 77 64 68 75 80 68 72 79 84 71 75 82 88 73 78 85 91
MBh 24.4 24.8 26.0 27.7 23.8 24.2 25.4 27.1 23.2 23.7 24.8 26.4 22.7 23.1 24.2 25.8 21.5 21.9 23.0 24.5 19.9 20.3 21.3 22.7
S/T 0.95 0.92 0.83 0.67 0.98 0.95 0.86 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.91 0.74 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77
DT 24 23 22 19 24 24 22 19 24 24 22 19 23 24 22 19 22 22 22 19 20 21 21 18
899 KW 1.63 1.67 1.72 1.78 1.76 1.80 1.86 1.92 1.87 1.92 1.98 2.05 1.97 2.02 2.08 2.16 2.06 2.10 2.17 2.25 2.13 2.18 2.25 2.33
AMPS 6.5 6.7 6.9 7.2 7.0 7.2 7.4 7.7 7.6 7.8 8.1 8.4 8.2 8.4 8.6 9.0 8.7 8.9 9.2 9.5 9.2 9.4 9.7 10.1
HI PR 146 158 166 174 164 177 187 195 187 201 212 221 213 229 242 252 239 258 272 284 264 285 301 313
LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 75 79 87 92 77 82 90 95
MBh 23.6 24.1 25.2 26.9 23.1 23.5 24.7 26.3 22.5 23.0 24.1 25.7 22.0 22.4 23.5 25.1 20.9 21.3 22.3 23.8 19.4 19.7 20.7 22.0
S/T 0.90 0.87 0.79 0.64 0.94 0.90 0.82 0.66 0.96 0.93 0.84 0.68 0.99 0.96 0.86 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.90 0.73
DT 25 24 23 20 25 25 23 20 25 25 23 20 25 25 23 20 24 24 23 20 22 23 22 19
85 799 KW 1.62 1.66 1.71 1.76 1.75 1.79 1.84 1.90 1.86 1.90 1.96 2.03 1.96 2.00 2.07 2.14 2.04 2.09 2.16 2.23 2.11 2.16 2.23 2.31
AMPS 6.5 6.6 6.8 7.1 7.0 7.2 7.4 7.7 7.6 7.8 8.0 8.3 8.1 8.3 8.6 8.9 8.6 8.8 9.1 9.4 9.1 9.3 9.6 10.0
HI PR 145 156 165 172 163 175 185 193 185 199 210 219 211 227 239 250 237 255 269 281 262 282 298 310
LO PR 61 65 71 75 64 69 75 80 67 71 78 83 70 75 82 87 74 78 86 91 76 81 89 94
MBh 21.8 22.2 23.3 24.9 21.3 21.7 22.8 24.3 20.8 21.2 22.2 23.7 20.3 20.7 21.7 23.1 19.3 19.7 20.6 22.0 17.9 18.2 19.1 20.3
S/T 0.87 0.84 0.76 0.62 0.90 0.87 0.79 0.64 0.93 0.89 0.81 0.65 0.96 0.92 0.83 0.68 0.99 0.96 0.86 0.70 1.00 0.97 0.87 0.71
DT 25 25 23 20 25 25 24 20 25 25 24 20 26 25 24 21 25 25 23 20 23 23 22 19
699 KW 1.58 1.62 1.67 1.72 1.70 1.74 1.80 1.86 1.81 1.85 1.91 1.98 1.91 1.95 2.01 2.08 1.99 2.03 2.10 2.17 2.06 2.11 2.18 2.25
AMPS 6.3 6.5 6.7 6.9 6.8 7.0 7.2 7.4 7.4 7.6 7.8 8.1 7.9 8.1 8.3 8.6 8.4 8.6 8.9 9.2 8.9 9.1 9.4 9.7
HI PR 141 151 160 167 158 170 179 187 179 193 204 213 204 220 232 242 230 247 261 272 254 273 289 301
LO PR 59 63 69 73 63 67 73 77 65 69 76 80 68 73 79 84 72 76 83 89 74 79 86 92
Shaded area is ARI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.
