COOLING PERFORMANCE DATA
ASH130481A*
EXPANDED PERFORMANCE DATA
MODEL: ASH130481A* & ARUF061-00*-1* / ARUF48601A* COOLING OPERATION
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB
*
Airflow 5963677159636771596367715963 67715963677159636771
MBh 45.6 46.6 49.8 53.3 44.6 45.6 48.7 52.0 43.5 44.5 47.5 50.8 42.5 43.4 46.4 49.5 40.3 41.2 44.0 47.1 37.4 38.2 40.8 43.6
S/T 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.94 0.77 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.83 0.62
DT 21 20 18 14 22 21 18 14 21 21 18 14 21 21 18 14 20 20 18 14 18 19 17 13
1865 KW 3.18 3.24 3.33 3.43 3.40 3.47 3.58 3.69 3.60 3.68 3.79 3.91 3.78 3.86 3.98 4.11 3.93 4.02 4.14 4.28 4.06 4.15 4.28 4.42
AMPS 12.3 12.6 13.0 13.5 13.3 13.6 14.0 14.6 14.4 14.8 15.3 15.8 15.4 15.8 16.3 16.9 16.4 16.8 17.4 18.0 17.4 17.8 18.4 19.1
HI PR 145 156 165 172 163 175 185 193 185 199 210 219 211 227 240 250 237 255 269 281 262 282 298 311
LO PR 65 69 76 81 69 73 80 85 72 76 83 89 75 80 87 93 79 84 92 97 81 87 95 101
MBh 44.3 45.3 48.4 51.7 43.3 44.2 47.3 50.5 42.3 43.2 46.1 49.3 41.2 42.1
45.0
48.1 39.2 40.0 42.8 45.7 36.3 37.1 39.6 42.3
S/T 0.90 0.85 0.69 0.51 0.93 0.88 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93
0.76
0.56 1.00 0.96 0.78 0.59 1.00 0.97 0.79 0.59
DT 22 21 18 15 22 21 19 15 22 22 19 15 23 22 19 15 22 21 19 15 20 20 17 14
80 1658 KW 3.15 3.21 3.31 3.41 3.38 3.45 3.55 3.66 3.58 3.65 3.76 3.88 3.75 3.83 3.95 4.08 3.90 3.98 4.11 4.24 4.03 4.12 4.25 4.38
AMPS 12.2 12.5 12.9 13.4 13.2 13.5 13.9 14.4 14.3 14.6 15.1 15.7 15.3 15.6 16.2 16.8 16.3 16.6 17.2 17.9 17.2 17.6 18.2 18.9
HI PR 144 155 163 170 161 173 183 191 183 197 208 217 209 225 237 247 235 253 267 278 259 279 295 307
LO PR 65 69 75 80 68 73 79 84 71 75 82 88 74 79 8
6
92 78 83 91 96 81 86 94 100
MBh 40.9 41.8 44.7 47.7 39.9 40.8 43.6 46.6 39.0 39.8 42.6 45.5 38.0 38.9 41.5 44.4 36.1 36.9 39.5 42.2 33.5 34.2 36.6 39.1
S/T 0.87 0.82 0.66 0.50 0.90 0.85 0.69 0.51 0.92 0.87 0.71 0.53 0.95 0.89 0.73 0.54 0.99 0.93 0.76 0.56 1.00 0.94 0.76 0.57
DT 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 23 22 19 15 21 20 18 14
1451 KW 3.08 3.14 3.23 3.33 3.30 3.37 3.47 3.57 3.49 3.57 3.67 3.79 3.66 3.74 3.86 3.98 3.81 3.89 4.01 4.14 3.94 4.02 4.14 4.28
AMPS 11.9 12.1 12.5 13.0 12.8 13.1 13.5 14.0 13.9 14.2 14.7 15.3 14.9 15.2 15.7 16.3 15.8 16.2 16.7 17.4 16.7 17.1 17.7 18.4
HI PR 139 150 158 165 156 168 178 185 178 191 202 211 202 218 230 240 228 245 259 270 252 271 286 298
LO PR 63 67 73 77 66 70 77 82 69 73 80 85 72 77 84 89 76 81 88 94 78 83 91 97
MBh 46.4 47.3 49.6 52.9 45.4 46.2 48.4 51.7 44.3 45.1 47.3 50.4 43.2 44.0 46.1 49.2 41.0 41.8 43.8 46.7 38.0 38.8 40.6 43.3
S/T 0.99 0.96 0.86 0.70 1.00 0.99 0.89 0.73 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.98 0.80 1.00 1.00 0.99 0.80
DT 23 22 21 18 22 23 21 18 22 22 21 18 21 22 22 19 20 21 21 18 19 19 20 17
1865 KW 3.20 3.26 3.36 3.46 3.43 3.50 3.60 3.72 3.63 3.71 3.82 3.94 3.81 3.89 4.01 4.14 3.96 4.05 4.18 4.31 4.10 4.18 4.32 4.46
AMPS 12.4 12.7 13.1 13.6 13.4 13.7 14.2 14.7 14.6 14.9 15.4 16.0 15.6 15.9 16.5 17.1 16.6 17.0 17.5 18.2 17.5 18.0 18.6 19.3
HI PR 146 158 166 174 164 177 187 195 187 201 212 222 213 229 242 252 239 258 272 284 265 285 301 314
LO PR 66 70 76 81 70 74 81 86 72 77 84 89 76 81 88 94 80 85 92 98 82 88 96 102
MBh 45.1 46.0 48.1 51.4 44.0 44.9 47.0 50.2 43.0 43.8 45.9 49.0 41.9 42.8 44.8 47.8 39.8 40.6 42.5 45.4 36.9 37.6 39.4 42.0
S/T 0.95 0.91 0.82 0.67 0.98 0.95 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77
DT 24 23 22 19 24 24 22 19 24 24 22 19 23 24 22 19 22 23 22 19 20 21 21 18
85 1658 KW 3.18 3.24 3.33 3.43 3.40 3.47 3.58 3.69 3.60 3.68 3.79 3.91 3.78 3.86 3.98 4.11 3.93 4.02 4.14 4.28 4.06 4.15 4.28 4.42
AMPS 12.3 12.6 13.0 13.5 13.3 13.6 14.0 14.6 14.4 14.8 15.3 15.8 15.4 15.8 16.3 16.9 16.4 16.8 17.4 18.0 17.4 17.8 18.4 19.1
HI PR 145 156 165 172 163 175 185 193 185 199 210 219 211 227 240 250 237 255 269 281 262 282 298 311
LO PR 65 69 76 81 69 73 80 85 72 76 83 89 75 80 87 93 79 84 92 97 81 87 95 101
MBh 41.6 42.4 44.4 47.4 40.6 41.4 43.4 46.3 39.7 40.4 42.4 45.2 38.7 39.5 41.3 44.1 36.8 37.5 39.3 41.9 34.1 34.7 36.4 38.8
S/T 0.91 0.88 0.79 0.64 0.94 0.91 0.82 0.67 0.97 0.93 0.84 0.68 1.00 0.96 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74
DT 24 24 22 19 24 24 23 20 24 24 23 20 25 24 23 20 23 24 22 19 22 22 21 18
1451 KW 3.10 3.17 3.26 3.36 3.33 3.39 3.49 3.60 3.52 3.59 3.70 3.82 3.69 3.77 3.89 4.01 3.84 3.92 4.04 4.17 3.97 4.05 4.18 4.31
AMPS 12.0 12.3 12.6 13.1 12.9 13.2 13.7 14.2 14.0 14.4 14.8 15.4 15.0 15.4 15.9 16.5 15.9 16.3 16.9 17.5 16.9 17.3 17.9 18.6
HI PR 141 151 160 167 158 170 179 187 180 193 204 213 204 220 232 242 230 248 261 273 254 273 289 301
LO PR 63 67 73 78 67 71 78 83 69 74 81 86 73 78 85 90 76 81 89 95 79 84 92 98
Shaded area is ARI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.
