COOLING PERFORMANCE DATA
GSH130483A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSH130483A* / ARUF61-00*-1* / ARUF48601A*
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67715963677159636771
MBh 45.6 46.6 49.8 53.3 44.6 45.6 48.7 52.0 43.5 44.5 47.5 50.8 42.5 43.4 46.4 49.5 40.3 41.2 44.0 47.1 37.4 38.2 40.8 43.6
S/T 0.95 0.89 0.72 0.54 1.00 0.92 0.75 0.56 1.00 0.94 0.77 0.57 1.00 1.00 0.79 0.59 1.00 1.00 0.82 0.61 1.00 1.00 0.83 0.62
Delta T22211815232119152221191522 22 19152121181519191714
1800 KW 3.15 3.22 3.32 3.42 3.39 3.46 3.58 3.69 3.60 3.68 3.80 3.93 3.79 3.87 4.00 4.13 3.95 4.04 4.17 4.31 4.09 4.18 4.32 4.46
AMPS 10.2 10.4 10.7 11.1 11.0 11.2 11.6 12.0 11.9 12.2 12.6 13.0 12.7 13.0 13.4 13.9 13.5 13.8 14.2 14.8 14.3 14.6 15.1 15.6
HI PR 148 159 168 176 166 179 189 197 189 204 215 224 215 232 245 255 242 261 275 287 268 288 304 317
LO PR 63 67 73 78 67 71 78 83 69 74 81 86 73 78 85 90 76 81 89 95 79 84 92 98
MBh 44.3 45.3 48.4 51.7 43.3 44.2 47.3 50.5 42.3 43.2 46.1 49.3 41.2 42.1
45.0
48.1 39.2 40.0 42.8 45.7 36.3 37.1 39.6 42.3
S/T 0.90 0.85 0.69 0.51 0.94 0.88 0.71 0.53 0.96 0.90 0.73 0.55 0.99 0.93
0.76
0.56 1.00 0.96 0.78 0.59 1.00 0.97 0.79 0.59
Delta T23221915232219152322191623 22
20
16 23 22 19 15 21 21 18 14
80 1600 KW 3.13 3.19 3.29 3.40 3.37 3.44 3.55 3.66 3.58 3.65 3.77 3.89 3.76 3.84
3.97
4.10 3.92 4.00 4.14 4.27 4.05 4.14 4.28 4.43
AMPS 10.1 10.3 10.6 11.0 10.9 11.1 11.5 11.9 11.8 12.1 12.4 12.9 12.6 12.9
13.3
13.8 13.4 13.7 14.1 14.6 14.1 14.5 14.9 15.5
HI PR 147 158 167 174 165 177 187 195 187 202 213 222 213 230
242
253 240 258 273 284 265 285 301 314
LO PR 63 67 73 77 66 70 77 82 69 73 80 85 72 77
84
89 76 81 88 94 78 83 91 97
MBh 40.9 41.8 44.7 47.7 39.9 40.8 43.6 46.6 39.0 39.8 42.6 45.5 38.0 38.9 41.5 44.4 36.1 36.9 39.5 42.2 33.5 34.2 36.6 39.1
S/T 0.87 0.82 0.66 0.50 0.90 0.85 0.69 0.51 0.92 0.87 0.71 0.53 0.95 0.90 0.73 0.54 0.99 0.93 0.76 0.57 1.00 0.94 0.76 0.57
Delta T23221916242320162423201624 23 20162423201622211815
1400 KW 3.05 3.12 3.21 3.32 3.28 3.35 3.46 3.57 3.49 3.56 3.68 3.80 3.67 3.75 3.87 4.00 3.82 3.90 4.03 4.17 3.95 4.04 4.17 4.31
AMPS 9.8 10.0 10.4 10.7 10.6 10.8 11.2 11.6 11.5 11.7 12.1 12.6 12.2 12.5 12.9 13.4 13.0 13.3 13.7 14.2 13.7 14.1 14.5 15.1
HI PR 142 153 162 169 160 172 181 189 182 195 206 215 207 223 235 245 233 250 264 276 257 277 292 305
LO PR 61 65 71 75 64 68 75 79 67 71 77 82 70 75 81 87 73 78 85 91 76 81 88 94
MBh 46.4 47.3 49.6 52.9 45.4 46.2 48.4 51.7 44.3 45.1 47.3 50.4 43.2 44.0 46.1 49.2 41.0 41.8 43.8 46.7 38.0 38.8 40.6 43.3
S/T 0.99 0.96 0.86 0.70 1.00 0.99 0.90 0.73 1.00 1.00 0.92 0.74 1.00 1.00 0.95 0.77 1.00 1.00 0.98 0.80 1.00 1.00 0.99 0.80
Delta T24232219232322192323221922 22 22192121221919202118
1800 KW 3.18 3.24 3.35 3.45 3.42 3.49 3.60 3.72 3.63 3.71 3.83 3.96 3.82 3.91 4.03 4.17 3.98 4.07 4.21 4.35 4.12 4.21 4.35 4.50
AMPS 10.3 10.5 10.8 11.2 11.1 11.3 11.7 12.1 12.0 12.3 12.7 13.1 12.8 13.1 13.5 14.0 13.6 13.9 14.4 14.9 14.4 14.7 15.2 15.8
HI PR 150 161 170 177 168 181 191 199 191 206 217 226 218 234 247 258 245 263 278 290 270 291 307 321
LO PR 64 68 74 79 67 72 78 83 70 75 81 87 74 78 86 91 77 82 90 95 80 85 93 99
MBh 45.1 46.0 48.1 51.4 44.0 44.9 47.0 50.2 43.0 43.8 45.9 49.0 41.9 42.8 44.8 47.8 39.8 40.6 42.5 45.4 36.9 37.6 39.4 42.0
S/T 0.95 0.91 0.82 0.67 0.98 0.95 0.85 0.69 1.00 0.97 0.88 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.95 0.77
Delta T25242320252423202524232024 25 23202323232021222119
85 1600 KW 3.15 3.22 3.32 3.42 3.39 3.46 3.58 3.69 3.60 3.68 3.80 3.93 3.79 3.87 4.00 4.13 3.95 4.04 4.17 4.31 4.09 4.18 4.32 4.46
AMPS 10.2 10.4 10.7 11.1 11.0 11.2 11.6 12.0 11.9 12.2 12.6 13.0 12.7 13.0 13.4 13.9 13.5 13.8 14.2 14.8 14.3 14.6 15.1 15.6
HI PR 148 159 168 176 166 179 189 197 189 204 215 224 215 232 245 255 242 261 275 287 268 288 304 317
LO PR 63 67 73 78 67 71 78 83 69 74 81 86 73 78 85 90 76 81 89 95 79 84 92 98
MBh 41.6 42.4 44.4 47.4 40.6 41.4 43.4 46.3 39.7 40.4 42.4 45.2 38.7 39.5 41.3 44.1 36.8 37.5 39.3 41.9 34.1 34.7 36.4 38.8
S/T 0.91 0.88 0.79 0.64 0.95 0.91 0.82 0.67 0.97 0.94 0.84 0.68 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.91 0.74
Delta T25252320252523202525232025 25 24202425232022232219
1400 KW 3.08 3.14 3.24 3.34 3.31 3.38 3.49 3.60 3.52 3.59 3.71 3.83 3.70 3.78 3.90 4.03 3.85 3.94 4.07 4.20 3.99 4.07 4.21 4.35
AMPS 9.9 10.1 10.4 10.8 10.7 10.9 11.3 11.7 11.6 11.8 12.2 12.7 12.3 12.6 13.0 13.5 13.1 13.4 13.9 14.4 13.9 14.2 14.7 15.2
HI PR 144 155 163 170 161 174 183 191 183 197 208 217 209 225 237 248 235 253 267 279 260 279 295 308
LO PR 61 65 71 76 65 69 75 80 67 72 78 83 71 75 82 88 74 79 86 92 77 82 89 95
Shaded area is AHRI Rating Conditions
n
ditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves.

Goodman GSH Series Specifications

General

SEER Rating	Up to 16 SEER
Refrigerant	R-410A
Cooling Capacity	1.5 to 5 tons
Stages	Single-Stage
Series	GSH Series
Compressor Type	Single-stage scroll
Energy Efficiency	High
Cooling Capacity (BTU/h)	18, 000 - 60, 000 BTU/h
Warranty	10-year limited parts warranty
