COOLING PERFORMANCE DATA
GSH130604A*
EXPANDED PERFORMANCE DATA
COOLING OPERATION
MODEL: GSH13060-4A* / ARUF61-00*-1* / ARUF48601A* Design Subcooling 9 ±3 °F @ the liquid service valve, AHRI 95 test conditions
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
MBh 56.29 57.52 61.45 65.69 54.98 56.18 60.02 64.16 53.67 54.84 58.59 62.64 52.36 53.51 57.17 61.11 49.74 50.83 54.31 58.05 46.08 47.09 50.31 53.78
S/T 0.90 0.85 0.69 0.51 0.93 0.88 0.71 0.53 0.96 0.90 0.73 0.55 1.00 0.93 0.75 0.56 1.00 0.96 0.78 0.59 1.00 0.97 0.79 0.59
Delta T23221915232219162322191624 23 20 162322191521211814
2025 KW 4.04 4.12 4.24 4.37 4.33 4.42 4.55 4.69 4.59 4.68 4.83 4.98 4.82 4.92 5.07 5.23 5.01 5.12 5.28 5.45 5.18 5.29 5.46 5.64
AMPS 3.2 3.2 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.5 3.4 3.5 3.5 3.5
HI PR 155 167 176 184 174 187 198 206 198 213 225 234 225 242 256 267 253 273 288 300 280 301 318 332
LO PR 60 64 69 74 63 67 73 78 66 70 76 81 69 73 80 85 72 77 84 89 75 80 87 92
MBh 54.755.859.763.853.454.558.362.352.153.256.960.850.8 51.9
55.5
59.3 48.3 49.4 52.7 56.4 44.7 45.7 48.8 52.2
S/T 0.86 0.81 0.66 0.49 0.89 0.84 0.68 0.51 0.91 0.86 0.70 0.52 0.94 0.88
0.72
0.54 0.98 0.92 0.75 0.56 0.99 0.93 0.75 0.56
Delta T24232016242320162423201624 23
20
16 24 23 20 16 23 22 19 15
80 1800 KW 4.01 4.09 4.21 4.34 4.30 4.38 4.52 4.66 4.55 4.65 4.79 4.94 4.78 4.88
5.03
5.19 4.97 5.08 5.24 5.41 5.14 5.25 5.41 5.59
AMPS 3.2 3.2 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.4 3.4 3.4
3.4
3.4 3.4 3.4 3.4 3.5 3.4 3.5 3.5 3.5
HI PR 153 165 174 182 172 185 196 204 196 211 222 232 223 240
253
264 251 270 285 297 277 298 315 329
LO PR 59 63 69 73 63 67 73 77 65 69 75 80 68 73
79
84 72 76 83 89 74 79 86 92
MBh 50.4 51.5 55.1 58.9 49.3 50.3 53.8 57.5 48.1 49.1 52.5 56.1 46.9 47.9 51.2 54.8 44.6 45.6 48.7 52.0 41.3 42.2 45.1 48.2
S/T 0.83 0.78 0.63 0.47 0.86 0.81 0.66 0.49 0.88 0.83 0.67 0.50 0.91 0.85 0.69 0.52 0.94 0.89 0.72 0.54 0.95 0.89 0.73 0.54
Delta T24232016252421162524211625 24 21 172524201623221915
1575 KW 3.92 4.00 4.11 4.24 4.20 4.28 4.41 4.55 4.45 4.54 4.68 4.82 4.67 4.76 4.91 5.07 4.85 4.95 5.11 5.27 5.01 5.12 5.28 5.45
AMPS 3.2 3.2 3.2 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.4 3.3 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.5 3.5
HI PR 149 160 169 176 167 180 190 198 190 204 216 225 216 233 246 256 243 262 277 288 269 289 306 319
LO PR 57 61 67 71 61 65 70 75 63 67 73 78 66 70 77 82 69 74 81 86 72 76 83 89
MBh 57.27 58.38 61.15 65.23 55.94 57.02 59.72 63.72 54.61 55.67 58.30 62.20 53.28 54.31 56.88 60.68 50.61 51.59 54.04 57.65 46.88 47.79 50.05 53.40
S/T 0.95 0.91 0.82 0.67 0.98 0.95 0.85 0.69 1.00 0.97 0.87 0.71 1.00 1.00 0.90 0.73 1.00 1.00 0.94 0.76 1.00 1.00 0.94 0.77
Delta T25242320252423202524232024 25 23 202323232021222119
2025 KW 4.07 4.15 4.27 4.40 4.36 4.45 4.59 4.73 4.62 4.72 4.87 5.02 4.85 4.96 5.11 5.28 5.05 5.16 5.32 5.49 5.22 5.33 5.50 5.68
AMPS 3.2 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.5 3.4 3.5 3.5 3.5
HI PR 157 168 178 185 176 189 200 208 200 215 227 237 227 245 258 270 256 275 291 303 283 304 321 335
LO PR 60 64 70 75 64 68 74 79 66 71 77 82 70 74 81 86 73 78 85 90 76 80 88 93
MBh 55.6 56.7 59.4 63.3 54.3 55.4 58.0 61.9 53.0 54.0 56.6 60.4 51.7 52.7 55.2 58.9 49.1 50.1 52.5 56.0 45.5 46.4 48.6 51.8
S/T 0.90 0.87 0.79 0.64 0.93 0.90 0.81 0.66 0.96 0.92 0.83 0.68 0.99 0.95 0.86 0.70 1.00 0.99 0.89 0.73 1.00 1.00 0.90 0.73
Delta T26252421262524212626242126 26 24 212525242123242219
85 1800 KW 4.04 4.12 4.24 4.37 4.33 4.42 4.55 4.69 4.59 4.68 4.83 4.98 4.82 4.92 5.07 5.23 5.01 5.12 5.28 5.45 5.18 5.29 5.46 5.64
AMPS 3.2 3.2 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.5 3.4 3.5 3.5 3.5
HI PR 155 167 176 184 174 187 198 206 198 213 225 234 225 242 256 267 253 273 288 300 280 301 318 332
LO PR 60 64 69 74 63 67 73 78 66 70 76 81 69 73 80 85 72 77 84 89 75 80 87 92
MBh 51.3 52.3 54.8 58.5 50.1 51.1 53.5 57.1 48.9 49.9 52.2 55.7 47.7 48.7 51.0 54.4 45.4 46.2 48.4 51.7 42.0 42.8 44.9 47.9
S/T 0.87 0.84 0.76 0.61 0.90 0.87 0.78 0.64 0.92 0.89 0.80 0.65 0.95 0.92 0.83 0.67 0.99 0.95 0.86 0.70 1.00 0.96 0.87 0.71
Delta T26262421262625212626252127 26 25 212626242124242320
1575 KW 3.95 4.02 4.14 4.27 4.23 4.32 4.45 4.58 4.48 4.57 4.71 4.86 4.70 4.80 4.95 5.11 4.89 4.99 5.15 5.32 5.05 5.16 5.32 5.50
AMPS 3.2 3.2 3.2 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.4 3.3 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.4 3.5 3.5
HI PR 150 162 171 178 169 181 192 200 192 206 218 227 218 235 248 259 246 264 279 291 272 292 309 322
LO PR 58 62 67 72 61 65 71 76 64 68 74 79 67 71 78 83 70 75 81 87 73 77 84 90
Shaded area i s AHRI Rating Conditions IDB: Entering Indoor Dry Bulb Temperature KW=Total system power AMPS=outdoor unit amps (comp.+fan) High and low pressures are measured at the liquid and suction service valves.
