P a g e | 32

GXV3350 User Guide

Version 1.0.1.8

GETTING TO KNOW GXV3350

Use the Touchscreen

When the phone boots up in HOME screen, the LCD will display as below. A registered account is shown

in the following figure and users might need register their own account to have the account status displayed.

Figure 9: GXV3350 Default Home Screen

Swipe from right to show the application menu of the phone. The settings and applications installed will be

brought up as shown below.

Figure 10: GXV3350 Onscreen Menu

The Status Bar shows time, network

connectivity, signal strength, notification

information etc...

Date and Time

Shortcut: Contacts

Shortcut: Call History

Shortcut: Phone Dialer

Account information Widget. Up to 6

accounts/Programmable-keys can

be displayed.
