P a g e | 45

GXV3350 User Guide

Version 1.0.1.8

DND is enabled.

Silent mode is enabled. When it's on, the incoming call/message

won't produce ring tone/notification tone from phone's speaker.

USB flash drive is inserted.

Downloading files via Internet connection.

Unread voicemail to be retrieved.

Incoming call from blacklist contact.

Camera is disabled.

Contact storage is full.

HDMI cable is connected to display device.

The phone is powered up using PoE.

Call forward is set up.

PPPoE is connected.

PPPoE is not connected.

Warning message.
