21.6 Factory settings
● Function is enabled.
❍ Function is disabled.
- Function is not available.
Settings CRE CME
Setpoint 30 % of sensor range 30 % of sensor range
Operating mode Normal Normal
Control mode Constant pressure Constant pressure
Pipe filling function ❍ ❍
Buttons on product ● ●
Stop function (Low-flow stop function) ● ●
Controller (Controller settings) ● ●
Ti 0.5 0.5
Kp 0.5 0.5
Operating range 25-100 % 25-100 %
Ramps
Ramp-up 1 second 1 second
Ramp-down 3 seconds 3 seconds
Number (Pump number) - -
Radio communication ● ●
Analog input 1 4-20 mA 4-20 mA
Analog input 2 ❍ ❍
Analog input 3
❍
8)
-
9)
Pt100/1000 input 1 ❍
-
9)
Pt100/1000 input 2 ❍
-
9)
Digital input 1 External stop External stop
Digital input 2 ❍
-
9)
Digital input/output 3
Dry running
10)
Dry running
10)
Digital input/output 4 ❍
-
9)
Pulse flowmeter ❍ ❍
Predefined setpoints ❍ ❍
Analog output ❍
-
9)
External setpoint function ❍ ❍
Signal relay 1 Ready Ready
Signal relay 2 Running Running
Limit 1 exceeded ❍
❍
9)
Limit 2 exceeded ❍ ❍
LiqTec function ❍
-
9)
Standstill heating ❍ ❍
Motor bearing monitoring ● ●
Pump name Hydro Multi-E Hydro Multi-E
8)
Active if inlet sensor is fitted from factory.
9)
Only available if an advanced functional module, type FM 300, is fitted.
10)
Not active if inlet sensor is fitted from factory.
46
English (GB)
