Smartdop
®
30EX Basic Operation
3. CONTROLS
3-1 FRONT VIEW
1) PRINTER To print waveforms, systolic pressures,
ABI/TBI and velocity/pressure documentation.
2) SPEAKER Outputs Doppler sounds.
3) VOLUME CONTROL To adjust sound volume.
4) PROBE HOLDER 1 For probe placement when not in use.
5) PROBE HOLDER 2 For probe placement when not in use.
6) INFLATION INLET To connect the tubing for the blood pressure cu.
7) LCD DISPLAY Displays waveform, numerical data and menu for
mode settings.
