30EX Basic Operation
5. MODE & MENU SETTINGS
5-3 MENU (Cont.)
5-3-4 MENU FOR PRESSURE MODE (MEASUREMENT & FREEZE)
For measuring blood systolic pressures, performing Ankle Brachial Index (ABI) and Toe Brachial
Index (TBI) studies and calculating ABI and TBI ratios.
Press the ARM/LEG or TOE mode to select the menu.
Bold face selections in the table above indicate default settings.
*1 GUIDANCE is available only in measurement mode.
*2 WAVEFORM, CURSOR and P.DISP are available only in freeze mode.
*3 MEMORY-STORE is available only in freeze mode.
*4 DISCHARGE is available when the AC adaptor is connected to the main unit.
18
Menu Submenu Selections Reference Section
STORE (*3) 1 to 30, FREEZE 5-3-8
MEMORY READ 1 to 30, FREEZE 5-3-9
CLEAR 1 to 30, ALL 5-3-10
GUIDANCE (*1) ON, OFF 5-3-22
WAVEFORM (*2) FULL, MAGNIFIED 5-3-13
CURSOR (*2) 5-3-23
P.DISPLAY (*2) ON, OFF 5-3-24
P.CLEAR 5-3-25
LANGUAGE ENGLISH, DEUTSCH, 5-3-14
ITALIANO, ESPAÑOL,
FRANÇAISE
OTHERS PRB-KEY FREEZE, PRINT, FRZ&PRINT 5-3-15
(Probe button)
BACKLIGHT ON, OFF, 10 to 60 5-3-18
(10 sec. steps)
AUTO OFF ON, OFF 5-3-19
RESET 5-3-20
DISCHARGE (*3) 5-3-21
To Next Page
