Smartdop
®
30EX Basic Operation
5-3 MENU (Cont.)
5-3-3 MENU FOR BLOOD VELOCITY FREEZE MODE
For observing blood ow velocity waveforms and numerical data.
Press the probe button or the INF/DUMP button to select the menu; press again to exit.
Bold face selections in the table above indicate default settings.
*1 DISCHARGE is available when the AC adaptor is connected to the main unit.
5. MODE & MENU SETTINGS
Menu Submenu Selections Reference Section
STORE 1 to 30, FREEZE 5-3-8
MEMORY READ 1 to 30, FREEZE 5-3-9
CLEAR 1 to 30, ALL 5-3-10
DIR, direction Forward , Reverse 5-3-11
DISP, display WAVE, DATA 5-3-12
WAVEFORM PAGE 1, PAGE 2 5-3-13
LANGUAGE ENGLISH, DEUTSCH, 5-3-14
ITALIANO, ESPAÑOL,
FRANÇAISE
OTHERS PRB-KEY FREEZE, PRINT, FRZ&PRINT 5-3-15
(Probe button)
CAL PRINT ON, OFF
5-3-17
BACKLIGHT ON, OFF, 10 to 60 5-3-18
(10 sec. steps)
AUTO OFF ON, OFF 5-3-19
RESET 5-3-20
DISCHARGE (*3) 5-3-21
17
